SSV WORKS, 201 N. Rice Ave Unit A, Oxnard, CA 93030
www.SSVworks.com | Phone: 818-991-1778 | Fax: 866-293-6751
WARRANTY INFORMATION:
All SSV Works enclosures are covered by a limited lifetime warranty against defects in
material or workmanship. All SSV Works Electronics are covered by a limited 1 year
warranty against defects in material or workmanship. Labor for replacement of defective
components is not covered. All SSV Works Speakers are covered by a limited 1 year
warranty against defects in material or workmanship. Contact SSV Works for further
warranty information.
TOOLS NEEDED FOR INSTALLATION
- 5mm Allen Key
PARTS LIST IMAGES
1. US-C65 Enclosures (1 pair)
4. M6 Hex Head Bolts &
Washers x4
INSTALLATION NOTES
It is recommended to wrap the bag that the clamps come in around the cage before you slide the clamp onto the cage to prevent scratching.
- 8mm Open End Wrench
2. Dual Mounting Ring
Adapter x 2
5. M6 Allen Socket Head Bolts
& Washers x4
6.5" Speaker Enclosures
Please read and understand these
!
instructions completely before
installation to avoid possible injury, or
damage to the accessory or vehicle.
3. Ring Clamp x 4
6. M6 Set Screws x 4
US-C65
Universal Cage Mount
7. #7 Screws x 8
(for use with unloaded pods only)
Advertisement
Table of Contents
Related Manuals for SSV Works US-C65
Summary of Contents for SSV Works US-C65
- Page 1 Labor for replacement of defective damage to the accessory or vehicle. components is not covered. All SSV Works Speakers are covered by a limited 1 year warranty against defects in material or workmanship. Contact SSV Works for further warranty information.
- Page 2 Connect and install the speaker into the enclosure (be sure to connect the “+” speaker wire to the “+” terminal on the speaker and the “-“ speaker wire to the “-“ terminal on the if not using a SSV Works speaker). Use a #2 Phillips screwdriver to mount the speaker to the pod using the provided #7 (holes are pre-drilled for use for #7 screws) D.
- Page 3 Amplifier For proper sound when not using the SSV Works speaker harness, ensure the speaker polarity is correct connect the “+” to the “+” and the “-“to the “-“from the speaker wire to the amplifier. If using with an SSV Works complete system refer to the amplifier wiring instructions for more detailed wiring information.
