BLAUBERG Ventilatoren BLAUBOX EC ME 300 S30 User Manual

Single-block air supply unit
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Single-block air Supply unit
BLAUBOX EC ME 300 S30/31/32
BLAUBOX EC ME 400 S30/31/32
BLAUBOX EC ME 700 S30/31/32
BLAUBOX EC ME 1000 S30/31/32
BLAUBOX EC ME 1500 S30/31/32
BLAUBOX EC ME 2000 S30/31/32
BLAUBOX EC ME 3000 S30/31/32
BLAUBOX EC ME 4000 S30/31/32
EN
USER'S MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BLAUBOX EC ME 300 S30 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for BLAUBERG Ventilatoren BLAUBOX EC ME 300 S30

Summary of Contents for BLAUBERG Ventilatoren BLAUBOX EC ME 300 S30

  • Page 1 Single-block air Supply unit BLAUBOX EC ME 300 S30/31/32 BLAUBOX EC ME 400 S30/31/32 BLAUBOX EC ME 700 S30/31/32 BLAUBOX EC ME 1000 S30/31/32 BLAUBOX EC ME 1500 S30/31/32 BLAUBOX EC ME 2000 S30/31/32 BLAUBOX EC ME 3000 S30/31/32 BLAUBOX EC ME 4000 S30/31/32...

  • Page 2: Table Of Contents

    blauboX ec Me 300/400/700/1000/1500/2000/3000/4000 S30/31/32 www.blaubergventilatoren.de CONTENTS Safety requirements ..................................3 Purpose ........................................ 5 Delivery set ......................................5 Designation key ....................................5 Technical data ....................................6 Design and operating principle ............................9 Mounting and set-up .................................. 13 Connection to power mains ..............................15 Technical maintenance ................................

  • Page 3: Safety Requirements

    blauboX ec Me 300/400/700/1000/1500/2000/3000/4000 S30/31/32 www.blaubergventilatoren.de SAFETY REQUIREMENTS This unit is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the unit by a person responsible for their safety. Children should be supervised to ensure that they do not play with the unit.
  • Page 4 blauboX ec Me 300/400/700/1000/1500/2000/3000/4000 S30/31/32 www.blaubergventilatoren.de All operations described in this manual must be performed by qualified personnel only, properly trained and qualified to install, make electrical connections and maintain ventilation units. Do not attempt to install the product, connect it to the mains, or perform maintenance yourself. This is unsafe and impossible without special knowledge.

  • Page 5: Purpose

    blauboX ec Me 300/400/700/1000/1500/2000/3000/4000 S30/31/32 www.blaubergventilatoren.de PURPOSE The unit is intended for filtering, supplying and heating purified intake air in offices, hotels, cafés, conference halls, manufacturing facilities, retail establishments and other residential and public spaces. The unit is a component part and is not designed for stand-alone operation. Transported air must not contain any flammable or explosive mixtures, evaporation of chemicals, sticky substances, fibrous materials, coarse dust, soot and oil particles or environments favourable for the formation of hazardous substances (toxic substances, dust, pathogenic germs).

  • Page 6: Technical Data

    The unit design is constantly being improved, thus some models may be slightly different from those described in this manual. Overall and connection dimensions of the models BLAUBOX EC ME 300 S30/31/32, BLAUBOX EC ME 400 S30/31/32, BLAUBOX EC ME 700 S30/31/32 Model øD...
  • Page 7 blauboX ec Me 300/400/700/1000/1500/2000/3000/4000 S30/31/32 www.blaubergventilatoren.de Overall and connection dimensions of the models BLAUBOX EC ME 1000 S30/31/32, BLAUBOX EC ME 1500 S30/31/32, BLAUBOX EC ME 2000 S30/31/32, BLAUBOX EC ME 3000 S30/31/32, BLAUBOX EC ME 4000 S30/31/32 (without side panels) Model BLAUBOX EC ME 1000 S30/31/32 BLAUBOX EC ME 1500 S30/31/32...
  • Page 8 blauboX ec Me 300/400/700/1000/1500/2000/3000/4000 S30/31/32 www.blaubergventilatoren.de Overall and connection dimensions of the models BLAUBOX EC ME 1000 S30/31/32, BLAUBOX EC ME 1500 S30/31/32, BLAUBOX EC ME 2000 S30/31/32, BLAUBOX EC ME 3000 S30/31/32, BLAUBOX EC ME 4000 S30/31/32 (with side panels) Model BLAUBOX EC ME 1000 S30/31/32 BLAUBOX EC ME 1500 S30/31/32...

  • Page 9: Design And Operating Principle

    blauboX ec Me 300/400/700/1000/1500/2000/3000/4000 S30/31/32 www.blaubergventilatoren.de DESIGN AND OPERATING PRINCIPLE The unit is housed in a sound-insulated galvanized steel casing (item 1). The unit casing has 4 mounting brackets with anti- vibration connectors for ceiling or wall mounting (item 5). The air flow direction is indicated by the arrow on the fan casing.
  • Page 10 blauboX ec Me 300/400/700/1000/1500/2000/3000/4000 S30/31/32 www.blaubergventilatoren.de TOP VIEW BLAUBOX ... L BLAUBOX ... R The figure below shows the internals of the left and right version of the units with the removable cover removed. The air flow direction is indicated by the arrows. •...
  • Page 11 blauboX ec Me 300/400/700/1000/1500/2000/3000/4000 S30/31/32 www.blaubergventilatoren.de BOTTOM VIEW BLAUBOX ... L BLAUBOX ... R...
  • Page 12 blauboX ec Me 300/400/700/1000/1500/2000/3000/4000 S30/31/32 www.blaubergventilatoren.de The unit supplies heated and filtered outdoor air into the room. The unit uses a frameless centrifugal fan directly driven by an external rotor motor. The fan impeller blades are curved backwards. The motor has built-in thermal protection and requires no maintenance. After filtration, the air passes through the block of heaters.

  • Page 13: Mounting And Set-Up

    The units are installed between the ducts, taking into account the direction of air flow, which is indicated by an arrow on the casing. Units BLAUBOX EC ME 300 S30/31/32, BLAUBOX EC ME 400 S30/31/32, BLAUBOX EC ME 700 S30/31/32 have spigots for connecting to air ducts with round cross-section.
  • Page 14 blauboX ec Me 300/400/700/1000/1500/2000/3000/4000 S30/31/32 www.blaubergventilatoren.de Moving the control unit to the opposite side of the casing If you want to move the control unit before connecting the unit to the power supply and external devices, perform the below steps in the following order: 1.

  • Page 15: Connection To Power Mains

    blauboX ec Me 300/400/700/1000/1500/2000/3000/4000 S30/31/32 www.blaubergventilatoren.de CONNECTION TO POWER MAINS The connection must be made using durable, insulated and heat-resistant conductors (cables, wires). The external power input must be equipped with an automatic circuit breaker built into the stationary wiring to open the circuit in the event of overload or short-circuit.
  • Page 16 blauboX ec Me 300/400/700/1000/1500/2000/3000/4000 S30/31/32 www.blaubergventilatoren.de To connect the power supply and external devices, unscrew the two screws on the cover of the control unit and remove the cover, as shown in the figure in the «Mounting and set-up» section. Lead the power supply cable and the cables for connecting the control panel and the outdoor temperature sensor through the cable glands in the control unit and connect them according to the wiring diagram.
  • Page 17 blauboX ec Me 300/400/700/1000/1500/2000/3000/4000 S30/31/32 www.blaubergventilatoren.de BLAUBOX EC ME 700-3.0, BLAUBOX EC ME 700-6.0 EC, BLAUBOX EC ME 700 E-9.0, BLAUBOX EC ME 1000-6.0, BLAUBOX EC ME 1000-12.0, BLAUBOX EC ME 1500-9.0, BLAUBOX EC ME 2000-12.0 3,15А 3,15А L1 L2 L3 SM_L SM_L1 SM_N K2:A2 K2:A1 Сom NO 0,5А...
  • Page 18 blauboX ec Me 300/400/700/1000/1500/2000/3000/4000 S30/31/32 www.blaubergventilatoren.de BLAUBOX EC ME 2000-24.0 3,15А 3,15А L1 L2 L3 SM_L SM_L1 SM_N K2:A2 K2:A1 Сom NO 0,5А 0,5А 2,5А 2,5А 1А 1А L1 L2 L3 F3 F4 1 PD2* Power input М2* SM1*/SM2* SM1*/SM2* ~380V, 50Hz X3 X3 X3 X3 X3 X3 X3 А1 X3...
  • Page 19 blauboX ec Me 300/400/700/1000/1500/2000/3000/4000 S30/31/32 www.blaubergventilatoren.de BLAUBOX EC ME 4000-24.0 3,15А 3,15А L1 L2 L3 K2:A2 K2:A1 Сom NO 0,5А 0,5А 5А 1А 1А 5А SM_L SM_L1 SM_N L1 L2 L3 PD2* Power input М2* SM1*/SM2* SM1*/SM2* ~380V, 50Hz X3 X3 X3 X3 А1 X3 X3 X3 X3 X3 А1 X3 А1 А1...
  • Page 20 blauboX ec Me 300/400/700/1000/1500/2000/3000/4000 S30/31/32 www.blaubergventilatoren.de BLAUBOX EC ME 4000-45.0 EC, BLAUBOX EC ME 4000-54.0 5А 5А 3,15А 3,15А L1 L2 L3 SM_L SM_L1 SM_N K2:A2 K2:A1 Сom NO PE N 0,5А 0,5А 1А 1А L1 L2 L3 F2 F4 N F3 PD2* Power input...
  • Page 21 blauboX ec Me 300/400/700/1000/1500/2000/3000/4000 S30/31/32 www.blaubergventilatoren.de Configuration selection By default, the unit configuration for operating with no CCU is enabled. If the unit is used with the CCU, it is necessary to activate the appropriate configuration. To activate the selected configuration, use the pGDE control. For units with the S30 and S31 automatic control system, this remote control must be connected only for the duration of the configuration activation.

  • Page 22: Technical Maintenance

    blauboX ec Me 300/400/700/1000/1500/2000/3000/4000 S30/31/32 www.blaubergventilatoren.de TECHNICAL MAINTENANCE DISCONNECT THE UNIT FROM POWER SUPPLY BEFORE ANY MAINTENANCE OPERATIONS! MAKE SURE THE UNIT IS DISCONNECTED FROM POWER MAINS BEFORE REMOVING THE PROTECTION. PRIOR TO COMMENCING ANY TECHNICAL MAINTENANCE PUT UP A PROHIBITORY SIGN ON THE FAN STARTING PANEL: “DO NOT SWITCH ON! MEN AT WORK!”...

  • Page 23: Troubleshooting

    blauboX ec Me 300/400/700/1000/1500/2000/3000/4000 S30/31/32 www.blaubergventilatoren.de TROUBLESHOOTING Problem Possible reasons Troubleshooting Make sure the power supply line is connected No power supply. correctly, otherwise troubleshoot a connection error. Disconnect the fan from power supply. Troubleshoot The unit does not start. Jammed motor.

  • Page 24: Manufacturer's Warranty

    blauboX ec Me 300/400/700/1000/1500/2000/3000/4000 S30/31/32 www.blaubergventilatoren.de MANUFACTURER’S WARRANTY The product is in compliance with EU norms and standards on low voltage guidelines and electromagnetic compatibility. We hereby declare that the product complies with the provisions of Electromagnetic Compatibility (EMC) Directive 2014/30/EU of the European Parliament and of the Council, Low Voltage Directive (LVD) 2014/35/EU of the European Parliament and of the Council and CE-marking Council Directive 93/68/EEC.
  • Page 25 blauboX ec Me 300/400/700/1000/1500/2000/3000/4000 S30/31/32 www.blaubergventilatoren.de...
  • Page 26 blauboX ec Me 300/400/700/1000/1500/2000/3000/4000 S30/31/32 www.blaubergventilatoren.de...

  • Page 27: Certificate Of Acceptance

    blauboX ec Me 300/400/700/1000/1500/2000/3000/4000 S30/31/32 www.blaubergventilatoren.de CERTIFICATE OF ACCEPTANCE Unit Type Single-block air supply unit Model Serial Number Manufacture Date Quality Inspector’s Stamp SELLER INFORMATION Seller Address Phone Number E-mail Purchase Date This is to certify acceptance of the complete unit delivery with the user’s manual. The warranty terms are acknowledged and accepted.
  • Page 28 www.blaubergventilatoren.de B263EN-03...

This manual is also suitable for:

Blaubox ec me 300 s31Blaubox ec me 300 s32Blaubox ec me 400 s30Blaubox ec me 400 s31Blaubox ec me 400 s32Blaubox ec me 700 s30 ... Show all
