- Page 1 Forklift hydraulic weighing system OPERATING INSTRUCTIONS ENGLISH www.diniargeo.com...
-
Page 3: Table Of Contents
Contents Introduction Warnings Display and keyboard Accuracy factors Weight reading Basic functions 8 Switching on 9 Switching off 9 Adjusting the display brightness 10 Setting a known tare value (PT) 10 Clearing the tare 11 Print ... -
Page 4: Introduction
• Please read this manual carefully before using the system. • Assistance must only be carried out by personnel authorised by Dini Argeo. • Dini Argeo is not responsible for any weighing errors resulting from improper use of the system. LTP_05_23.03_EN_U... -
Page 5: Display And Keyboard
Display and keyboard ITEM ICON DESCRIPTION This indicates that the scale is empty (gross zero). This indicates that the weight is unstable. The net weight is displayed. Note: A tare has been stored. The gross weight is displayed. 4 / 5 This indicates the battery level: A tare has been blocked. - Page 6 Description • For numerical entries, decreases the value. • If pressed for a long time (2 sec), it allows you to set the brightness of the display. • For numerical entries, increases the value. • If pressed for a long time (2 sec) it allows you to insert a preset tare. •...
-
Page 7: Accuracy Factors
(indicated by the stickers). The theoretical precision of the LTP system, correctly installed on suitable electric forklifts and used under optimal conditions, varies from 0.5% to 5% of the capacity (min. 10 kg). -
Page 8: Weight Reading
Weight reading Before turning on the weight indicator, make some lifting with empty forks (at least 5) to heat the oil inside the hydraulic circuit. With the forks down (without touching the ground), turn on the weight indicator and wait for it to zero. During load acquisition the display shows: ---- At the end of the acquisition, the weight is shown. -
Page 9: Switching Off
Switching off Display view: Display view: -off- Press for Condition of the forklift: Condition of the forklift: Adjusting the display brightness Display view: Display view: ZERO brGt 0 Press for Condition of the forklift: Set the brightness value: Increase value Decrease value Confirm LTP_05_23.03_EN_U... -
Page 10: Setting A Known Tare Value (Pt)
Setting a known tare value (PT) 50 kg ? kg Display view: Display view: 000050 Press for Condition of the forklift: Setting the tare value: Increase / decrease the value Display view: Display view: PRINT Condition of the forklift: Condition of the forklift: 200 kg 50 kg Clearing the tare... -
Page 11: Print
Print Display view: Display view: print Condition of the forklift: Condition of the forklift: NUM. WEIGHED GROSS 15.000 kg TARA 3.000 kg 12.000 kg RECEIPT NO. 54321 15/11/2018 15:39:03 Metric information Display view: Display view: INFo Press for Condition of the forklift: Condition of the forklift: 2000 LTP_05_23.03_EN_U... -
Page 12: Advanced Functions Of The Scale
Advanced functions of the scale How to enter the functions menu Display view: Display view: ConfiG Press for Condition of the forklift: “Co n fiG” will flash on the indicator for a few seconds Display view: Display view: Display view: CloCk Mode FunCt... -
Page 13: Horizontal Weight Totalisation
Horizontal weight totalisation HOW TO SUM THE WEIGHS Display view: Display view: t. 1 Condition of the forklift: Condition of the forklift: NUM. WEIGHED 00000001 100 kg Display view: Display view: t. 2 Condition of the forklift: Condition of the forklift: NUM. - Page 14 HOW TO MOMENTARILY READ THE TOTAL Display view: N . 3 Number of weighs Total weight HOW TO END WEIGHT TOTALISATION AND ZERO THE TOTAL NUM. WEIGHED 00000001 Display view: 100 kg N . 3 NUM. WEIGHED 00000002 200 kg Press for Number of weighs NUM.
-
Page 15: Exchange Between Net Weight And Gross Weight
Exchange between net weight and gross weight Display view: Display view: Press for Condition of the forklift: Condition of the forklift: Setting the tare value: Increase / decrease the value Display view: Display view: Condition of the forklift (*): Condition of the forklift (*): Display view: Display view: Condition of the forklift:... -
Page 16: Unit Of Measure Conversion
Unit of measure conversion HOW TO CONVERT THE UNIT OF MEASUREMENT TO POUNDS (STANDARD MODE) Display view: Display view: 440.9 Condition of the forklift: Condition of the forklift: MODE By pressing at any time you can switch from weight in kg to weight in pounds. HOW TO CONVERT THE UNIT OF MEASURE WITH FREE CONVERSION FACTOR Display view: Display view:... - Page 17 Display view: Display view: 101.2 Condition of the forklift: Condition of the forklift: MODE By pressing at any time, the unit of measurement can be converted with a free conversion factor. LTP_05_23.03_EN_U...
-
Page 18: Configuration Menu
Configuration menu MENU CloCk - DATE AND TIME How to enter How to browse 5 Sec. month Month month year CloCk Year dyn.wGt year preC. 10 month hour sCreen year Hour hour autoff hour minute tik.res Minute diaG Minute mode Minute Max.wGt LTP_05_23.03_EN_U... - Page 19 MENU DYN.WGT - SENSOR FINE TUNING How to enter How to browse Advanced configuration parameters. For use by the installer. 5 Sec. div.zmk div.unf CloCk WGt.unf dyn.wGt tim.up preC. 10 div.zmk div.unf sCreen tim.avG WGt.unf autoff Refer to the technical manual for more information. tim.up tik.res tim.avG...
- Page 20 MENU SCreen - ADJUSTING THE DISPLAY How to enter How to browse Backlighting 5 Sec. bak.it Always on CloCk On when weight is auto dyn.wGt unstable preC. 10 briGht sCreen Brightness bak. it autoff briGht briGht tik.res brGt 1 loCk diaG mode Max.wGt...
- Page 21 MENU autoff - AUTOMATIC SWITCH-OFF How to enter How to browse 5 Sec. autoff min.off M 003 CloCk tik.res dyn.wGt preC. 10 sCreen autoff tik.res - TICKET NUMBER RESET tik.res diaG sure? tik.res mode diaG Max.wGt diaG - DIAGNOSTICS Reserved for technical staff. diaG 21 21 LTP_05_23.03_EN_U...
- Page 22 MENU mode - INDICATOR FUNCTIONS How to enter How to browse mode 5 Sec. Weight totalisation Total Conver Converting units of measurement CloCk Exchange net net.Gro weight / gross dyn.wGt weight preC. 10 max.wGt sCreen autoff tik.res Max.wGt - SETPOINT ON GROSS WEIGHT diaG mode max.wGt...
-
Page 23: Maintenance
Maintenance The results of the weighing system depend on the condition of the various parts of the forklift. The weighing system does not require any special maintenance, but a poor condition of the various parts of the forklift can negatively affect the accuracy. -
Page 24: Notes
Notes LTP_05_23.03_EN_U... - Page 25 LTP_05_23.03_EN_U...
- Page 26 LTP_05_23.03_EN_U...
- Page 28 Stamp of the authorised service centre HEAD OFFICE Via Della Fisica, 20 41042 Spezzano di Fiorano, Modena - Italy Tel. +39 0536 843418 - Fax +39 0536 843521 SERVICE ASSISTANCE Via Dell’Elettronica, 15 41042 Spezzano di Fiorano, Modena - Italy Tel.
