- Page 1 USER AND INSTALLATION MANUAL SDV6-CLOUD C O M M E R C I A L A I R C O N D I T I O N E R S S D V 6...
-
Page 2: Table Of Contents
CONTENTS 1 Safety Precautions 1.1 Icon description 2 Operation Instructions 2.1 Gateway Hardware 2.2 Gateway Functions 3 Installation Instructions 3.1 Product Introduction 3.2 Product Dimensions 3.3 Installation Accessories 3.4 Installation Method... -
Page 3: Safety Precautions
1 Safety Precautions The Operation and Installation Manual of this product describes how to properly handle the product, prevent harm to others and prevent property losses, as well as how to use the product correctly and safely. Read the following carefully, make sure you understand the content (symbols and marks), and observe the precautions below. - Page 4 WARNING This unit must be installed by professional technicians. Users are not allowed to install the unit themselves; otherwise, it may cause harm to you or others or damage the controller. Other electrical wiring work must be carried out by a professional technician according to the circuit diagram.
-
Page 5: Operation Instructions
2 Operation Instructions 2.1 Gateway Hardware SDV6-CLOUD Gateway [hereinafter referred to as the "Gateway"] is used together with " CloudService" to upload VRF unit data to the cloud server through the Gateway. The model adapted are SDV6 ODU + 3rd generation IDU or SDV6 ODU + SDV6 IDU. -
Page 6: Gateway Functions
Function When the power supply is working normally, the power supply indicator PWR remains illuminated. Note: When the power supply indicator flashes, the power supply is abnormal. Indicate whether the connection to the cloud server is successful: remains on when CLOUD the connection is successful;... - Page 7 2.2.1.1 Settings The parameters are described as follows: Parameter page Description IP address IP address of the gateway with factory settings 192.168.1.200 Subnet mask with factory settings 255.255.255.0 Mask Network Settings Gateway Default gateway, factory settings 192.168.1.1 DHCP If it is checked, the DHCP function is enabled. This function is disabled on factory settings.
- Page 8 2.2.2 Restore Factory Settings Function Restore Factory Configuration Reserved When the factory configuration is restored, the gateway IP address, and server parameters are set to factory setting values. Steps: 1. Power off the Gateway, press and hold SW1 and turn on the power of Gateway; 2.
-
Page 9: Installation Instructions
3 Installation Instructions 3.1 Product Introduction X Y E A B E DI1 M DI2 3.2 Product Dimensions Unit: mm 51.5 74.5... -
Page 10: Installation Accessories
3.3 Installation Accessories Please check that you have all the following parts. Name Quantity Remarks Self-tapping screw ST4* 20 Plastic expansion pipe For use in installing the controller onto the wall 3 pin black terminal For communication 3 pin gray ter., adapter For connecting the power supp. - Page 11 Plastic expansion pipe Philips head screw ST4*20 (This fixing screw is pre-inserted into the wall and the distance from the highest position of the nut to the wall is 5.5 mm) Drill with a 6 mm drill bit, with a drill depth of no less than 30 mm Philips head screw ST4*20...
- Page 12 United Kingdom www.sinclair-world.com This product was manufactured in China (Made in China). R E P R E S E N T A T I V E SINCLAIR Global Group s.r.o. Purkynova 45 612 00 Brno Czech Republic T E C H N I C A L S U P P O R T SINCLAIR Global Group s.r.o.
