2025+ (C1) Vivid Coil Ultimate Dh Rc2 (Rs-Vivc-Udh-C1) - RockShox VIVID COIL 2025 Service Manual

2 0 2 5 + ( C 1 ) V i v i d C o i l U l t i m a t e D H R C 2 ( R S - V I V C - U D H - C 1 )
25
26
1. Adjuster - Low Speed Compression (LSC)
2. Adjuster - Hydraulic Bottom Out (HBO)
3. Adjuster - High Speed Compression (HSC)
4. Reservoir can
5. Internal Floating Piston (IFP)
6. Cap - reservoir
7. Schrader valve - reservoir
8. Air cap - IFP Schrader valve
9. Retaining ring - IFP cap
10. Standard eyelet / mount
11. Spring preload adjuster
25
8
26
12. Damper body
13. Coil spring
14. Piston Nut
15. Check piston
16. Bottom post
17. Damper piston assembly
18. Topout plate
19. Sealhead
20. Damper shaft
21. Bottomout bumper
22. Spring clip
1
3
4
5
6
7
9

2025+ (C1) Vivid Coil Ultimate DH RC2 (RS-VIVC-UDH-C1)

10
2
11
12
13
20
21
22
23
24
23. Adjuster - Rebound
24. Standard eyelet / mount
25. Trunnion eyelet / mount
26. Standard eyelet / mount with Bearing Mount
Adapter
14
15
16
17
18
19
11
