HIVE Flow
HIVE Flow
Mini
2-31
SAUNA STOVE
32-61
POÊLE POUR SAUNA
Patent pending
BimSchV II
1
Ecodesign 2015/1185

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HIVE Flow and is the answer not in the manual?

Questions and answers

Summary of Contents for HUUM HIVE Flow

  • Page 1 HIVE Flow HIVE Flow Mini 2-31 SAUNA STOVE 32-61 POÊLE POUR SAUNA Patent pending BimSchV II Ecodesign 2015/1185...
  • Page 2: Table Of Contents

    WARNINGS AND NOTES SOLVING PROBLEMS WARRANTY APPENDIX 1 - TECHNICAL DATA OF THE SAUNA STOVE APPENDIX 2 - DECLARATION OF HIVE FLOW PERFORMANCE APPENDIX 3 - DECLARATION OF HIVE FLOW MINI PERFORMANCE APPENDIX 4 - SPARE PARTS APPENDIX 5 - ACCESSORIES...
  • Page 3 (2 pcs); ash drawer. Spare parts article numbers can be found in the Appendix 4 and 5 A sauna stove needs stones. We recommend using HUUM 5-10cm sauna stones ATTENTION! (See Appendix 5, page 30-31). Only the specialist of the relevant field may connect the wood-burning sauna ATTENTION! stove described in the manual to the chimney.
  • Page 4: General

    GENERAL Thank you for choosing HUUM Flow. You have choosen a unique sauna stove that is the cleanest woodburning stove on the market. You will not just have an unforgett able sauna experience, but also keep the enviroment clean. For an optimal and safe sauna experience, it is strongly recommended to review the operation manual and retain it for future consultation.
  • Page 5 • Changing the construction of the sauna stove is strictly prohibited and may result in serious malfunction. It will result in termination of the warranty. Use only HUUM spare parts off ered by the manufacturer. • Appendix 4, page 29.
  • Page 6: Installation

    INSTALLATION • All relevant local regulations should be followed when installing the sauna stove, including those referring to country specific standards and European standards. • Before installing and using the sauna stove, thoroughly review the requirements for installing the sauna stove in the sauna room. If you have questions or to obtain additional information, be sure to contact the local or national fire safety agency or consult an authorized specialist.
  • Page 7 Place the ash grate in place Push the ash drawer into place Install the lower cleaning hatch through the opening of the upper cleaning hatch Install the upper cleaning hatch Add a flue pipe to the leg of the chimney to improve draft. Preferably at least 1 metre (not included in the set).
  • Page 8: Base Surface

    30 mm is mandatory between such a base and the fl oor, so that air can move freely. SAFETY DISTANCES Min. 40" / 1000mm Figure 7. Safety distances of HIVE Flow sauna stove from fl ammable materials (e.g. wooden wall, bench etc). Quantity of Table 1.
  • Page 9 HUUM floor protection plate (sold separately) has been provided in Appendix 5, page 30. HIVE Flow HIVE Flow Mini Min. 15 ³/₄"/ 400 mm Min. 16 ¹⁷/₃₂"/ Min. 15"/ 420mm 380mm Figure 8. HIVE Flow and Flow Mini sheet metal plate for floor protection (sold separately).
  • Page 10 Figure 9. Installing HIVE Flow LS and Flow Mini LS sauna stoves through the wall. The minimum dimensions for the non-combustible wall and the opening in the case of HIVE Flow LS are provided in Table 2. For HIVE Flow Mini LS, see Table 3. Table 2.
  • Page 11: Connection To The Flue

    The flue (chimney) must comply with the specifications provided in Appendix 1. HIVE Flow sauna stove can be connected to the flue both from the top and back of the sauna stove. To connect from the back, the positions of the bolted chimney leg and cover plate should be changed.
  • Page 12: Sauna Room

    6' 6" - 7' 5" (2000 - 2300 mm). In case of a higher sauna room, it is advisable to lower the ceiling, thus reducing the volume of the sauna room. The minimum permissible height of the sauna room for HUUM Flow sauna stove is 6' 2" (1900 mm).
  • Page 13: Darkening Of The Sauna Room Wall

    ATTENTION! When covering the walls or ceiling with heat protection (e.g. with mineral tiles), a sufficient ventilation gap should be left between the materials. Installing tiles directly on a wall or ceiling surface can cause dangerous overheating of wall and/or ceiling materials. Check with your local authorities responsible for fire safety regarding ATTENTION! parts of the firewall can be insulated.
  • Page 14: Ventilation

    You can find instructions on the proper sauna ventilation solution on HUUM's website: huum.eu "HUUM Blog - Sauna ventilation" After using the sauna, the room should be ventilated to get rid of excess humidity.
  • Page 15: Use

    • The size and quantity of suitable stones for the sauna stove have been provided in Appendix 1. • HIVE Flow stone grate can be split. To insert and remove the lower stones, the upper part of the grate should be removed and raised as far as the chimney connection allows (Figure 13).
  • Page 16: Heating

    • To remove the ash drawer for emptying, open the hearth door, lift the ash drawer slightly and then pull it out (the ash drawer has a safety limiter that prevents it from being opened excessively during heating). See Figure 15. Figure 15. Removing HIVE Flow ash drawer.
  • Page 17: Starting The Heating

    Ashes and coals should be completely extinguished and cooled ATTENTION! before emptying the ash drawer into a fire resistent waste bucket or combustible material container. • Make sure there is a draft in the chimney. If in doubt, check the draft, by burning some paper in the hearth of the sauna stove.
  • Page 18: Filling The Hearth During Heating

    • Keep the ash drawer open for up to 15 minutes after lighting. The ash drawer has /₈ " (3 mm). a limiter that prevents it from being opened more than • The hearth door can be kept open for approximately 2 minutes after lighting. A few millimetres are enough.
  • Page 19 3 When the fi rst batch is burnt, add fi rewood (max. 4 lb / 1.8 kg). 4 If you need more heat, add fi rewood after the previous batch has burnt (max. 3 lb / 1.4 kg). Figure 17. Starting HIVE Flow Mini heating and adding the batch of fi rewood.
  • Page 20: Making Steam

    MAKING STEAM As the sauna heats up, the air in the sauna room becomes dry. To achieve a pleasant humidity level and the best sauna experience, throw water on the hot stove stones. • Start making steam only when the stones are properly hot and the water has completely evaporated from them.
  • Page 21: Maintenance

    Without a seal, the combustion process receives too much air and can cause overheating. The door seal can be replaced. You can order a suitable seal and glue as HUUM's spare parts. See Appendix 4, page 29.
  • Page 22: Removal From Use

    REMOVAL FROM USE HUUM sauna stoves are designed to last with the aim of leaving the smallest possible ecological footprint on the environment. When the sauna stove has served its time, take it and the related parts to a designated collection point for disposal in accordance with local legal regulations.
  • Page 23: Solving Problems

    If the door glass is broken, order a replacement glass as a HUUM spare part. The list of spare parts Appendix 4, page 29. Heating the sauna stove with cracked glass is prohibited! ATTENTION! •...
  • Page 24 The sauna stove is overheating • The ash drawer is open during heating. • The chimney draft is too big. • Firewood is too thin and/or dry. • The amounts and intervals of batches are incorrect (see Appendix 1, page 26) The oven glass is getting sooty •...
  • Page 25: Warranty

    • If the product has been repaired by an unauthorized person, the parts that do not belong to the product have been added or the consumables not accepted by the manufacturer have been used. • The set of the product is not complete. Find the most up-to-date information on our website: huum.eu...
  • Page 26: Appendix 1 - Technical Data Of The Sauna Stove

    APPENDIX 1 TECHNICAL DATA OF THE SAUNA STOVE Flow Flow Flow Flow Mini Mini LS 282-635/ 282-635/ 211-494/ 211-494/ Size of the sauna room, ft 8-18 8-18 6-14 6-14 35 / 884 35 / 884 35 / 884 35 / 884 Height from the floor, in / mm 21 / 526 21 / 526...
  • Page 27: Appendix 2 - Declaration Of Hive Flow Performance

    APPENDIX 2 DECLARATION OF HIVE FLOW PERFORMANCE EN 15821:2010 Wood-burning sauna stoves with reheating for heating rooms in residential buildings. Sauna stove HIVE Flow • HUUM Sauna OÜ HIVE Flow LS • Vahi tee 9 60534 Vahi küla BImSchV Stufe 2 01/26/2010 DIN EN 13240...
  • Page 28: Appendix 3 - Declaration Of Hive Flow Mini Performance

    APPENDIX 3 DECLARATION OF HIVE FLOW MINI PERFORMANCE EN 15821:2010 Wood-burning sauna stoves with reheating for heating rooms in residential buildings. Sauna stove HIVE Flow Mini • HUUM OÜ HIVE Flow Mini LS • Vahi tee 9 60534 Vahi küla...
  • Page 29: Appendix 4 - Spare Parts

    APPENDIX 4 SPARE PARTS Figure Code Model Name Ashgrate SP0092 All Flow models SP0093 Cleaning hatch All Flow models Wooden parts of the door handle SP0094 All Flow models including screws Flow SP0095 SP0096 Flow LS Ashdrawer SP0097 Flow Mini Flow Mini LS SP0098 Flow/Flow LS...
  • Page 30: Appendix 5 Accessories

    APPENDIX 5 ACCESSORIES Figure Code Name/model Floor protection plate H3017011 For all HIVE Flow modelst Stainless steel Mounting collar H3016021 for HIVE Flow LS Black Mounting collar H3016031 for HIVE Flow LS Stainless steel Mounting collar H3018021 for HIVE Flow Mini LS...
  • Page 31 APPENDIX 5 ACCESSORIES Figure Code Name/model Chimney set, H3100 through the ceiling Chimney set, H3101 barrel sauna Chimney set, H3102 through the wall Rear connection H310202 chimney set...
  • Page 32 PROBLÈMES ET REMÈDES CONDITIONS DE GARANTIE ANNEXE 1 – CARACTÉRISTIQUES TECHNIQUES DU POÊLE ANNEXE 2 – DÉCLARATION DES PERFORMANCES DE HIVE FLOW ANNEXE 3 – DÉCLARATION DES PERFORMANCES DE HIVE FLOW MINI 120 ANNEXE 4 – PIÈCES DÉTACHÉES ANNEXE 5 – ACCESSOIRES...
  • Page 33 Ce poêle pour sauna a besoin de pierres. Nous recommandons d'utiliser les ATTENTION ! pierres de sauna HUUM de 5 à 10 cm (voir Annexe 5, pages 122-123). Seul le cheministe/fumiste est habilité à raccorder à la cheminée le poêle à bois ATTENTION ! décrit dans la présente notice.
  • Page 34 GÉNÉRALITÉS Merci d'avoir choisi le poêle HUUM Flow pour votre sauna – le poêle à bois le plus écologique sur le marché, qui vous garantira une expérience inoubliable de sauna. Pour que notre promesse se réalise, nous vous recommandons fortement de lire la notice d'utilisation et de la garder précieusement.
  • Page 35 • Veuillez utiliser uniquement les pièces détachées HUUM, proposées par le fabricant (voir Annexe 4, page 121.) Il est interdit d’enlever l'étiquett e de données collée sur le poêle ou de modifi er •...
  • Page 36 INSTALLATION • Veuillez respecter toutes les réglementations locales concernant l'installation du poêle pour sauna, les normes nationales et européennes y compris. • Avant de procéder à l'installation et l'utilisation du poêle pour sauna, veuillez lire attentivement les instructions sur l'installation de ce poêle dans votre sauna. Si vous avez des questions ou vous voulez obtenir des informations supplémentaires, veuillez contacter les autorités de sécurité...
  • Page 37 1. Installez la grille de décendrage. 2. Installez le bac à cendres. 3. Installez la trappe de nettoyage inférieure à travers l'ouverture pour la trappe de nettoyage supérieure 4. Installez la trappe de nettoyage supérieure 5. Installez le conduit de fumée pour améliorer le tirage du poêle. Nous recommandons le conduit au moins d'un mètre de longueur (non inclus dans le kit).
  • Page 38 DISTANCES DE SÉCURITÉ Min. 40" / 1000mm Figure 7. Distances de sécurité pour le poêle HIVE Flow par rapport aux matériaux combustibles (p. ex. murs et bancs en bois etc.). Quantité de...
  • Page 39 (vendue séparément) veuillez voir l'Annexe 5, page 122. HIVE Flow HIVE Flow Mini Min. 15 ³/₄"/ 400 mm Min. 16 ¹⁷/₃₂"/ Min. 15"/ 420mm 380mm Figure 8. Plaques en tôle de protection du plancher pour les modèles HIVE Flow et Flow Mini (vendues séparément).
  • Page 40 Figure 9. Installation des poêles HIVE Flow LS et Flow Mini LS à travers le mur.. Les dimensions minimales du mur non-combustible et de l'ouverture dans le mur pour HIVE Flow LS sont désignées dans le Tableau 2. Pour HIVE Flow Mini LS veuillez voir le Tableau 3.
  • Page 41 Le conduit de fumée (la cheminée) doit être conforme aux spécifications fournies dans l'Annexe 1. Le poêle pour sauna HIVE Flow peut être connecté au conduit de fumée par le haut ou par l'arrière. Pour un raccordement par l'arrière, il faut changer les positions du manchon et de la plaque vissés au poêle.
  • Page 42 2000 à 2300 mm. Si le plafond est plus haut, il est conseillé de le baisser, réduisant ainsi son volume. La hauteur minimale autorisée pour le poêle HUUM Flow est de 1900 mm. La distance entre le banc supérieur et le plafond doit être comprise entre 1100 et 1300 mm.
  • Page 43 Pour que vos séances de sauna soient saines et agréables, il est important d'assurer une bonne circulation de l'air dans votre sauna. Les instructions concernant une ventilation appropriée sont publiées sur le site huum.eu "HUUM Blog - Sauna ventilation"...
  • Page 44 Après la séance de sauna, pensez à toujours bien aérer la pièce pour éliminer l'excès d'humidité. Une ventilation mécanique peut entraîner des problèmes de flux ATTENTION ! d'air dans la pièce et un manque d'oxygène pour une bonne combustion dans le foyer.
  • Page 45 • • La cage à pierres HIVE Flow se compose de deux parties démontables. Pour poser les pierres dans la partie inférieure de la cage, démontez sa partie supérieure et relevez-la autant que le permet le raccordement à la cheminée (Figure 13).
  • Page 46 • Pour retirer le bac à cendres et le vider, ouvrez la porte du foyer, soulevez un peu le bac à cendres et retirez-le (le bac est doté d'une sécurité qui empêche de le retirer pendant le chauff age). Voir la fi gure 15. Figure 15. Dépose du bac à cendres HIVE Flow...
  • Page 47 Les cendres et les charbons doivent être complètement éteints ATTENTION ! et refroidis avant de vider le bac à cendres dans un seau ou une poubelle ignifuge. • Assurez-vous que le tirage est bon. Pour se faire, brûlez du papier dans le foyer. •...
  • Page 48 • Entrouvrez le bac à cendres pour environ 15 minutes après l'allumage. Le bac à cendres est doté d'un limiteur qui permet de l'entrouvrir à 3 mm au maximum pendant la combustion. • On peut entrouvrir la porte du foyer à quelques millimètres pendant environ 2 minutes.
  • Page 49 3 Après que les braises soient formées, rechargez le feu (1,8 kg au maximum). 4 Pour augmenter la température dans le sauna, rechargez le poêle encore une fois (1,4 kg au maximum). Figure 17. Comment allumer et recharger le poêle HIVE Flow Mini.
  • Page 50 ARROSAGE DES PIERRES Au fur et à mesure que la température dans le sauna monte, l'air dans le sauna devient de plus en plus sec. Pour l’humidifier, on peut verser un peu d'eau sur les pierres chaudes. • Arrosez les pierres après qu’elles sont devenues suffisamment chaudes pour évaporer l'eau complètement.
  • Page 51 Vous pouvez commander le joint approprié et l'adhésif en tant que pièces détachées HUUM. Veuillez voir l'Annexe 4, page 121.
  • Page 52 POÊLE EN FIN DE VIE Les poêles de sauna HUUM sont conçus pour durer en laissant la plus petite empreinte écologique possible. Lorsque vient le temps de remplacer le poêle, veuillez le ramener au centre de recyclage conformément aux réglementations locales.
  • Page 53 à la vitre. Si la vitre de la porte se casse, vous pourrez la commander comme pièce détachée HUUM. Pour la liste des pièces détachées veuillez voir l'Annexe 4, page 121.
  • Page 54 PROBLÈMES ET REMÈDES Le tirage du poêle est faible • Le poêle n'a pas été utilisé depuis longtemps et le conduit de fumée et les pierres sont humides. • L’apport d’air n’est pas suffisant pour le poêle ou la ventilation a créé une dépression dans le sauna.
  • Page 55 • Le produit a été réparé par une personne non autorisée ; des pièces non conformes ont été montées sur le produit ; des consommables non approuvés par le fabricant ont été utilisés. • Le produit n'est pas complet. Pour consulter les informations les plus récentes, veuillez visiter notre site huum.eu...
  • Page 56 ANNEXE 1 CARACTÉRISTIQUES TECHNIQUES DU POÊLE POUR SAUNA Flow Flow Flow Flow Mini Mini LS 6..14 6..14 Volume du sauna, m 8..18 8..18 Hauteur à compter du sol, mm Largeur, mm Profondeur (sans poignée), mm Diamètre du manchon de raccord, mm Classe de température de cheminée T450 T450...
  • Page 57 ANNEXE 2 DÉCLARATION DES PERFORMANCES DE HIVE FLOW EN 15821:2010 Poêles à bois pour sauna, destinés à chauffer des locaux dans les immeubles d'habitation. Sauna stove HIVE Flow • HUUM OÜ HIVE Flow LS • Vahi tee 9 60534 Vahi küla...
  • Page 58 ANNEXE 3 DÉCLARATION DES PERFORMANCES DE HIVE FLOW MINI EN 15821:2010 Poêles à bois pour sauna, destinés à chauffer des locaux dans les immeubles d'habitation. Sauna stove HIVE Flow Mini • HUUM OÜ HIVE Flow Mini LS • Vahi tee 9 60534 Vahi küla...
  • Page 59 ANNEXE 4 PIÈCES DÉTACHÉES Figure Code Modèle Dénomination Pour tous les modèles Grille de décendrage SP0092 Flow Pour tous les modèles SP0093 Trappe de nettoyage Flow Poignée de porte, Pour tous les modèles SP0094 Flow vis compris Flow SP0095 SP0096 Flow LS Bac à...
  • Page 60 Pour tous les modèles Flow Cadre de montage en acier inoxydable pour HIVE H3016012 Flow LS H3016013 Cadre de montage peint en noir pour HIVE Flow LS Cadre de montage en acier H3018012 inoxydable pour HIVE Flow Mini LS Cadre de montage en acier...
  • Page 61 ANNEXE 5 ACCESSOIRES Figure Code Dénomination/Modèle Kit de cheminée, raccordement H3100 à travers le plafond Kit de cheminée pour sauna H3101 en forme de tonneau Kit de cheminée, H3102 raccordement à travers le mur Kit de cheminée, H310202 raccordement arrière...
  • Page 62 NOTES REMARQUES © All rights reserved HUUM Sauna 2024...
  • Page 63 NOTES REMARQUES © All rights reserved HUUM Sauna 2024...
  • Page 64 #huumsauna...
