Gigamon GigaVUE TA Series Hardware Installation Manual

Hide thumbs Also See for GigaVUE TA Series:

Hardware installation manual (115 pages)

Installation manual (91 pages)

Hardware installation manual (102 pages)

page of 74

/ 74
Bookmarks

Quick Links

Download this manual

GigaVUE-TA25

Hardware

Installation Guide

GigaVUE TA Series

Product Version: 6.7

Document Version: 1.0

Last Updated: Tuesday, June 11, 2024

(See Change Notes for document updates.)

Need help?

Do you have a question about the GigaVUE TA Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Gigamon GigaVUE TA Series

Page 1 GigaVUE-TA25 Hardware Installation Guide GigaVUE TA Series Product Version: 6.7 Document Version: 1.0 Last Updated: Tuesday, June 11, 2024 (See Change Notes for document updates.)
Page 2 Gigamon Inc. Trademark Attributions Gigamon and the Gigamon logo are trademarks of Gigamon in the United States and/or other countries. Gigamon trademarks can be found at www.gigamon.com/legal- trademarks.
Page 3 GigaVUE-TA25 Hardware Installation Guide Change Notes When a document is updated, the document version number on the cover page will indicate a new version and will provide a link to this Change Notes table, which will describe the updates. Product Version Document Version Date Change...
Page 4 GigaVUE-TA25 Rules and Notes Breakout Modes Configure the Port Mode Breakout Panels Getting Unpacked, Racked, Installed and Connected Unpacking the GigaVUE TA Series Traffic Aggregator Rack-Mounting the GigaVUE TA Series Two-Post Rack Methods: Four-Post Rack Methods: Basic Connections and Configuration...
Page 5 SSH2 Advantages of SSH2 Changing Host Keys Initial User Account Configuration Configuring the GigaVUE TA Series Host Name Configuring GigaVUE TA Series Node’s Time Options Setting Time Manually Performing One-Time NTP Server Synchronization Using NTP Time Server for System Clock Synchronization...
Page 6 Bonding of Battery Return (BR) Input Terminals Connections Input AC/DC Voltage Commercial Power Ports Maintenance Maintenance Additional Sources of Information Documentation How to Download Software and Release Notes from My Gigamon Documentation Feedback Contact Technical Support Contact Sales Premium Support The VÜE Community Glossary Contents...
Page 7 GigaVUE TA Series Overview GigaVUE TA Series nodes allow you to aggregate the traffic from multiple low-utilization links before sending the traffic to the GigaVUE HC Series nodes that form your Gigamon Deep Observability Pipeline. : The GigaVUE TA Series support network, tool, clustering, and stack port MPORTANT connections to other GigaVUE TA Series nodes, including GigaVUE HC Series nodes.
Page 8 GigaVUE-TA25 Hardware Installation Guide GigaVUE TA Series Nodes GigaVUE TA Series includes the following models: GigaVUE-TA25 1 RU Footprint ■ 48 25Gb/10Gb/1Gb ports ■ and 8 100Gb/40Gb ports, dual hot- pluggable power supplies (AC/DC), four rear hot swappable fan modules, two console...
Page 9 GigaVUE TA Series nodes allow you to aggregate traffic from multiple network links from 1Gb up to 100Gb. The GigaVUE TA Series can pre-filter traffic for monitoring or be integrated into the GigaVUE HC Series cluster for end-to-end Flow Mapping® and management.
Page 10 Optional patch panel or breakout panel allows use of 40Gb ports as four individual ■ 10Gb ports on all the GigaVUE TA Series nodes, or 100Gb ports as four individual 25Gb ports on GigaVUE-TA200, GigaVUE-TA200E, GigaVUE-TA25, GigaVUE-TA25E. All ports of same type and speed can be used to create GigaStream.
Page 11 Benefit Descriptions eight (8) 100Gb/40Gb ports enabled. The GigaVUE TA Series nodes make it easy to leverage the system’s 10Gb or 40Gb port density, aggregating multiple underused 40Gb/10Gb/1Gb network ports to 40Gb/10Gb tool ports for uplink to the Gigamon Deep Observability Pipeline.
Page 12 The c1 and c5 ports accept QSFP28/QSFP+ connections using 100G/40G SR and PLR4 transceivers. This button on the front panel next to Gigamon logo allows you to reset Reset Button GigaVUE-TA25 without having to unplug both PSU’s. Push and hold the button for 5 seconds to reset.
Page 13 GigaVUE-TA25 Hardware Installation Guide Chassis Cooling The fans on the GigaVUE-TA25 run at 100% of their maximum speed on power up, then drop to approximately 60% during normal operations. The temperatures of four components: transceivers, exhaust, CPU, and switch CPU, are monitored. When a component crosses a pre-defined threshold, the fan speed is adjusted dynamically, in increments of approximately 10%. An SNMP trap is sent when a component reaches the threshold for warning or critical temperature conditions.
Page 14 Egress Vlan Tag: none none Buffer Index: default default Discovery: off off GDP: disable disable SFP present: yes yes SFP type: qsfp+ sr qsfp28 sr SFP vendor name: GIGAMON QSF-502 GIGAMON Q28-502 SFP vendor PN: GMONQ85S-NGM GMONC85S-NGM SFP vendor SN: INGBT8030260 INGBL5673819 SFP Power (1-2) (dBm): -3.66 -3.63 0.05 -0.69 SFP Power (3-4) (dBm): -40.00 -40.00 0.02 -0.48 SFP Power (5-6) (dBm): - - - - SFP Power (7-8) (dBm): - - - - SFP Power (9-10)(dBm): - - - -...
Page 15 GigaVUE-TA25 Hardware Installation Guide Solid GREEN indicates that the power supply unit (PSU) is connected to switch and ■ is operating normally. Solid AMBER indicates that the PSU has failed. ■ Blinking AMBER indicates that the PSU has been removed. ■ Off indicates that the PSU is disconnected.
Page 16 GigaVUE-TA25 Hardware Installation Guide : When Copper Cable is connected the following LED status can be noticed; - The Link light turns GREEN when the port is enabled administratively and turns OFF when disabled administratively. PSU LED The individual power LED on the rear of the chassis are as follows: GREEN indicates the PSU is operating normally and is receiving good AC input.
Page 17 GigaVUE-TA25 Hardware Installation Guide AC and DC Powered GigaVUE TA25 Models Gigamon provides both AC and DC-powered versions of the GigaVUE-TA25. Refer to Connecting -48V DC Power Supplies. Battery Caution A disposable, non-rechargeable, Real Time Clock (RTC) Lithium metal coin cell battery is in the GigaVUE-TA25.
Page 18 VPort. Utilizing Fabric Maps. ● Breakout Modes The breakout modes for GigaVUE TA Series can be in port mode. GigaVUE-TA25, GigaVUE-TA25E, GigaVUE-TA100, GigaVUE-TA200, GigaVUE-TA200E and GigaVUE-TA400 allows port breakout mode. Refer to Configure the Port Mode for further details.
Page 19 GigaVUE-TA25 Hardware Installation Guide Any of the 100Gb ports on the GigaVUE-TA100 (1/1/c1 to 1/1/c32), the first 32 ports on the GigaVUE-TA200 and GigaVUE-TA200E (1/1/c1 to 1/1/c32), the eight ports on GigaVUE-TA25 ( 1/1/c1..1/1/c8) or any ports in GigaVUE-TA400 can operate at 40Gb with QSFP+ SR transceivers.
Page 20 GigaVUE-TA25 Hardware Installation Guide Breakout Panels Breakout panels let you connect ports on a GigaVUE TA Series node to a tool or network port or TAP for port breakout or aggregation. The following breakout panels are available: PNL-M341/PNL-M341T ■ PNL-M343/PNL-M343T ■...
Page 21 Position) in either a two-post or four-post rack. Two-Post Rack Methods: Most GigaVUE TA Series Traffic Aggregation nodes can either be front mounted or rear mounted using the rack ears as shown below. GigaVUE-TA200, GigaVUE-TA25 and GigaVUE-TA400 can only be front mounted.
Page 22 Figure 1 GigaVUE TA Series Traffic Aggregator Rack Ears in Front-Mount Position To mount the GigaVUE TA Series Traffic Aggregation node in a rack: Attach the orange rack ears to the front or rear of the unit (rear mounting does not apply to GigaVUE-TA200, GigaVUE-TA25 and GigaVUE-TA400) using the supplied screws.
Page 23 GigaVUE-TA25 Hardware Installation Guide Four-Post Rack Methods: GigaVUE TA Series Traffic Aggregation nodes also come with a pair of full length mounting rails. These rails can be used for four point mounting on four-post racks. The keyhole rivets on the sides of each node can be used to adjust the fit of the node to the desired position or dimension on the rack.
Page 24 GigaVUE-TA25 Hardware Installation Guide Figure 3 Front View of the Mounted Node to the Four-Post Rack 2. Slide in the provided rails on to the node. The position of the rails can be adjusted to fit the dimensions of the rack by sliding over the rivets and placing them securely over the rivets once set in the desired position.
Page 25 GigaVUE-TA25 Hardware Installation Guide Figure 4 Rear View of the Mounted Node and Rails on the Four-Post Rack 3. Last, tighten the rails to the rear posts using the supplied screws. Basic Connections and Configuration This chapter describes how to establish your first configuration session with the GigaVUE TA Series Traffic Aggregator and set the basic initial configuration options necessary to get you up and running.
Page 26 GigaVUE-TA25 Hardware Installation Guide Grounding the GigaVUE TA Series Chassis Locate the grounding holes at the rear of the chassis. Refer to Grounding the GigaVUE TA Series Chassis Figure 6 Ground Screws (GigaVUE TA Series-Shown). Figure 5 Ground Screws (GigaVUE TA Series Shown)
Page 27 GigaVUE-TA400 as shown in Figure 7 Connecting AC Power Figure 9 Connecting AC Power on a GigaVUE TA Series- TA200. NOTE: For information on connecting the optional DC power supplies, Refer to Connecting -48V DC Power Supplies.
Page 28 GigaVUE TA Series command-line interface (CLI). Connecting -48V DC Power Supplies The GigaVUE TA Series Traffic Aggregator is available with two DC power supplies instead of the standard AC power supply. This section provides instructions for connecting a -48V DC power source to the DC power supplies.
Page 29 Connect the -48V source wire to the -48V (blue) terminal using a straight blade screwdriver. : The leads to the DC power supply modules on the GigaVUE TA Series MPORTANT node should attach from the side of the chassis away from the terminal block. Run the wires to avoid obstructing airflow for the adjacent fans.
Page 30 Cautions for Power and Ground connections Caution : Class I Equipment. The GigaVUE TA Series equipment must be earthed. The power plug must be connected to a properly wired earth ground socket outlet. An improperly wired socket outlet could place hazardous voltages on accessible metal parts.
Page 31 GigaVUE-TA25 Hardware Installation Guide Caution: When installing DC Power to GigaVUE-TA400, a Skilled Person is needed to connect the Power. Cable Suggestion to use VW-1, 600V, 105 degree C, tightening torque : 13.88/1.57 (lb- in/N.m), Wire Range : 8-18AWG, Wire Type: CU's power cable(wire). Caution : The output of certified DC source must be grounded.
Page 32 Attention : La sortie de la source DC certifiée doit être mise à la terre Warning: Fiber Optic Port Safety GigaVUE TA Series nodes are intend to installed in an UL certified Optical Transceiver Module,Laser Class1. When using a fiber optic port, never look at the transmit laser while itis powered on.
Page 33 Connecting Serial Console and Mgmt Ports To make basic connections (serial console and Mgmt ports): Locate the DB9-to-RJ45 serial cable provided with the GigaVUE TA Series-TA400 node. This cable is called a console cable. : This cable is Cisco-compatible. Refer to B Console Port Signaling and Cabling for pinout details.
Page 34 Port. Once you have used the console port to configure the Mgmt port’s network properties, you can configure the GigaVUE TA Series node remotely using the Mgmt port’s network connection. : The same commands are available in the command-line interface regardless of how you connect.
Page 35 GigaVUE-TA25 Hardware Installation Guide Data bits – 8 Parity – None Stop bits – 1 Flow control – None : The GigaVUE-TA100, GigaVUE-TA200 and GigaVUE-TA25 support only a fixed serial baud rate of 115,200bps. Figure 13 Setting COM Port Properties for the Console Connection 5.
Page 36 GigaVUE-TA25 Hardware Installation Guide Run the Jump-Start Script Gigamon provides the GigaVUE TA Series nodes with a jump-start script that walks you through the process of configuring basic settings. Run this script as follows: Switch to Config mode. There are three command entry modes, each with increasingly powerful rights –...
Page 37 Enable cluster support if this node will be a part of a cluster Cluster Enable? of connected GigaVUE TA Series nodes. If you enable cluster support, the jump-start script prompts you to supply the Cluster ID, Cluster Name, and Cluster Mgmt Virtual IP Address.
Page 38 Changing the admin Account Password. Refer to Completing the Initial Setup for a quick summary of the available GigaVUE TA Series commands for GigaVUE TA Series nodes. Port Licensing GigaVUE-TA25 have all ports enabled. Additional ports are available through licenses for GigaVUE-TA25A Contact your Sales representative for port licenses.
Page 39 5. Save your changes so that ports come up automatically at the next reboot: write memory Advanced Features Licensing GigaVUE-TA400 nodes can be clustered with GigaVUE TA Series and GigaVUE HC Series nodes. Clustering is enabled with an Advanced Features License. Contact your Sales representative for Advanced Features Licenses. Refer to Contacting Sales.
Page 40 GigaVUE-OS Command-Line Modes. : If you are working simultaneously with multiple GigaVUE TA Series nodes, you may want to assign each a separate hostname so its easy to identify separate terminal sessions from the system prompt. Admin users can do this in Configure mode with the hostname <name>...
Page 41 GigaVUE-TA25 Hardware Installation Guide Entering Commands in the CLI The GigaVUE TA Series CLI provides several conventions that make it easy to identify available commands and enter them quickly: Technique Description Context-Sensitive The ? symbol is the key to receiving help wherever you...
Page 42 Config Mode Syntax When using the GigaVUE TA Series CLI, the “config” part of the command is implied whenever you are working in Configure mode. The system prompt helps you remember this by including the word (config) in parentheses. For example:...
Page 43 Configure bonded interface settings. boot Configure system boot parameters. card Configure a card. On TA Series nodes, use the card command to enable additional ports on GigaVUE TA Series nodes. chassis Configure the chassis. clear Reset statistics or clear caches.
Page 44 Upgrades the BIOS image on GigaVUE-TA100, GigaVUE-HC1, GigaVUE-HC3 and GigaVUE-TA25. crypto Manage X.509 certificates for the node’s Web server. debug Generate a dump file for use in debugging issues with Gigamon Technical Support. disable Leave Enable mode and return to Standard mode. email Configure email and event notification via email.
Page 45 GigaVUE-TA25 Hardware Installation Guide Command Description ntpdate Set system clock once from a remote server using NTP. ping Send ICMP echo requests to a specified host. ping6 Send ICMPv6 echo requests to a specified host. policy Configures an active visibility policy. port Configure port type, parameters, and filters.
Page 46 Enable to Configure. SSH2 SSH2 is available for remote connections to the GigaVUE TA Series Traffic Aggregator’s Mgmt port. By default, SSH2 is enabled. Use the ssh commands in Configure mode to enable or disable the corresponding connections. To disable the corresponding connection, you include no before the command, as demonstrated in the table below.
Page 47 (SSH2 supports both RSA and DSA encryption algorithms). The first time you connect to the GigaVUE TA Series node with an SSH2 client, the client will warn you that the host keys are not in your local cache and show you the actual host key presented by the node.
Page 48 Enter a new password that meets the standards and confirm the password. Setting Up Some Basic Accounts 1. The GigaVUE TA Series node has a local account database that can optionally integrate with an LDAP, RADIUS, or TACACS+ server for authentication. Any account you want to authenticate using an external AAA server must have a matching account name in the local database.
Page 49 Figure 16 Reviewing the User List Configuring the GigaVUE TA Series Host Name It is generally a good idea to configure the GigaVUE TA Series node’s name, date, and time as part of your initial configuration. The following command shows how to set the system name.
Page 50 Enable use of ntp with ntp enable command. Setting Time Manually The easiest way to set the GigaVUE TA Series node’s time is manually with the clock set command. For example: (config) # clock set 05:18:38 2011/05/24 : Even if you are using NTP/SNTP, It is a good idea to configure time manually as well.
Page 51 You specify the timezone in terms of the offset from UTC (either plus or minus). For example, to set the timezone for a GigaVUE TA Series node in the United States for Pacific Standard Timezone, you would use the following command: (config) # clock timezone America North United_States Pacific Once you’ve finished configuring NTP options, use the show ntp command to...
Page 52 GigaVUE-TA25 Hardware Installation Guide system prompt, you are in Configure mode. If not, use the enable and configure terminal commands sequentially to change to Configure mode. Then, configure email notifications as follows: Description Command First, use the email (config) # email mailhub smtp.emailsrvr.com mailhub command to specify the mail server to use for notification emails.
Page 53 There are many other options for fine-tuning automatic email settings, including how to handle “dead letters” (emails that did not reach their recipient), how the email address of the GigaVUE TA Series should appear, the port for the email server, the reply- to address, and so on.
Page 54 (config) # banner login "Pacific Call Center" : You only need to use quotation marks for the <string> if it includes spaces. The next time you log in or out of the GigaVUE TA Series node, you will see the customizable banner.
Page 55 Duplex BiDi optics must be used for the tool port. The network port may be either Full Duplex or RX-only BiDi optics. When stacking multiple GigaVUE TA Series nodes, 40Gb BiDi optics must not be ■ used on stack links because the 40Gb BiDi technology is not compatible with the Gigamon stack protocol.
Page 56 For details about the supported transceiver, cable type, and connectivity ■ specifications, refer to “GigaVUE-OS Compatibility and Interoperability Matrix”. For details about how to cable GigaVUE TA Series nodes, refer to “GigaVUE- ■ OS Pluggables Guide”. MPO/MTP 12 Position Fiber Cable for Use with SR4 Transceivers This is a female to female Multi-fiber Push On (MPO) / Ultra Polished Connector (UPC) of cable type B.
Page 57 ® TA Series Specifications This section provides the physical specifications, power requirements and environmental specifications for the GigaVUE TA Series Traffic Aggregation node. Compliance for safety, emissions and immunity are also provided. Physical Dimensions and Weight The following table summarizes the dimensions for the GigaVUE TA Series Traffic...
Page 58 Including latches without ears 19.25in (48.89cm) Power Requirements Each GigaVUE TA Series node come standard with dual, load sharing power supplies. Table 2: Power Requirements for GigaVUE-TA25 summarize the electrical characteristics for the GigaVUE TA Series Traffic Aggregation node, GigaVUE-TA25.
Page 59 -4ºF to 158ºF (-20ºC to 70ºC) Recommended Storage Relative 15% to 85%, non-condensing Humidity Altitude Up to 16405ft (5.00km) for , GigaVUE-TA25 Compliance This section provides compliance information for GigaVUE TA Series Traffic Aggregation nodes. Safety Emissions Immunity Environmental Security BSMI RoHS...
Page 60 ■ BSMI (GigaVUE-TA100,GigaVUE-TA200 and GigaVUE-TA400) ■ CCC, EAC (GigaVUE-TA100,GigaVUE-TA200 and GigaVUE-TA400) ■ Emissions GigaVUE TA Series Traffic Aggregation nodes are compliant with the following emissions regulations: FCC Part 15, Class A ■ VCCI Class A. Refer to VCCI. ■ EN 55032/CISPR 32 Class A ■...
Page 61 NEBS Level 3 (GigaVUE-TA100). Refer to NEBS Level 3 Compliance. ■ Security GigaVUE TA Series Traffic Aggregation nodes are compliant with the following security certifications: FIPS 140-2 (GigaVUE-TA100). Refer to “FIPS 140-2 Compliance” in the GigaVUE-OS ■ CLI User's Guide.
Page 62 Interference by Information Technology Equipment (VCCI). If this equipment is used in a domestic environment, radio disturbance may occur, in which case, the user may be required to take corrective action. Warranty Gigamon offers a range of premium support and extended services. For details regarding warranty, visit: https://www.gigamon.com/support/warranty. Contents...
Page 63 GigaVUE-TA25 Hardware Installation Guide Regulatory Label NEBS Level 3 Compliance This appendix provides installation instructions for GigaVUE-TA25,GigaVUE-TA25E, GigaVUE-TA100, and GigaVUE-TA200 Network Equipment-Building System (NEBS) Level 3 compliance. Installation Instructions The following sections detail installation instructions for GigaVUE-TA25, GigaVUE-TA25E, GigaVUE-TA100, and GigaVUE-TA200. Topics: Intrabuilding or Intra-connection for GigaVUE- TA25...
Page 64 GigaVUE-TA25 Hardware Installation Guide GigaVUE TA25 equipment or subassembly are suitable for connection to intrabuilding or unexposed wiring or cabling only. The intra-building port(s) of the equipment or subassembly MUST NOT be metallically connected to interfaces that connect to the OSP or its wiring.
Page 65 GigaVUE-TA25 Hardware Installation Guide Connections a. The GigaVUE-TA100, GigaVUE-TA200 and GigaVUE-TA25 shall be grounded via a copper ground conductor #6 AWG for CPE installation. b. All bare grounding connection points to the GigaVUE-TA100, GigaVUE-TA200 or GigaVUE-TA25 shall be cleaned and coated with an antioxidant solution before connections are made.
Page 66 GigaVUE-TA25 Hardware Installation Guide Commercial Power Ports The manufacturer recommends that Surge Protection Device (SPD) is intended to be used with AC-power equipment. The SPD, if used, is installed at the AC power entrance (Refer to definition in the NEC). Maintenance CAUTION: Remove all power sources before servicing.
Page 67 ■ Documentation This table lists all the guides provided for GigaVUE TA Series software and hardware. The first row provides an All-Documents Zip file that contains all the guides in the set for the release. : In the online documentation, view...
Page 68 GigaVUE-TA25 Hardware Installation Guide GigaVUE TA Series 6.7 Hardware and Software Guides GigaVUE-TA200E Hardware Installation Guide GigaVUE-TA400 Hardware Installation Guide GigaVUE-OS Installation Guide for DELL S4112F-ON G-TAP A Series 2 Installation Guide GigaVUE M Series Hardware Installation Guide GigaVUE-FM Hardware Appliances Guide...
Page 69 GigaVUE Firewall and Security Guide GigaVUE Licensing Guide GigaVUE-OS Cabling Quick Reference Guide guidelines for the different types of cables used to connect Gigamon devices GigaVUE-OS Compatibility and Interoperability Matrix compatibility information and interoperability requirements for Gigamon devices GigaVUE-FM REST API Reference in GigaVUE-FM User's Guide...
Page 70 Product: "GigaVUE-FM" and Release: "5.6," enter "pdf" in the search box, and then click GO to view all PDF documentation for GigaVUE-FM 5.6.xx. : My Gigamon is available to registered customers only. Newer documentation PDFs, with the exception of release notes, are all available through the publicly available online documentation.
Page 71 You can also refer to https://www.gigamon.com/support-and-services/contact-support Technical Support hours and contact information. Email Technical Support at support@gigamon.com. Contact Sales Use the following information to Gigamon channel partner or Gigamon sales representatives. Telephone: +1.408.831.4025 Additional Sources of Information Contact Technical Support...
Page 72 Gigamon users, partners, security and network professionals and Gigamon employees come together to share knowledge and expertise, ask questions, build their network and learn about best practices for Gigamon products. Visit the VÜE Community site to: Find knowledge base articles and documentation ■...
Page 73 GigaVUE-TA25 Hardware Installation Guide Glossary decrypt list need to decrypt (formerly blacklist) decryptlist need to decrypt - CLI Command (formerly blacklist) drop list selective forwarding - drop (formerly blacklist) forward list selective forwarding - forward (formerly whitelist) leader leader in clustering node relationship (formerly master) member node follower in clustering node relationship (formerly slave or non-master) no-decrypt list...
Page 74 GigaVUE-TA25 Hardware Installation Guide nodecryptlist no need to decrypt- CLI Command (formerly whitelist) primary source root timing; transmits sync info to clocks in its network segment (formerly grandmaster) receiver follower in a bidirectional clock relationship (formerly slave) source leader in a bidirectional clock relationship (formerly master) Glossary...
