Setting Up; Connecting To Your Tv - Avantree Opera Plus User Manual

User Manual
Powering the Transmitter
To power the transmitter, connect it to a wall outlet via the provided power
cables and wall adapter. It doesn't hold a charge, so it needs to be connected to
power in order to function.

Setting up

Connecting to Your TV

Once the transmitter is connected to a power source, next is to connect it to
your TV's audio output ports. You can choose one of 4 options to do this:
Optical port (Recommended)
OPTION 1
Plug the provided optical audio cable into the TV's optical OUT or "OPT / OUT"
port, then plug the other end into the transmitter's optical port in the "INPUT
FROM TV" section.
On your transmitter, switch the "AUDIO INPUT SELECTOR" to the "OPT"
postion.
TV
OPT/OUT
Input From TV
OPT
Opera plus
AUX
OPT
HDMI
ARC
9
