9. Align the antenna

To ensure trouble-free programming, the antenna alignment of selected
components is shown below. You can achieve the greatest possible read
range for programming if the SmartCD2.G2 and locking device antennas
are positioned in parallel to one another.
As a general rule, the distance between antennas should be at least 10 cm
to prevent overshooting.
≈ 15-20 cm
≈ 10-15 cm
In this example, all antennas are parallel to one another!
