- Page 1 Operating & Maintenance Manual Circulaire® Powder Containment Booth PCB1800 www.monmouthscientific.co.uk...
-
Page 2: Table Of Contents
Contents SECTION 1 ............................3 ............................3 ENERAL NOTES ............... 4 ENERAL AFETY INSTRUCTIONS FOR SERVICE WORK AND REPAIRS ......................5 TANDARDS AND SAFETY REGULATIONS .............................. 6 ARRANTY ............................7 ESCRIPTION ............................8 ECHNICAL ......................9 ORMAL NVIRONMENTAL ONDITIONS SECTION 2 ............................. - Page 3 This cabinet must be used in compliance with these instructions and any repairs or maintenance carried out by qualified personnel. See explanation of hazard symbols at the end of this document. For parts or service information please contact Monmouth Scientific: +44 (0) 1278 458090 https://monmouthscientific.co.uk info@monmouthscientific.co.uk...
-
Page 4: Section 1
SECTION 1 General notes Symbols used in this manual. DANGER Indicate[s] a hazardous situation which, if not avoided, will result in death or serious injury. WARNING Indicate[s] a hazardous situation which, if not avoided, could result in death or serious injury. CAUTION Indicate[s] a hazardous situation which, if not avoided, could result in minor or moderate injury. -
Page 5: General Safety Instructions For Service Work And Repairs
Servicing or repairs to this product must be carried out, only by personnel with the appropriate qualifications and training. They must have been specifically trained and authorised to work on Monmouth Scientific cabinets. Allowing unauthorised personnel to carry out service or repairs will invalidate the product warranty. -
Page 6: Standards And Safety Regulations
Ensure any components such as capacitors etc. are fully de-energized. CAUTION Before any service/ Maintenance work is carried out; Ensure the work area is adequately ventilated. Read any data sheets/ COSHH information about the product used within the cabinet and take appropriate action to illuminate any hazards. -
Page 7: Warranty
Warranty Monmouth Scientific Ltd guarantee the operational safety and functions of the cabinet provided that: The cabinet is not modified or changed without authorization. Only original spare parts or accessories as supplied by Monmouth Scientific are used. Use of non-original parts will invalidate the warranty. -
Page 8: Description
The cabinet is fitted is an audible low airflow alarm, meaning that if the airflow drops below a safe level, it will alert the user with a sound and flashing light. Please contact Monmouth Scientific for further information. Issue C... -
Page 9: Technical Data
Technical Data MODEL NO. PCB-1800 AIRFLOW TOTAL AIRFLOW 1700M /H+/- 5% NOMINAL AIRFLOW VELOCITY (@ PRE-FILTER ADJUSTABLE ≥0.9 m/sec APERTURE) DIMENSIONS EXTERNAL (H X W X D) 2450* X 1800 X 770mm ( * Allow Min +150mm above unit for exhaust airflow) INTERNAL (H X W X D) 1950 X 1700 X 600mm ELECTRICAL... -
Page 10: Normal Environmental Conditions
Normal Environmental Conditions INDOOR OR OUTDOOR USE INDOOR USE TEMPERATURE 5 °C to 40°C RELATIVE HUMIDITY MAX HUMIDITY 80% OVERVOLTAGE CATEGORY OVERVOLTAGE CATEGORY II POLLUTION DEGREE (II) POLLUTION CATEGORY II ALTITUDE UP TO 2000m MAINS SUPPLY VOLTAGE FLUCTUATION 230V -6% +10% Issue C... -
Page 11: Section 2
SECTION 2 Packaged Items 1-OFF POWDER CONTAINMENT BOOTH FACTORY CONFIGURED TO YOUR SPECIFICATION 1-OFF MAINS SUPPLY CABLE 1-OFF CIRCULAIRE FUME FILTRATION CABINET USER MANUAL Installation and assembly The cabinet will be delivered part assembled to aid with transportation on siting. Trained engineers will then fully assemble the unit to ensure it is ready to use. -
Page 12: Installation (General)
Installation (general) The cabinet should be sited in a draught free position. The cabinet is supplied with the main filter fitted. Check the pre-filter is in place by turning the silver knobs, which will allow the pre-filter retaining grille to be lowered. ... -
Page 13: Testing / Commissioning
Testing / Commissioning Certification is provided with each unit. Individual certificates are provided for HEPA filters. The airflow should be checked using a vane anemometer and the results recorded. The main HEPA filter will have been factory tested before delivery. A DOP filter challenge test should be carried out to verify filter integrity when the cabinet is installed. -
Page 14: Section 3
(see section 4 for details). The fan speed control knob is to be used for initial set-up and low airflow monitor calibration only (see section 4 for details). Pre-Filters are available from Monmouth Scientific (see section 4 for details). Issue C... -
Page 15: Filter Replacement
Filter replacement Genuine Monmouth Filters are fitted with a label to indicate the part numbers needed when ordering replacement filters, Details are also given below. Filters concentrate dust, pollutants etc, Care must be taken when changing filters. CAUTION Personal Protective Equipment must be worn when changing filters, including gloves &... -
Page 16: Main Filter Changing
Main filter changing Replacement HEPA Filter Part Number: K-HF0460 (3 off/Cabinet) Using the supplied key, unlock and drop-down the access door. Working inside the enclosure, slacken the 4 off clamp knobs clamping each fan box module to the filter. Work each side in turn to raise the fan box evenly, until a sufficient gap is present to enable the removal of the HEPA filter which should freely slide out of place. -
Page 17: Low Airflow Alarm Calibration
To refit, check there is sufficient gap and engage the new filter into the side guide rails, taking particular care to ensure the seal does not drag on the bottom face. Slide the filter all the way back until it rests against the backstop. Re-tighten the clamp knobs, ensuring an even filter seal when fully tightened. -
Page 18: Section 4
SECTION 4 General Cleaning Surface cleaning and decontamination The powder coated surfaces should be kept clean to preserve the finish by preventing stains. Only soapy water or mild detergents should be used on painted surfaces, abrasive products and harsh chemical cleaners should be avoided. -
Page 19: Replacing The Main Fuse
The high efficiency, low voltage LED light is fitted to the underside of the head. They should provide many years of service without requiring replacement. replacements are available from Monmouth Scientific and have the following part numbers: GS-04377 ELECTRICAL HAZARD Always isolate power before working on any electrical component. -
Page 20: Section 5
Check filter inlet and exhaust outlet air flows. Check general condition of cabinet - fasteners, seals, corrosion etc. Inspect electrical components. Issue test report and airflow certificate. Note any feedback from customer. For parts or service information please contact Monmouth Scientific Issue C... - Page 21 Monmouth Scientific Limited UK Headquarters Monmouth House, Peninsula Business Park, Bridgwater, Somerset, TA6 4QB. +44(0)1278 458090 www.monmouthscientific.co.uk info@monmouthscientific.co.uk B r i t i s h D e s i g n & Manufacture...
