- Page 1 Operating & Maintenance Manual Ductaire TITAN ® Ducted Fume Cupboard DT1000/DT1200/DT1800/DT2000 www.monmouthscientific.co.uk...
- Page 2 SECTION 4: FACE VELOCITY PROFILE RESULTS ........10 This manual is intended to provide information about the product. Monmouth Scientific Limited assumes no liability whatsoever for the accuracy of any information contained herein, as products can be subject to improvement changes at any time.
-
Page 3: Section 1: Operation Of The Cabinet
SECTION 1: OPERATION OF THE CABINET Starting the extract fan The method of starting the extract system may differ depending on the installation and specification. 1. The extract system may have a starter / on/off buttons near the fume cupboard 2. - Page 4 Muting the alarm panel Depending on how your alarm panel is configured, when the extract fan is switched off you may encounter an audible beep and a flashing red light. Press the ENTER button on the alarm panel to mute the alarm, the red light will still flash. Consult the alarm panel user manual for further details Light The light switch is located on the left-hand service panel at the top, press to turn light on and off...
-
Page 5: Section 2: Testing/Maintenance
SECTION 2: TESTING/MAINTENANCE Testing and maintenance schedules should be carried out every 12 – 14 months as a minimum. A risk assessment by the laboratory manager on the type and frequency of work in the fume cupboard may indicate that more periodic testing and maintenance is required. Routine testing ✓... - Page 6 Access to fume cupboard services WARNING Danger of electrical shock Isolate electrical supply before carry out any maintenance. Only qualified personnel may carry out work on these fume cupboards Removal of Access Grille To remove the front access grille, remove the M6 socket head bolts and lift out the access panel This will give you access to the light fitting, electrical junction box and the exhaust take off section.
- Page 7 Warranty 12 months warranty on parts and labour from date of delivery or installation with an extension of up to 5 years Subject to T&C’s Spare Parts Please contact our office for advice on replacement parts. Phone +44(0) 01278 458090 Option 2 +44(0) 01278 458091 Services@monmouthscientific.co.uk...
- Page 8 Internal Wiring Schematic...
-
Page 9: Section 3: Specification Of The Cabinet
SECTION 3: SPECIFICATION OF THE CABINET Ductaire Titan Model: Size: 1 x 1000mm(W) x 2400(H) x 900(D) Chamber: 316g Stainless Steel Work base: 316g Stainless Steel Manufacturer Connection Services: NONE Drainage: NONE Storage: NONE Power: 2 x D.S.S.O. Light: Alarm Type: AFA 1000E VAV alarm panel and controller c/w VAV actuator and damper Extract System None... -
Page 10: Section 4: Face Velocity Profile Results
SECTION 4: FACE VELOCITY PROFILE RESULTS Face Velocity Profile Results Fume Cupboard Type: Ductaire Titan Fume Cupboard Ref: XXXX Fume cupboard width: 1000mm Sash width: 700mm Sash height: 500mm (recommended) Identification of grid point positions. Grid spacing < = 400mm 700mm 100mm 0.00... - Page 11 Monmouth Scientific Limited UK Headquarters Units 5 & 6 Kilnside, East Quay, Bridgwater, Somerset, TA6 4DB. +44(0)1278 458090 www.monmouthscientific.co.uk info@monmouthscientific.co.uk B r i t i s h D e s i g n & Manufacture...
