Jofran MADISON COUNTY 1700B-KBDHB Assembly Instructions

j
OFRAN
Thank you for purchasing this quality product. Be sure to check all packing material carefully for small parts that may have come
loose inside the carton during shipment.
No Code
6
1700B-KBDHB
7
1700B-KBDHBP07
6
MADE IN VIET NAM
INC.
Parts key
Qty
Description
1 pc
Headboard
2 pcs
Door
ASSEMBLY INSTRUCTIONS
& PARTS IDENTIFICATION
MODEL # 1700B-KBDHB+KPFB+KRS
MADISON COUNTY KING BARN DOOR BED
BARNWOOD FINISH
No
A
B
C
D
E
F
G
H
7
Hardware kit #1700B-KBDHBP01
Description
Bolt Ø5/16'' x 2.75" (#12 Coarse throad)
Ø5/16" x 0.78" (#12 Coarse thread)
Bolt
Ø5/16"
Lock washer
Ø5/16" x 0.63''
Flat washer
Ø25/64" x 0.86"
Flat washer
Ø5/16"
Nut
K5/32"
Allen key
33/64"
Wrench
D C B G
H E
F C A
Note :
Long bolt (A) is used
in the bottom single bracket.
Qty
2 pcs
4 pcs
8 pcs
4 pcs
4 pcs
2 pcs
1 pc
1 pc
x 4
G
x 2
1OF3
