Jofran 2004-42 Assembly Instructions & Parts Identification

j
OFRAN
Thank you for purchasing this quality product. Be sure to check all packing material carefully for small parts that may have come loose inside
the carton during shipment.
No Qty
Code
1
2004-42P24 1 pc
2
2004-42P09 1 pc
3 4 pcs
2004-42P02
4
2004-42P01F 4 pcs
Do not use power tools to assemble this table
Step 1
Attach the I Plate "E" to the top of
the legs, by using wood screws "F".
F
x 16
E
3
MADE IN VIET NAM
INC.
Parts key
Description
Top Frame
Round Glass Insert
Legs
Floor Glide
Finish
Carefully lay the Glass Insert in place
2
ASSEMBLY INSTRUCTIONS
& PARTS IDENTIFICATION
URBAN ICON 42" ROUND
DINNING TABLE - BLACK
Hardware kit
No
Bolt
A
Lock washer
B
Flat washer
C
Allen key
D
E Iron Plate
F Wood Screw
Attach the legs to the position of the legs
Step 2
inside the top frame and attach as shown.
MODEL # 2004-42
# 2004-42P01
Description
Ø6 x 20
Ø8
Ø8 x 18
K4
Ø4x35
x 12
Qty
12 pcs
12 pcs
12 pcs
01 pc
04 pcs
16 pcs
4
Page : 1/1
