Workstation Bracket Attachment
Hook the Mounting Bracket
Slide bracket forward, then
1
2
over the vertical extrusion.
down onto V4 connector.
V4 connectors stay permanently
attached to vertical extrusion.
Mounting
Bracket
Extrusion
TOP VIEW
Workstation Assembly
1) Attach threaded studs on underside
of Counter Top to Counter Legs; secure
with wing nuts.
2) Connect Counter Top to Mounting Bracket,
using wing nuts.
Counter Top
Threaded
Studs
Wing
nuts
Counter
Legs
UNDERSIDE VIEW
Symphony SYM-400 Portable Counter
Tighten thumb screws to
3
secure connection to inside
of frame.
Slide down onto
V4 connector
Slide
Bracket
forward
Bracket
V4
Tighten knobs
SIDE VIEW
to secure.
Mounting
Bracket
*
Workstation
SETUP INSTRUCTIONS
If you would like to tell us about your experience with your setup instructions please email us at info@classicexhibits.com
Steps:
1) Attach Workstation Mounting Bracket
to backwall vertical as shown.
See
Workstation Bracket Attachment
detail.
2) Assemble Workstation legs & counter top to
bracket. See
Workstation Assembly
detail.
