Pre-Delivery Manual

Read the operator's manual entirely. When you see this symbol, the

subsequent instructions and warnings are serious - follow without

exception. Your life and the lives of others depend on it!

Illustrations may show optional equipment not supplied with standard unit.

ORIGINAL INSTRUCTIONS

Table of Contents

Index

VT1110-20 - VT1110-25

Manufacturing, Inc.

www.greatplainsmfg.com

Printed 2024-03-13

Index

Turbo Max

TP-69605

588-619Q

Table of Contents

Need help?

Do you have a question about the VT1110-20 and is the answer not in the manual?

Questions and answers

Summary of Contents for GREAT PLAINS VT1110-20

Page 1 Table of Contents Index Pre-Delivery Manual VT1110-20 - VT1110-25 Turbo Max Manufacturing, Inc. www.greatplainsmfg.com Read the operator’s manual entirely. When you see this symbol, the subsequent instructions and warnings are serious - follow without exception. Your life and the lives of others depend on it! TP-69605 Illustrations may show optional equipment not supplied with standard unit.
Page 2 VT1110-20 - VT1110-25 Table of Contents Index Great Plains | 588-619Q | 2024-03-13 Table of Contents Index...
Page 3: Vt1110-20 Chopper/Single Reel
Great Plains Manufacturing, Inc. assumes no responsibility for errors or omissions. Neither is any liability assumed for damages resulting from the use of the information contained herein. Great Plains Manufacturing, Inc. reserves the right to revise and improve its products as it sees fit.
Page 4 VT1110-20 - VT1110-25 Table of Contents Index Great Plains | 588-619Q | 2024-03-13 Table of Contents Index...
Page 5  Be prepared if a fire starts  Keep a first aid kit and fire extinguisher handy.  Keep emergency numbers for doctor, ambulance, hospital and fire department near phone. Great Plains | 588-619Q | 03/13/2024 Table of Contents Index...
Page 6: Decals
 Lower implement, put tractor in park, turn off engine, and remove the key.  Secure Turbo Max using blocks and supports provided.  Detach and store Turbo Max in an area where children normally do not play. Great Plains | 588-619Q | 03/13/2024 Table of Contents Index...
Page 7  Wear snug-fitting clothing to avoid entanglement with moving parts.  Watch out for wires, trees, etc., when folding and raising machine. Make sure all persons are clear of working area. Great Plains | 588-619Q | 03/13/2024 Table of Contents Index...
Page 8: Fork Truck
Description of Unit The VT1110-20 - VT1110-25 Turbo Max is a three section “hybrid” tillage tool. Working width ranges from 20 to 25 feet. The implement is designed to cut and size...
Page 9: Definitions
An orientation rose in some line art illustrations shows the directions of: Up, Back, Left, Down, Front, Right. Great Plains | 588-619Q | 03/13/2024 Table of Contents Index...
Page 10: Finishing Attachments
VT1110-20 - VT1110-25 Table of Contents Index Introduction Shipping • Models VT1110-20 - VT1110-25 center frames will be shipped partially pre-assembled. The Turbo Max wings will be shipped un-attached and stacked together. • The attachment frames (if equipped) will be stacked on pallets and banded together.
Page 11 Further Assistance Great Plains Manufacturing, Inc. wants you to be satisfied with your new Turbo Max. If for any reason you do not understand any part of this manual or are otherwise dissatisfies with the product please contact: Great Plains Service Department 1525 E.
Page 12 19. You may install the center fold bracket (8) now using hex bolts (5), lock washers and nuts to secure to the center frame. 20. Bolts may be tightened to specs, See “Torque Values Chart” on page 37. Great Plains | 588-619Q | 03/13/2024 Table of Contents Index...
Page 13 2 Gr. 8 hex   bolts (7), lock washers and nuts. 24. Bolts may be tightened to specs, See “Torque Values Chart” on page 37 and cotter pins bent. Great Plains | 588-619Q | 03/13/2024 Table of Contents Index...
Page 14 If your machine is equipped with weight packs be sure they are installed before the level bar and the torque tube. Only 1 set (2 stacks) of weights are available on models VT1110-20 - VT1110-25. 25. Lower the torque tube (1) onto the center frame using an appropriate hoist or forklift.
Page 15 37. Be sure hoses are routed as shown in, See “Valve Brackets & Hoses” on page 12.  Bolts may be tightened to specs, Bolts may be tightened to specs, See “Torque Values Chart” on page 37. Great Plains | 588-619Q | 03/13/2024 Table of Contents Index...
Page 16 See “Appendix - Reference Information” on page 37 for proper mounting instructions. Great Plains | 588-619Q | 03/13/2024 Table of Contents Index...
Page 17 VT1110-20 - VT1110-25 Table of Contents Index Assembly This page intentionally left blank. Great Plains | 588-619Q | 03/13/2024 Table of Contents Index...
Page 18 45. Secure hydraulic cylinder (20) to front gang bar using clevis pin (16), cotter pin (2), and washer (15) and then to the gang cylinder mount (21) using clevis pin (2), cotter pin (2) and washer (15). Great Plains | 588-619Q | 03/13/2024 Table of Contents Index...
Page 19 VT1110-20 - VT1110-25 Table of Contents Index Assembly 69925 Great Plains | 588-619Q | 03/13/2024 Table of Contents Index...
Page 20 Do not attach the fold cylinder to the wing frame, the hydraulic system will need to be purged of air before trying to fold the wings. If the hydraulic system is not purged of air before the wings are folded they could fall and cause serious injury! 69869 Great Plains | 588-619Q | 03/13/2024 Table of Contents Index...
Page 21 VT1110-20 - VT1110-25 Table of Contents Index Assembly This page intentionally left blank. Great Plains | 588-619Q | 03/13/2024 Table of Contents Index...
Page 22 See “Purging Hydraulic System” on page 25. 55. Bolt may be tightened to specs, See “Torque Values Chart” on page 37 and all cotter pins may be bent. Great Plains | 588-619Q | 03/13/2024 Table of Contents Index...
Page 23 VT1110-20 - VT1110-25 Table of Contents Index Assembly Great Plains | 588-619Q | 03/13/2024 Table of Contents Index...
Page 24: Depth Stop
5. Bolt may be tightened to specs, See “Torque Values Chart” on page 37. 183/4 There are 2 tabs on the gang bar. BE SURE to install the link on the outside face of the outside tab. Great Plains | 588-619Q | 03/13/2024 Table of Contents Index...
Page 25 (12) and 1” top lock nut. The hoses will need to be attached to the bulk head fittings on the center brace bar.  Before adhering the decal to the level gauge bracket, be sure to retract the cylinder all the way, position A lines up with the red indicator. Great Plains | 588-619Q | 03/13/2024 Table of Contents Index...
Page 26 16. Do not hook up rod end of fold cylinder (7) until system is purged of air. See “Purging Hydraulic System” on page 25. 17. Bolt may be tightened to specs, See “Torque Values Chart” on page 37. Great Plains | 588-619Q | 03/13/2024 Table of Contents Index...
Page 27 24. Fasten hoses to wings with bolts and clamps (provided). Attach hose wraps on hoses to prevent hoses from dragging or getting pinched. 25. Also see Hydraulic Layouts in “Appendix Section” for all hose routing. Great Plains | 588-619Q | 03/13/2024 Table of Contents Index...
Page 28: Hose Handles
Hydraulic Hose Hookup 28. Great Plains hydraulic hoses are color coded to help you hookup hoses to your tractor outlets. Hoses that High Pressure Fluid Hazard: go to the same remote valve are marked with the Relieve pressure before disconnecting hydraulic lines.
Page 29  up to wing with the 1 x 3 usable pin (6), 1.5 x 1.0  x.075 machine washer and x 2 cotter pin. Bend cotter pin over to secure. Great Plains | 588-619Q | 03/13/2024 Table of Contents Index...
Page 30 37. Attach gauge link (7) to ear on front of center frame gang bar and gauge bracket assembly (5), secure with    hex bolts (8) and top lock nuts. 38. Bolt may be tightened to specs, See “Torque Values Chart” on page 37. Great Plains | 588-619Q | 03/13/2024 Table of Contents Index...
Page 31: Hydraulic Hoses
45. Install the LH (9) and RH (10) light brackets to center    drag frame (11) with the u-bolts (12),   lock washers and nuts. 46. Tighten all bolts to specs, See “Torque Values Chart” on page 37. Great Plains | 588-619Q | 03/13/2024 Table of Contents Index...
Page 32 (4) that will be mounted on the bulkhead bracket on the front of the brace bar. 49. On the VT1110-20 & 25 the pigtail will also attach to the fold assist harness (5) and the fold assist harness will plug into the bypass valve (6).
Page 33 52. Install one, 848-972C bypass valve operating instruction decal (3) on front of truss (left side) (4). 53. Install two, model number decals (5) on front of brace bar (one each side). Great Plains | 588-619Q | 03/13/2024 Table of Contents...
Page 34  Re-installation instructions are to place left ball joint brackets (6) in proper location from layout drawing and torque u-bolts to 150 ft-lb. Leave right ball joint bracket (7) loose, as it may need move a little while you bolt up the left rolling harrow bracket (3). Great Plains | 588-619Q | 03/13/2024 Table of Contents Index...
Page 35 VT1110-20 - VT1110-25 Table of Contents Index Assembly This page intentionally left blank. Great Plains | 588-619Q | 03/13/2024 Table of Contents Index...
Page 36: Chopper Reel (Optional)
 Please note the direction of travel, if chopper reels are not installed with the indication arrows pointing forward damage may occur. Please see layouts for dimensions and placement, and Part Manual for a complete list of parts. Great Plains | 588-619Q | 03/13/2024 Table of Contents...
Page 37 VT1110-20 - VT1110-25 Table of Contents Index Assembly Arrows on Chopper Wheel Arrows on Chopper Wheel indicate direction of rotation. indicate direction of rotation. Travel Travel Great Plains | 588-619Q | 03/13/2024 Table of Contents Index...
Page 38: Double Hydraulic Reel (Optional)
The top ports of the double tee block will be routed to the rod end of the hydraulic cylinders. For complete hose routing starting with “VT1110-20 Rolling Harrow/Double Reel Layout” on page 48 66. Hook the hydraulic hoses to the cylinders, rod to rod, and base to base.
Page 39 VT1110-20 - VT1110-25 Table of Contents Index Assembly Great Plains | 588-619Q | 03/13/2024 Table of Contents Index...
Page 40  washers and nuts.  76. Torque x 2 Gr. 8 bolts (1) to 375 ft-lbs to be sure bolts do not work loose and cause damage to machine. Great Plains | 588-619Q | 03/13/2024 Table of Contents Index...
Page 41 Rolling Harrow Spike Bolt 1 1/2”-6 650-750 Foot-pounds (175 lbs on 4’ cheater). Wheel Bolt Torque Values 1/2”-20 (75-85ft-lbs) Wheel Bolt Torque Values 9/16”-18 (80-90ft-lbs) Wheel Bolt Torque Values 5/8”-18 (85-100ft-lbs) Great Plains | 588-619Q | 03/13/2024 Table of Contents Index...
Page 42: Inflation
-18 ORB w/jam nut 16-22 12-16  -18 ORB straight 24-33 18-24  -16 JIC 37-53 27-39  -16 ORB w/jam nut 27-41 20-30  -16 ORB straight 37-58 27-43 Great Plains | 588-619Q | 03/13/2024 Table of Contents Index...
Page 43 VT1110-20 - VT1110-25 Table of Contents Index Appendix - Reference Information This page intentionally left blank. Great Plains | 588-619Q | 03/13/2024 Table of Contents Index...
Page 44: Hydraulic Lift
VT1110-20 - VT1110-25 Table of Contents Index Appendix - Reference Information Hydraulic Lift Layout TP-69641 Great Plains | 588-619Q | 03/13/2024 Table of Contents Index...
Page 45 VT1110-20 - VT1110-25 Table of Contents Index Appendix - Reference Information VT1110-20 & 25 Hydraulic Fold Layout TP-69636 Great Plains | 588-619Q | 03/13/2024 Table of Contents Index...
Page 46: Vt1110-20 & 25 Hydraulic Gang Angle
VT1110-20 - VT1110-25 Table of Contents Index Appendix - Reference Information VT1110-20 & 25 Hydraulic Gang Angle Layout TP-69642 Great Plains | 588-619Q | 03/13/2024 Table of Contents Index...
Page 47 VT1110-20 - VT1110-25 Table of Contents Index Appendix - Reference Information VT1110-20 & 25 Reel Hydraulic Layout TP-69644 Great Plains | 588-619Q | 03/13/2024 Table of Contents Index...
Page 48: Vt1110-20 Machine
VT1110-20 - VT1110-25 Table of Contents Index Appendix - Reference Information VT1110-20 Machine Layout TP-77338 Great Plains | 588-619Q | 03/13/2024 Table of Contents Index...
Page 49 VT1110-20 - VT1110-25 Table of Contents Index Appendix - Reference Information VT1110-20 Machine Layout TP-77339 Great Plains | 588-619Q | 03/13/2024 Table of Contents Index...
Page 50 VT1110-20 - VT1110-25 Table of Contents Index Appendix - Reference Information VT1110-25 Machine Layout TP-77340 Great Plains | 588-619Q | 03/13/2024 Table of Contents Index...
Page 51 VT1110-20 - VT1110-25 Table of Contents Index Appendix - Reference Information VT1110-25 Machine Layout TP-77341 Great Plains | 588-619Q | 03/13/2024 Table of Contents Index...
Page 52 VT1110-20 - VT1110-25 Table of Contents Index Appendix - Reference Information VT1110-20 Rolling Harrow/Double Reel Layout Round Bar Double Reel Arm & Reel Assembly TP-77315 Locations will be the same as shown on each model layout. Great Plains | 588-619Q | 03/13/2024...
Page 53 VT1110-20 - VT1110-25 Table of Contents Index Appendix - Reference Information VT1110-20 Rolling Harrow/Double Reel Layout Round Bar Double Reel Arm & Reel Assembly TP-77316 Locations will be the same as shown on each model layout. Great Plains | 588-619Q | 03/13/2024...
Page 54: Vt1110-25 Rolling Harrow/Double
Index Appendix - Reference Information VT1110-25 Rolling Harrow/Double Reel Layout TP-77335 Round Bar Double Reel Arm & Reel Assembly Locations will be the same as shown on each model layout. Great Plains | 588-619Q | 03/13/2024 Table of Contents Index...
Page 55 Index Appendix - Reference Information VT1110-25 Rolling Harrow/Double Reel Layout TP-77336 Round Bar Double Reel Arm & Reel Assembly Locations will be the same as shown on each model layout. Great Plains | 588-619Q | 03/13/2024 Table of Contents Index...
Page 56 Table of Contents Index Appendix - Reference Information VT1110-20 Chopper/Single Reel Layout TP-77363 Flat Bar Reel Arm & Reel Assembly Locations will be the same as shown on each model layout. Great Plains | 588-619Q | 03/13/2024 Table of Contents Index...
Page 57 Table of Contents Index Appendix - Reference Information VT1110-20 Chopper/Single Reel Layout TP-77364 Flat Bar Reel Arm & Reel Assembly Locations will be the same as shown on each model layout. Great Plains | 588-619Q | 03/13/2024 Table of Contents Index...
Page 58 Table of Contents Index Appendix - Reference Information VT1110-25 Chopper/Single Reel Layout TP-77365 Flat Bar Reel Arm & Reel Assembly Locations will be the same as shown on each model layout. Great Plains | 588-619Q | 03/13/2024 Table of Contents Index...
Page 59 Table of Contents Index Appendix - Reference Information VT1110-25 Chopper/Single Reel Layout TP-77366 Flat Bar Reel Arm & Reel Assembly Locations will be the same as shown on each model layout. Great Plains | 588-619Q | 03/13/2024 Table of Contents Index...
Page 60 VT1110-20 - VT1110-25 Table of Contents Index Appendix - Reference Information Great Plains | 588-619Q | 03/13/2024 Table of Contents Index...
Page 61: Table Of Contents
......... 20 VT1110-20 Rolling Harrow/Double tires ............3 Reel ......48 torque value chart .......37 banding ..........7 VT1110-20 & 25 Hydraulic Fold .. 41 torque values chart (wheel bolts)..37 VT1110-20 & 25 Hydraulic Gang trailer bed..........7 CAUTION, defined .......1 Angle ......42 truck driver ..........7...
Page 62 VT1110-20 - VT1110-25 Table of Contents Index Great Plains | 588-619Q | 2024-03-13 Table of Contents Index...
Page 63 Table of Contents Index Table of Contents Index...
Page 64 Table of Contents Index Great Plains, Mfg. 1525 E. North St. P.O. 5060 Salina, KS 67402...
