GREAT PLAINS VT1110 Manual

Implement command system
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Implement Command
Read the operator's manual entirely. When you see this symbol, the
subsequent instructions and warnings are serious - follow without
exception. Your life and the lives of others depend on it!
Illustrations may show optional equipment not supplied with standard unit.
ORIGINAL INSTRUCTIONS
© Copyright 2024
System Manual
VT1110 & HT1110-6.0 & 7.5M
Narrow Turbo Max & Terra Max
Manufacturing, Inc.
www.greatplainsmfg.com
Printed 2024-12-19
EN
588-645M

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VT1110 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for GREAT PLAINS VT1110

Summary of Contents for GREAT PLAINS VT1110

  • Page 1 Implement Command System Manual VT1110 & HT1110-6.0 & 7.5M Narrow Turbo Max & Terra Max Manufacturing, Inc. www.greatplainsmfg.com Read the operator’s manual entirely. When you see this symbol, the subsequent instructions and warnings are serious - follow without exception. Your life and the lives of others depend on it! Illustrations may show optional equipment not supplied with standard unit.

  • Page 2: Machine Identification

    Implement Command System, VT1110/HT1110-6.0 & 7.5M Narrow Machine Identification Record your machine details in the log below. If you replace this manual, be sure to transfer this information to the new manual. If you, or the dealer, have added Options not originally ordered with the machine, or removed Options that were originally ordered, the weights and measurements are no longer accurate for your machine.

  • Page 3: Important Safety Information

    Important Safety Information Important Safety Information Look for Safety Symbol The SAFETY ALERT SYMBOL indicates there is a potential hazard to personal safety involved and extra safety precaution must be taken. When you see this symbol, be alert and carefully read the message that follows it.

  • Page 4: Be Familiar With Safety Decals

    Implement Command System, VT1110/HT1110-6.0 & 7.5M Narrow Be Familiar with Safety Decals  Read and understand the “Safety Decals” section of the Operators Manual.  Read all instructions noted on the decals.  Keep decals clean. Replace damaged, faded and illegible decals.

  • Page 5: Shutdown And Storage

    Important Safety Information Shutdown and Storage  Lower implement, put tractor in park, turn off engine, and remove the key.  Secure Hydraulic Reel Attachment using blocks and supports provided.  Detach and store Hydraulic Reel Attachment in an area where children normally do not play.

  • Page 6: Description Of Unit

    Implement Command System, VT1110/HT1110-6.0 & 7.5M Narrow Introduction The Implement Command System has been designed with care and built by skilled workers using quality materials. Proper setup, maintenance, safe operating practices will help the customer get years of satisfactory use from this system.
  • Page 7 Assembly Assembly Implement Command System  NOTE: For parts reference refer to parts breakdown on page 16 to page 23 of this manual. For in-field conversions to ICS, also refer to the most recent parts manual for comparison between existing and new ICS layouts.
  • Page 8 Implement Command System, VT1110/HT1110-6.0 & 7.5M Narrow Refer to Figure 5 The cylinder that is located on the hitch will be connected to the FAS1wire on the harness. The harness will run under the cylinder, thru the “ears” that connect to the H-bracket and towards the center frame.
  • Page 9 Assembly Refer to Figure 7 The Down Pressure Valve (1) (for the wing down pressure) is plugged into DPT1, DPT3, and DPC1, on the frame harness. The Down Pressure Valve (2) (for the finisher down pressure) is plugged into Finisher DPT1, Finisher DPT3, Finisher and DPC1, on the frame harness.
  • Page 10 Implement Command System, VT1110/HT1110-6.0 & 7.5M Narrow Refer to Figure 8 The Splitter Valve is attached on the right hand side of the center brace bar. The Splitter valve is attached to SVC1 and SVC2 on the center frame harness.
  • Page 11 Assembly Refer to Figure 10 The wiring will follow the hydraulic hoses that are hooked to the torque tube cylinder secured with p-clamps. After all the connections are made, extra wire can be bundled up and secured together with a zip tie to keep from getting damaged.

  • Page 12: Operation

    Implement Command System, VT1110/HT1110-6.0 & 7.5M Narrow Operation Implement Command System Refer to Figure 13 This system allows you to monitor and adjust Hydraulic Down Pressure on the wings and finisher and Working Depth from an ISOBUS Virtual Terminal. You can also monitor Gang Angle, Fore & Aft leveling, these must be adjusted by using the hydraulic lever in the tractor.
  • Page 13 Operation Highlighten Area Actual Decrease Is Target Depth Depth Depth Depth Control Feature Increase Presets Depth Manual Depth Control Button Figure 14 TP-69755a Depth Control Depth Control Refer to Figure 14  The manual depth stop needs to be turned all the way out for the ICS System to work correctly.
  • Page 14 Implement Command System, VT1110/HT1110-6.0 & 7.5M Narrow Fore/Aft Position Gauge Finisher Pressure Gauge Fore/Aft Gang Angle Lock Gauge Figure 15 TP-69755b Reel Position, Fore/Aft, Gang Angle  The Fore/Aft Leveling and the Gang Angle are on the Gang Angle same hydraulic circuit, to change from one to the...
  • Page 15 Operation Increase Pressure Wing Down Decrease Pressure Pressure Figure 16 TP-69755c 5-Section Screen - Down Pressure Hydraulic Down Pressure (wings) 3-Section Wings Refer to Figure 16 On a 3 section machine if you want to run 0 down pressure you just set the fold hydraulic circuit detent into The down pressure is active and can be increased or the float position allowing the wings to move while not decreased, on the go through the field.

  • Page 16: Manual Override

    Implement Command System, VT1110/HT1110-6.0 & 7.5M Narrow Manual override Depth control valve Refer to Figure 17 Push knurled button in and turn ¼ turn on coil DCC1, this will cause the button to pop out and then you can adjust your depth with the manual depth valve.
  • Page 17 Operation Finisher Reel – upper valve Refer to Figure 19 To override the finisher down pressure valve you need to adjust the 3/16” alen screw in, Engage SCV then start to dial up the pressure, watch gauges *DO NOT* exceed 900psi, frame damage could occur.
  • Page 18 Implement Command System, VT1110/HT1110-6.0 & 7.5M Narrow HT/VT1110 ICS System Parts TP-77337 Great Plains | 588-645M...
  • Page 19 Operation HT/VT1110 ICS System Parts List dwgTP-77337 Image No. 843-222C DOWN PRESSURE VALVE 1 CIRCUIT 843-226C DEPTH CONTROL VALVE 843-225C SPLITTER VALVE 599-169S GPAC CONTROLLER ASSY - HT1110 599-168S HT1110 DEPTH CTRL SENSOR ASSY Inludes items 11, 19, 20 & 30-34 589-727S ADJUSTABLE LINK 4.25"...
  • Page 20 Implement Command System, VT1110/HT1110-6.0 & 7.5M Narrow HT/VT1110 ICS System Hydraulics TP-77262 Great Plains | 588-645M...
  • Page 21 Operation HT/VT1110 ICS System Hydraulics Parts List 12/19/2024...
  • Page 22 Implement Command System, VT1110/HT1110-6.0 & 7.5M Narrow HT/VT1110 ICS Fold System TP-77273 Great Plains | 588-645M...
  • Page 23 Operation HT/VT1110 ICS Fold System Parts List 12/19/2024...
  • Page 24 Implement Command System, VT1110/HT1110-6.0 & 7.5M Narrow HT/VT1110 ICS Lift System TP-77269 Great Plains | 588-645M...
  • Page 25 Operation HT/VT1110 ICS Lift System Parts List dwgTP-77269 Image No. 1 811-913C HG HANDLE - BLACK RET 2 811-826C HG HANDLE - BLACK EXT 3 811-919C AD 3/4MORB 3/4FORB (HG) 4 548-001S HG PAIR - BLACK MORB-FORB Includes items 1-3...
  • Page 26 Implement Command System, VT1110/HT1110-6.0 & 7.5M Narrow Implement Command Hitch/Gang Hydraulic Layout Ht/VT1110-6.0 & 7.5M TP-69742 Great Plains | 588-645M...
  • Page 27 Operation Implement Command Hydraulic Fold Layout HT/VT1110-6.0 & 7.5M TP-77641 12/19/2024...
  • Page 28 Implement Command System, VT1110/HT1110-6.0 & 7.5M Narrow Implement Command Hydraulic Lift Layout HT/VT1110-6.0 & 7.5M TP-69967 Great Plains | 588-645M...
  • Page 29 Operation Implement Command Hydraulic Lift Layout HT/VT1110-6.0 & 7.5M TP-69968 There is a cradle on the underside of the brace bar, some hoses run thru this to keep them from getting damaged. 12/19/2024...
  • Page 30 Implement Command System, VT1110/HT1110-6.0 & 7.5M Narrow Implement Command Hydraulic Finisher Layout HT/VT1110-20 & 25 TP-69741 Great Plains | 588-645M...
  • Page 31 Operation Wiring Connections Layout TP-69738 12/19/2024...
  • Page 32 Implement Command System, VT1110/HT1110-6.0 & 7.5M Narrow Great Plains | 588-645M...
  • Page 34 Great Plains, Mfg. 1525 E. North St. P.O. 5060 Salina, KS 67402 MADE IN USA WITH U.S. & GLOBAL COMPONENTS...

This manual is also suitable for:

Ht1110-6.0Ht1110-7.5m
