- Page 1 Installation Instructions and Owner’s Manual FTS1 Series Water Softener System Franklin Water Treatment, LLC 12630 US Highway 33 N Churubusco, IN 46723 Phone (260) 693-1972 Fax (260) 693-0602 FTS1 Instruction Manual 231009...
-
Page 2: Table Of Contents
Page 12 - 14 Specifications Pages 15-16 Component Parts Breakdown & List Page 17 Control Valve Breakdown Page 18 Control Valve Parts List Page 19 Installation Fitting Assemblies Pages 21-23 Limited Warranties Page 24-25 Copyright ©2023, Franklin Water Treatment, LLC. All Rights Reserved. -
Page 3: Pre-Installation Instructions
8. Appliances requiring extended periods of continuous or high flow water use (i.e., geothermal heat pumps, swimming pools, lawn irrigation, outside hose bibs, etc.) should bypass all water conditioning equipment unless the equipment has been specifically designed for that purpose. Copyright ©2023, Franklin Water Treatment, LLC. All Rights Reserved. -
Page 4: General Installation
Untreated Water Iron Filter w/ inlet check Pressure Tank Water Heater Brine Tank Softener valve or Backwash Filter (well system only) (if needed) Tank FIGURE 1: Typical Installation Copyright ©2023, Franklin Water Treatment, LLC. All Rights Reserved. -
Page 5: Bypass Valve
If water is available on the outlet side of the softener it is an indication of water bypassing the system (Fig. 5) Figure 3 - Bypass Figure 2 - Service Figure 5 – Shut Off Figure 4 - Diagnostic Copyright ©2023, Franklin Water Treatment, LLC. All Rights Reserved. -
Page 6: Installation Instructions
Drain Line Flow Control Assembly Inlet / Outlet Head DLFC Retainer Clip (Drain fitting Not Shown) Inlet from Water Supply BLFC Retainer Clip FIGURE 6: Top View of Control Valve with Bypass Installed Copyright ©2023, Franklin Water Treatment, LLC. All Rights Reserved. - Page 7 This fitting is an elbow on the side of the brine tank (Figure 7). Attach a length of 1/2" I.D. (5/8” O.D.) tubing to fitting and run to drain. (Continued on next page) Copyright ©2023, Franklin Water Treatment, LLC. All Rights Reserved.
- Page 8 2. Based on water analysis results (obtained either from a lab or in-field testing). Set the amount of hardness in grains per gallon using the UP or DOWN (triangle pointing up or down) buttons. The allowable range is from 1 to 150 in 1 grain Copyright ©2023, Franklin Water Treatment, LLC. All Rights Reserved.
- Page 9 The upper left of the display will show “TIME” b. The current time of day will be shown on the right side of the display c. Only the colon between the hour and minutes will be flashing Copyright ©2023, Franklin Water Treatment, LLC. All Rights Reserved.
- Page 10 Purge air from second tank: Repeat steps 12 – 15 and then proceed with step 22. STEP 21: When the water flowing to drain runs clear, press the “REGEN” button to advance to the “Brine STEP 22: Draw” cycle. Copyright ©2023, Franklin Water Treatment, LLC. All Rights Reserved.
- Page 11 STEP 27: Add salt to brine tank. Fill the brine tank with salt. Any type of softening salt may be used. STEP 28: TURN ON FUEL / ELECTRICAL SUPPLY TO WATER HEATER. Copyright ©2023, Franklin Water Treatment, LLC. All Rights Reserved.
- Page 12 Note: If the salt tank does not contain salt, fill with salt and wait at least two hours before regenerating. If two regenerations are desired within 24 hour period, press /release REGEN button. REGEN TODAY will flash on screen. Press and hold REGEN button until valve initiates an immediate regeneration. Copyright ©2023, Franklin Water Treatment, LLC. All Rights Reserved.
- Page 13 K) Time of Day is spinning, replace meter if defective flashing 12) Reset time & replace backup battery if needed Copyright ©2023, Franklin Water Treatment, LLC. All Rights Reserved.
- Page 14 3) Remove meter and check for restriction automatically D) Defective meter 4) Replace meter if needed E) Defective PC board 5) Replace PC board if needed Copyright ©2023, Franklin Water Treatment, LLC. All Rights Reserved.
- Page 15 ALT oFF 2) Remove piston and seal assemblies for looking for park B) Obstruction in inspection and repair or replacement and position control valve reset control valve. Copyright ©2023, Franklin Water Treatment, LLC. All Rights Reserved.
-
Page 16: Specifications
Overall, length x depth x height 48 x 18 x 56 49 x 18 x 62 51 x 18 x 56 53 x 18 x 62 62 x 34 x 76 Approximate Ship Wt., lbs. Copyright ©2023, Franklin Water Treatment, LLC. All Rights Reserved. - Page 17 23 x 42 24 x 50 Overall, length x depth x height 66 x 34 x 76 70 x 34 x 78 76 x 34 x 78 Approximate Ship Wt., lbs. 1,128 Copyright ©2023, Franklin Water Treatment, LLC. All Rights Reserved.
-
Page 18: Component Parts Breakdown & List
**A 4” x 2.5” tank busing (SF4821-2, not shown) is included with models FTS1-1665 through FTS1-2162 ***Refer to “Installation Fitting Assemblies” pages 21-23 for available I/O fittings. ALL MODELS EXCEPT FTS1-2162 & FTS1-2162-HE INCLUDE ¾ QUICK CONNECT FITTINGS AS WELL AS 1” MALE NPT ELBOWS Copyright ©2023, Franklin Water Treatment, LLC. All Rights Reserved. - Page 19 This page intentionally left blank Copyright ©2023, Franklin Water Treatment, LLC. All Rights Reserved.
-
Page 20: Control Valve Breakdown
Control Valve Breakdown Copyright ©2023, Franklin Water Treatment, LLC. All Rights Reserved. -
Page 21: Control Valve Parts List
Flow Control Washer, 5.3 GPM (FTS1-1465) CV3162-065 Flow Control Washer, 6.5 GPM (FTS1-1665) CV3162-075 Flow Control Washer, 7.5 GPM (FTS1-1865) CV3190-110 Flow Control Washer, 11.0 GPM (FTS1-2162, requires 1” drain housing CV3008-05) Copyright ©2023, Franklin Water Treatment, LLC. All Rights Reserved. - Page 22 1" brass sweat assembly CV3007-03 assembly CV3151 Nut, 1" quick connect CV3151 Nut, 1" quick connect CV3150 Split ring CV3150 Split ring CV3105 O-ring 215 CV3105 O-ring 215 CV3188 Fitting CV3188-01 Fitting Copyright ©2023, Franklin Water Treatment, LLC. All Rights Reserved.
- Page 23 O-ring 215 CV3629 Fitting CV3628 Fitting 1-1/4" PLASTIC MALE NPT Description Part # 1-1/4" plastic male NPT CV3007-05 assembly CV3151 Nut, 1" quick connect CV3150 Split ring CV3105 O-ring 215 CV3317 Fitting Copyright ©2023, Franklin Water Treatment, LLC. All Rights Reserved.
- Page 24 SERVICE WRENCH - CV3193 Although no tools are necessary to assemble or disassemble the valve, the Service Wrench, (shown in various positions on the valve) is available to aid in assembly or disassembly. Copyright ©2023, Franklin Water Treatment, LLC. All Rights Reserved.
- Page 25 TEN YEAR LIMITED WARRANTY Models: FTS1-0948, FTS1-1054, FTS1-1248, FTS1-1354, FTS1-1465 (including “-HE”) WARRANTY – Franklin Water Treatment, LLC, warrants this water conditioner against any defects that are due to faulty material or workmanship during the warranty period. This warranty does not include damage to the product resulting from accident, neglect, misuse, misapplication, alteration, installation, or operation contrary to printed instructions, or damage caused by freezing, fire, flood, or Acts of God.
- Page 26 FIVE YEAR LIMITED WARRANTY Models: FTS1-1665, FTS1-1865, FTS1-2162 (Including “-HE”) WARRANTY – Franklin Water Treatment, LLC, warrants this water conditioner against any defects that are due to faulty material or workmanship during the warranty period. This warranty does not include damage to the product resulting from accident, neglect, misuse, misapplication, alteration, installation, or operation contrary to printed instructions, or damage caused by freezing, fire, flood, or Acts of God.
