Summary of Contents for Avantree HT3831
- Page 1 HT3831 User Manual Model No.: WSHT-3831...
-
Page 2: Table Of Contents
User Manual HT3831 Table of Contents Box Contents 3... -
Page 3: Box Contents
User Manual HT3831 Box Contents Wireless Transmitter& Dual Charging HT381 Earbuds x3 Charging Dock Dock Spare Battery Earbuds tips Optical Audio Cable (M / S) x6 3.5mm AUX 3.5mm AUX to Wall 6.35mm to Cable RCA Adapter Adapter x2 3.5mm Adapter... -
Page 4: Product Introduction (Earbuds)
User Manual HT3831 Product Introduction (Earbuds) Product Overview Power / Connection / Volume Control Mode Indicator AMBIENT AMBIENT Button ON / OFF AMBIENT ON/OFF Microphone ON/OFF Left-right Audio Balance Control Battery... -
Page 5: Button Functions
User Manual HT3831 Button Functions Button Functions Switch to the “ON / OFF” position to turn the earbuds on / off Roll to “+ / -” to increase / decrease volume Click once to enter / exit AMBIENT mode to amplify... -
Page 6: Product Introduction (Transmitter & Charging Dock)
User Manual HT3831 Product Introduction (Transmitter & Charging Dock) Product Overview Spare Battery Charging Slot Charging Cradle Mode / Pair Button BASS Spare Battery Charging Indicator TREBLE BASS TRANSMIT Earbuds Charging Indicator BALANCED Bass / Treble / TREBLE Power / Connection Indicator... -
Page 7: Button Functions
User Manual HT3831 Charging Port Charging Indicator Button Functions Button Functions Click once to switch between BASS / TREBLE / BALANCED modes. Long press for 2 seconds to enter pairing mode Switch between "Stereo / Mono". Switch to "mono" mode... -
Page 8: Led Indicators
User Manual HT3831 LED Indicators Indicators Status Solid red Spare battery charging Solid green Spare battery fully charged Solid red Earbuds charging Solid green Earbuds fully charged Solid Green Power on / Connected Flashing green rapidly Pairing mode Solid orange... -
Page 9: Setting Up
User Manual HT3831 Setting Up Connecting to Your TV The transmitter dock must be connected to a power source using the provided power cable and charger in order to function. Once the transmitter dock is connected to a power source, you can connect it to your TV. You can choose... - Page 10 User Manual HT3831 AUX 3.5mm port OPTION 2 Plug the provided AUX 3.5mm audio cable into the TV’s AUX 3.5mm output port, then plug the other end into the transmitter’s AUX 3.5mm port. RGB IN AUDI O HDMI/DVI IN RG B( P C )
-
Page 11: Connecting The Earbuds To The Transmitter
User Manual HT3831 Connecting the Earbuds to the Transmitter STEP 1 Power on the earbuds by sliding the to the “ON” position. STEP 2 Keep the earbuds close to the transmitter; they should connect within 2-5 seconds. Once connected, both the LED indicator on the earbuds and the LED indicator on the transmitter will turn solid green. - Page 12 Audio Out Optical Out Audio Format Dolby - OFF If you’re having trouble finding these settings, you can scan the QR code of your TV’s brand below OR visit avantree.com/3831/tv-audio-settings for a more detailed guide. SONY SAMSUNG NETFLIX/ AMAZON PRIME NOTE 1: Smart TVs automatically reset their settings after system updates.
-
Page 13: Advanced Features
HT3831 Advanced Features Listening with an AV Receiver The HT3831 comes with one 6.35mm to 3.5mm audio adapter and one AUX 3.5mm audio cable that you can use with your AV Receiver. STEP 1 Plug a 3.5mm AUX audio cable into the transmitter’s AUX 3.5mm port in the “INPUT FROM TV”... -
Page 14: Adding More Ht381 Earbuds
User Manual HT3831 Adding More HT381 Earbuds The HT3831 transmitter can connect up to 100 pairs of earbuds. Follow these steps to connect four or more HT381 earbuds to the transmitter: STEP 1 On your transmitter, press & hold the “MODE” button for 2 seconds. -
Page 15: Charging The Earbuds
User Manual HT3831 Charging the Earbuds When the earbuds’ battery is low, you’ll start hearing “beeps” three times per minute and the LED will flash green rapidly. Please charge the earbuds when this happens. There are 2 ways to charge the earbuds. - Page 16 HT3831 Swapping in the spare battery OPTION 2 The HT3831 set comes with an extra battery. Simply swap in that extra battery, and insert the drained battery into the battery charging dock to charge. indicator on the front side of the transmitter dock will turn red when the battery is charging and turn green when the charging is complete.
-
Page 17: Specifications
User Manual HT3831 Specifications Transmitter Carrier Frequency 2.4GHz Operating range Up to 100ft / 30m Operating Voltage Supported audio format in optical mode PCM / LPCM Power port Type C Rated input DC5V/500mA~2.0A Weight 157g Earbuds Carrier Frequency 2.4GHz Operating range... -
Page 18: Faq
This completely depends on whether or not your TV supports the ability to output audio to 2 sources simultaneously. You can try a few different methods to test if your TV is capable of this or not - please refer to avantree. com/3831/sound for more details. -
Page 19: Contact Us
Contact Us Support Tickets avantree.com/submit-a-ticket Support Email support@avantree.com Support Numbers US +1 800 232 2078 9am-6pm PST Mon-Fri CA +1 800 232 2078 9am-6pm PST Mon-Fri UK +44 208 068 2023 9am-6pm GMT Mon-Sat DE +49 322 2109 7297 11am-9pm CET... - Page 20 Manufacturer: Avantronics Limited Luohu District, Shenzhen 518000 China + 86 755 8228 5022 support@avantree.com US Importer: Avantree Corporation San Jose, California 95119 USA +1 800 232 2078 support@avantree.com UK Importer: Avantree Limited Watford, WD180 0HQ UK +44 20 8068 2023 support@avantree.com Servicer in Europe: Gizmex GmbH,...
