Homeowner's Manual
P2
WARNING:
FIRE OR EXPLOSION HAZARD
Failure to follow safety warnings
exactly could result in serious
injury, death, or property damage.
Do not store or use gasoline or other
fl ammable vapors and liquids in the
vicinity of this or any other appliance.
WHAT TO DO IF YOU SMELL GAS
Do not try to light any appliance.
▪
DANGER
4009485-01
Direct Vent Gas Fireplace
natural gas 200AN
propane gas 200AP
Hot glass
will cause burns.
Do not touch glass
until cooled.
Never allow children
to touch glass.
Do not touch any electrical switch; do
▪
not use any phone in your building.
Leave the building immediately.
▪
Immediately call your gas supplier from
▪
a neighbor's phone. Follow the gas
supplier's instructions.
If you cannot reach your gas supplier,
▪
call the fi re department.
Installation and service must be
performed by a qualifi ed installer, service
agency or the gas supplier.
A barrier designed to reduce
the risk of burns from the hot
viewing glass is provided with this
appliance and must be installed for
the protection of children and
other at-risk individuals.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Valor 200AN
Summary of Contents for Valor 200AN
- Page 1 Homeowner’s Manual Direct Vent Gas Fireplace natural gas 200AN propane gas 200AP Do not touch any electrical switch; do ▪ WARNING: not use any phone in your building. FIRE OR EXPLOSION HAZARD Leave the building immediately. ▪ Failure to follow safety warnings Immediately call your gas supplier from ▪...
- Page 2 Ltd. reserves the right to change or modify any information or specifications without notice. Miles Industries Ltd. grants no warranty, implied or stated, for the installation or maintenance of your heater, Valor Fireplaces and assumes no responsibility for any consequential 190–2255 Dollarton Highway damage(s).
-
Page 3: Table Of Contents
fireplace. Contents Your Valor Fireplace Safety and your fi replace .......... 4 Here are some important details about your Valor Child safety and your fi replace ......... 6 fireplace, should you need to contact your dealer. Model: _________________________________________ Getting started ............ -
Page 4: Safety And Your Fireplace
Read and understand all instructions carefully before operating your fi replace. Failure to follow these instructions may result in possible fi re hazard and will void the warranty. Replacement manuals are available by contacting the Valor Customer Service at 1-800-468-2567, or by visiting valorfi... - Page 5 Safety and your fireplace Glass window Initial and annual inspection • Installation and repair should be performed by a qualifi ed service person. The appliance should WARNING be inspected before use and at least annually by a professional service person. More frequent clean- Do not operate this appliance with the ing might be required due to excessive lint from glass front removed, cracked, or broken.
-
Page 6: Child Safety And Your Fireplace
Read and carefully follow all safety warnings and operating instructions contained in this manual, and follow these important child safety precautions and recommendations: • Parts of your Valor Fireplace become extremely • A physical barrier is strongly recommended if hot while in operation. The glass viewing window there are young children, or at-risk individuals in temperature can exceed 500º... -
Page 7: Getting Started
After a few hours use, the vapors will have disappeared and the flames will be at their normal height. Valor automatic gas shut-off For your safety, this fireplace is fitted with a flame supervision device which will shut-off the gas supply if, for any reason, the pilot flame goes out. -
Page 8: Parts Of Your Fireplace
Parts of your fireplace Here are the major components of your installed fireplace, both with and without the protective barrier installed. Your individual fireplace may appear slightly different depending on your installed options. Front/Trim Barrier Screen Backing Plate (mesh) Window Liners (behind barrier screen) Fuel Bed... -
Page 9: Operating Your Fireplace
Appendix A - Remote Control the fireplace - see page 7 to learn how to access it. Operation on pages 23–29 of this manual or Also, a copy of this plate is reproduced in Appendix A visit valorfireplaces.com/remotes of the Installation Manual. -
Page 10: Preventing Inadvertent Ignition
Automatic shut-off (in certain conditions) Your fireplace’s remote control is equipped with an automatic shut-off mechanism which is activated in certain conditions. See Appendix A - Remote Control Operation on page 28 or go to valorfireplaces.com/ remotes for a description of this feature. -
Page 11: Replacing Batteries
Replacing batteries To replace the batteries: WARNING 1. Locate the battery holder at the bottom of the fi replace and pull it out. Do not attempt to access the batteries while the fi replace is hot! Let the fi replace cool fi rst before touching it! Caution Do not use a screwdriver or other metallic object to remove the batteries from the... -
Page 12: Annual Service And Maintenance
Annual service and maintenance We recommend having your fi replace serviced every year. Contact your dealer quoting the model number. It will be helpful if the fi replace’s serial number can also be quoted. These numbers are on the information plate (see Locating fi... -
Page 13: Cleaning Your Fireplace
Cleaning your fireplace Remove Window The window is held in place by 4 spring-loaded latches, 2 on each side of the firebox. A handle is necessary to unhook the latches. 1. Locate the handle on the bottom front of the fi re- place. - Page 14 • Damage components. • Cause overheating resulting in dangerous conditions. Damage caused by incorrect window installation is not covered by the Valor Warranty. 2. Using the latch pull handle, hook the four spring latches over the corresponding tabs as shown.
- Page 15 Cleaning your fireplace 3. Pull and release the top and bottom of the window 8. Reinstall the side doors if the front used includes to ensure the springs return it. them. If not, go to step 9. 4. Apply fi rm hand pressure around window frame to a.
- Page 16 Cleaning your fireplace Hook the barrier screen or the front/barrier Hook the front/barrier screen to the backing screen depending of the front used. plate. Install barrier screen a. Rest the bottom tabs on the edge of the removable panel. b. Push the screen against the steel front. c.
- Page 17 Most Log position paper towels and synthetic materials are abrasive Log position is important in your Valor fi replace. to ceramic glass and should be avoided. Proper log positioning optimizes the beauty of the •...
-
Page 18: Checking Pilot And Burner Flames
Checking pilot and burner flames Correct fl ame appearance A periodic check of the pilot and burner flames should be made. Check after the fire has been on for at least 30 minutes. The pilot flame must cover the tip of the thermocouple probe. -
Page 19: Frequently Asked Questions
If the fireplace still won't turn on after that, call your dealer for further information. Your fireplace may require service by a qualified service technician. Visit valorfireplaces.com/contact for a list of dealers near you. I've just started my fi replace When first lit, your fireplace will burn some paint and oil residues left over... - Page 20 Where can I purchase parts Any of our Valor dealers are able to order parts or provide field service. for my fi replace? Please contact your dealer—see page 3, or visit valorfireplaces.com/ contact for a list of dealers near you.
-
Page 21: Valor ® Warranty
Installation and maintenance must be performed by 5. No Other Warranty an authorized and trained dealer in accordance with All obligations to repair this unit are de ned in this warranty. -
Page 22: Valor ® Outdoor Installation Warranty
The Company does not allow anyone to extend, b) Installation and maintenance must be performed alter or modify this warranty and assumes no... -
Page 23: Appendix A - Remote Control Operation
Appendix A - Remote Control Operation Remote Control Operation Note: Before using the remote control system for the first time, the receiver and the handset must be paired. NOTE: Before using the remote control system for the first time, the receiver and the handset must be paired. See See the Remote Control Pairing section in the fireplace's Installation Manual. - Page 24 Appendix A - Remote Control Operation Designated Low Fire and High Fire To deactivate functions: To go to low re, double-click . “LO” 1. Install batteries. All icons are displayed and ashing. is displayed. 2. While the icons are ashing, press the relevant func- tion button and hold for 10 seconds.
- Page 25 Appendix A - Remote Control Operation Child Proof Light/Dimmer Operation Your handset can be set to lock out all commands to the Not available on this appliance. replace, except OFF. Press is displayed. Light is on at preset level. To turn Child Proof ON: 1.
- Page 26 Appendix A - Remote Control Operation Modes of Operation Thermostatic Mode Thermostatic Mode The room temperature is measured and Press . is displayed. Preset compared to the set temperature. The temperature displays brie y, followed ame height is automatically adjusted by the room temperature.
- Page 27 Appendix A - Remote Control Operation Temperature Setting: Off Time Setting (PROGRAM 1) , 1, OFF 1. Press and hold until ashes. are displayed. ALL is ON and set temperature (set in Ther- displayed brie y. Hour ashes. mostatic Mode) is displayed. 2.
- Page 28 Appendix A - Remote Control Operation Low Battery Indication Low Battery Receiver With low battery power in the battery holder, the system shuts o the re completely. (This will not CAUTION: Do not use a screwdriver or other happen if the power is completely interrupted.) metallic object to remove the batteries from the battery holder or the handset.
- Page 29 Appendix A - Remote Control Operation Error Codes In the event of an error condition with the handset or replace, the handset will display an error code. Failure Message on Duration of Symptom Possible Cause Code Handset Display 4 sec •...
- Page 30 Notes...
