SSV Works WC2-FKP65 Instructions

SSV WORKS, 201 N. Rice Ave Unit A, Oxnard, CA 93030
www.SSVworks.com | Phone: 818-991-1778 | Fax: 866-293-6751
WARRANTY INFORMATION:
All SSV Works enclosures are covered by a limited lifetime warranty against
defects in material or workmanship. All SSV Works Electronics are covered by a
limited 1 year warranty against defects in material or workmanship. All SSV Works
Speakers are covered by a limited 1 year warranty against defects in material or
workmanship. Labor for replacement of defective components is not covered.
Contact SSV Works for further warranty information.
TOOLS NEEDED FOR INSTALLATION
- T-30 Torx Driver - Phillips Screwdriver
PARTS LIST IMAGES
1. WC2-FKP65
Enclosures (1 pair)
B. Set the unloaded pod in place and mark the top mounting
location with a scribe or punch tool on to the floorboard.
- Drill with 1/4" Drill bit
2. M6 x 16mm 3. M6 Washers x 12
Screws x 12
B
6.5" Speaker Front Kick Panels
!
- Scribe or Punch tool
4. #7 Screws x 8
C. With a 1/4" drill bit, drill the screw hole for mounting the
speaker pod.
WC2-FKP65
Textron Wildcat
Please read and understand these
instructions completely before
installation to avoid possible injury, or
damage to the accessory or vehicle.
A. Bolt down the pod brackets like above
using five (5) M6 Screws and Washers.
A
C
