- Page 1 Installation Instructions and Owner’s Manual FSX1 Series SanX Water Softener Systems Franklin Water Treatment, LLC. 12630 US Highway 33 N Churubusco, IN 46723 Phone (260) 693-1972 Fax (260) 693-0602 FSX1 Instruction Manual 231009...
-
Page 2: Table Of Contents
Page 16 Installation Fitting Assemblies Page 17 - 19 Troubleshooting Guide Page 20 - 22 Chlorine Generator Board - Dip Switches & Status Light Page 23 Ten Year Limited Warranty Page 24 Copyright ©2023, Franklin Water Treatment, LLC. All Rights Reserved. - Page 3 This page intentionally left blank Copyright ©2023, Franklin Water Treatment, LLC. All Rights Reserved.
-
Page 4: Pre-Installation Instructions
7. Appliances requiring extended periods of continuous or high flow water use (i.e. geothermal heat pumps, swimming pools, lawn irrigation, outside hose bibs, etc.) should bypass all water conditioning equipment unless the equipment has been specifically designed for that purpose. Copyright ©2023, Franklin Water Treatment, LLC. All Rights Reserved. -
Page 5: General Installation Instructions
Expansion Tank Untreated Water Water Heater Brine Tank Iron Filter with Pressure Tank FSX1 Check Valve or (well system only) Backwash Filter Tank (if needed) FIGURE 1: Typical Installation Copyright ©2023, Franklin Water Treatment, LLC. All Rights Reserved. - Page 6 Compression Nut 3/4” FNPT & Tube Insert Chlorine Generator for 5/8” OD Drain Tube and Brine Refill Elbow (Retainer Clip not shown) Control Valve Cover FIGURE 2: Top View of Control Valve Copyright ©2023, Franklin Water Treatment, LLC. All Rights Reserved.
- Page 7 Add water in the brine tank to slightly above the top level of the salt grid (approx. 5 - 6 gallons). DO NOT ADD SALT TO THE BRINE TANK AT THIS TIME. Copyright ©2023, Franklin Water Treatment, LLC. All Rights Reserved.
- Page 8 (refer to Installer Settings, Page 10, for details), then press NEXT repeatedly until the time of day is displayed. STEP 19: Press the CLOCK button to set the current time of day. (Page 10, note AM and PM). Copyright ©2023, Franklin Water Treatment, LLC. All Rights Reserved.
-
Page 9: Bypass Valve
If water is available on the outlet side of the softener it is an indication of water bypassing the system (Fig. 4d) Figure 4b - Bypass Figure 4a - Service Figure 4d – Shut Off Figure 4c - Diagnostic FIGURE 4: Bypass Valve Operation Copyright ©2023, Franklin Water Treatment, LLC. All Rights Reserved. - Page 10 Note: If the salt tank does not contain salt, fill with salt and wait at least two hours before regenerating. If two regenerations are desired within 24 hour period, press /release REGEN button. REGEN TODAY will flash on screen. Press and hold REGEN button until valve initiates an immediate regeneration. Copyright ©2023, Franklin Water Treatment, LLC. All Rights Reserved.
- Page 11 3. Regeneration Days Override: Press the “NEXT” button a. The upper left of the display will show “DAYS BETWEEN REGEN” b. The lower left of the display will show “SET” c. A number will flash (default 14) Copyright ©2023, Franklin Water Treatment, LLC. All Rights Reserved.
- Page 12 The upper left of the display will show “TIME” b. The current time of day will be shown on the right side of the display c. Only the colon between the hour and minutes will be flashing Copyright ©2023, Franklin Water Treatment, LLC. All Rights Reserved.
-
Page 13: Specifications
23 x 42 Overall, depth x width x height 18 x 28 x 62 18 x 30 x 56 18 x 31 x 62 23 x 37 x 76 Approximate Ship Wt., lbs. Copyright ©2023, Franklin Water Treatment, LLC. All Rights Reserved. -
Page 14: Component Parts Breakdown
Component Parts Breakdown Copyright ©2023, Franklin Water Treatment, LLC. All Rights Reserved. -
Page 15: Component Parts List
Elbow Locking FC103 FC103 FC103 FC103 Clip **Refer to “Installation Fitting Assemblies” pages 17-19 for available I/O fittings. ALL MODELS INCLUDE ¾ QUICK CONNECT FITTINGS AS WELL AS 1” MALE NPT ELBOWS Copyright ©2023, Franklin Water Treatment, LLC. All Rights Reserved. -
Page 16: Control Valve Breakdown
Control Valve Breakdown Copyright ©2023, Franklin Water Treatment, LLC. All Rights Reserved. -
Page 17: Control Valve Parts List
Flow Control Washer, 3.2 GPM (FSX1-1248) CV3162-042 Flow Control Washer, 4.2 GPM (FSX1-1354) CV3162-053 Flow Control Washer, 5.3 GPM (FSX1-1465) CG-3HDW Chlorine Generator Hardware, for CG-3 less Pwr Supply & PCB CG-3PCB PCB Board for CG-3 Copyright ©2023, Franklin Water Treatment, LLC. All Rights Reserved. -
Page 18: Installation Fitting Assemblies
1" brass sweat assembly CV3007-03 assembly CV3151 Nut, 1" quick connect CV3151 Nut, 1" quick connect CV3150 Split ring CV3150 Split ring CV3105 O-ring 215 CV3105 O-ring 215 CV3188 Fitting CV3188-01 Fitting Copyright ©2023, Franklin Water Treatment, LLC. All Rights Reserved. - Page 19 O-ring 215 CV3629 Fitting CV3628 Fitting 1-1/4" PLASTIC MALE NPT Description Part # 1-1/4" plastic male NPT CV3007-05 assembly CV3151 Nut, 1" quick connect CV3150 Split ring CV3105 O-ring 215 CV3317 Fitting Copyright ©2023, Franklin Water Treatment, LLC. All Rights Reserved.
- Page 20 SERVICE WRENCH - CV3193 Although no tools are necessary to assemble or disassemble the valve, the Service Wrench, (shown in various positions on the valve) is available to aid in assembly or disassembly. Copyright ©2023, Franklin Water Treatment, LLC. All Rights Reserved.
- Page 21 11) Verify meter cable (grey cable, 3 pins) is H) Faulty or unplugged connected to control valve circuit board connector J2 (labeled “METER”) drive motor Meter cable disconnected Copyright ©2023, Franklin Water Treatment, LLC. All Rights Reserved.
- Page 22 C) Restricted/stalled water is flowing meter turbine 3) Remove meter and check for restriction D) Defective meter 4) Replace meter if needed E) Defective PC board 5) Replace PC board if needed Copyright ©2023, Franklin Water Treatment, LLC. All Rights Reserved.
- Page 23 ALT OFF inspection and repair or replacement and looking for park B) Obstruction in reset control valve (hold “NEXT” and position control valve “REGEN” buttons for 3 seconds) Copyright ©2023, Franklin Water Treatment, LLC. All Rights Reserved.
- Page 24 Orange – End of cycle • Red – Alert: 1 blink – high current shut down 2 blinks – no current warning 3 blinks – chlorine generation time exceeded the maximum of 32.5 minutes Copyright ©2023, Franklin Water Treatment, LLC. All Rights Reserved.
-
Page 25: Ten Year Limited Warranty
TEN YEAR LIMITED WARRANTY WARRANTY – Franklin Water Treatment, LLC, warrants this water conditioner against any defects that are due to faulty material or workmanship during the warranty period. This warranty does not include damage to the product resulting from accident, neglect, misuse, misapplication, alteration, installation, or operation contrary to printed instructions, or damage caused by freezing, fire, flood, or Acts of God.
