Summary of Contents for Dini Argeo TPWX2GDI
- Page 1 ATEX SAFETY INSTRUCTION TPWX2GD,TPWX2GDI,TPW20IEX2GD TPWX_ 05_17.12_EN_U...
-
Page 2: Table Of Contents
10. REFERENCE DRAWINGS.............................. 11 11. INSTRUMENT POWER SUPPLY ........................... 13 11.1 BATTERY CHARGING ............................. 13 11.2 BATTERY CONNECTION TO RECHARGER AND WEIGHT INDICATOR .............. 13 11.3 BATTERY INSTALLATION ............................16 EU DECLARATION OF CONFORMITY ..........................17 WARRANTY ..................................18 TPWX2GD/TPWX2GDI/TPW20IEX2GD... -
Page 3: Introduction
It is advisable to verify if there are any updates. the person responsible for the use of the TPWX2GD/TPWX2GDI/TPW20IEX2GD pallet truck must make sure that all the existing safety norms in the country of use are respected and guarantee that the instrument is used in conformity with the use for which it has been manufactured for. -
Page 4: Warnings
It is forbidden to connect the instrument to modules not provided for by the certification; this action compromises the intrinsic safety of the instrument (with a subsequent loss of the Ex approval). Contact Dini Argeo srl for further information. - Page 5 The TPWX2GD atex pallet truck is an atex assembly composed of the TPW atex mechanical part, the DFWATEX2GD atex weighing indicator and the atex load cell. The TPWX2GDI/TPW20IEX2GD atex pallet truck is an atex assembly composed of the TPWX2GDI atex mechanical part, the DFWATEX2GD atex weighing indicator and the atex load cell.
-
Page 6: Description Of The System
The metallic structure parts are electrically connected and a sliding chain is provided for its grounding. 5. SAFETY DATA / PLATE PARAMETERS The power supply of the Atex assemblies TPWX2GD/TPWX2GDI/TPW20IEX2GD is provided with battery (See the “DFWATEX2GD” atex weight indicator manual): ... -
Page 7: Markings
7. INSTRUCTIONS FOR INSTALLATION AND MAINTENANCE IN HAZARDOUS ZONE The Atex assemblies TPWX2GD/TPWX2GDI/TPW20IEX2GD must be installed and maintained according to the applicable standards regarding the installations and maintenance in hazardous areas (different from the mines) classified for the presence of gas as ZONE 1, and/or the presence of dusts like ZONE 21, for example: EN 60079-14 / IEC 60079-14, EN 60079-17 / IEC 60079-17, EN 1127-1 and all the standards applicable in the zone and in the installation environment. -
Page 8: Installation Example
.1 INSTALLATION EXAMPLE WE DECLINE ALL RESPONSIBILITY FOR DAMAGES CAUSED BY THE UNOBSERVANCE OF THESE WARNINGS TPWX2GD/TPWX2GDI/TPW20IEX2GD... -
Page 9: Dimensions (Mm)
PALLET TRUCK 8. DIMENSIONS (mm) 1150 1190 TPWX2GD/TPWX2GDI/TPW20IEX2GD... -
Page 10: Operating Instructions
2. If necessary add oil. Maximum filling level is 200mm below top of tank. 3. Turn on the pump to get air out of the hydraulic circuit. 4. Put cap ( 202 ), o-ring ( 11 ) and cover (204 ) back. TPWX2GD/TPWX2GDI/TPW20IEX2GD... -
Page 11: Reference Drawings
- For applications with double roller: 9000 hours of use; Once reached this time period one should substitute these with bearing of the same model (SKF6204Z). For any questions or problems check with an Authorised service Centre. 10. REFERENCE DRAWINGS 1150 TPWX2GD/TPWX2GDI/TPW20IEX2GD... - Page 12 C" D" LUBRIFICATION POINTS Ref. “K” fig. D needs silicon oil for food industry, expiry of 1 month. Ref. “P” fig. D needs silicon grease for food industry, expiry of 2 months. TPWX2GD/TPWX2GDI/TPW20IEX2GD...
-
Page 13: Instrument Power Supply
See the DFWATEX2GD atex weight indicator manual. 11.2 BATTERY CONNECTION TO RECHARGER AND WEIGHT INDICATOR Models equipped with battery also include its recharger. Both parts must be connected with their specific cables. The two connectors have specific holes for a solid connection. TPWX2GD/TPWX2GDI/TPW20IEX2GD... - Page 14 Grasp the cable terminal of the battery charger – or of the indicator – exactly in the point corresponding to its square section. Push the battery cable connector, and then turn its rotating part in the sense indicated by the arrow, until the two connectors are perfectly fitted. The connection is now done. TPWX2GD/TPWX2GDI/TPW20IEX2GD...
- Page 15 Pull the battery cable as shown in the figure. Absolutely AVOID carrying out the connection / disconnection of the cables grasping them in their external parts: there can be the risk of breaking the internal wires. TPWX2GD/TPWX2GDI/TPW20IEX2GD...
-
Page 16: Battery Installation
To install the battery in the column one should: connect the battery connector to the power supply cable install and turn the battery stops indicated in the figure NOTE: the battery DFWBP76ATEX can be connected and disconnected in explosion risk zones (ATEX ZONES). TPWX2GD/TPWX2GDI/TPW20IEX2GD... -
Page 17: Eu Declaration Of Conformity
DFWATEX2GD series electronic weighing terminal (CEC 07 ATEX 060 rev2 CE type certificate nr.) 2GD series TPW pallet truck scale (Tech. File AETF01 Dep. n° CEC-04/2036-ADF088) Dini Argeo atex load cells (CEC 07 ATEX 093 X rev2 CE type certificate nr.) TPWRAS... -
Page 18: Warranty
This warranty DOES NOT provide for any compensation for losses or damages incurred by the Customer due to complete or partial failure of instruments, even during the warranty period. AUTHORIZED SERVICE CENTRE STAMP TPWX2GD/TPWX2GDI/TPW20IEX2GD...
