axing basic-line BVS 1-01P Operation Instructions page 3

 Observe the safety instructions supplied with the device!
They are also available at the following Internet address:
https://download.axing.com/BAs/Sicherheitshinweise_9sprachig.pdf
 Use the device only as described in these operating instructions and in
particular in accordance with the state of the art.
If the device is used for other purposes, no warranty will be assumed!
Commission regulation (EU) 2019/1782
External plug-in power supply
Manufacturer's name or trademark Channel Well Technology Co Ltd
commercial registration number and 222 Sec 2 Nankan Rd, Lujhu Township Taoyuan
address Hsien, 33855 Taiwan | 84573516
Model identifier 1edo HPS34-1200300ABE
Input voltage
Input AC frequency
Output voltage
Output current
Output power
Average active efficiency
Load condition 1 – 100 % ±2 %
Load condition 2 – 75 % ±2 %
Load condition 3 – 50 % ±2 %
Load condition 4 – 25 % ±2 %
Efficiency at low load (10 %)
No-load power consumption
EU Declaration of Conformity
Hereby AXING AG declares that the CE marked products comply with the
valid EU guidelines.
WEEE Nr. DE26869279 | Electrical and electronic components must not be
disposed of as residual waste, it must be disposed of separately.
Technical improvements, changes in design, printing and other errors reserved.
Page 1 of 2 | AXING-BA_BVS-1-01P | 2023-11-27
Technical data:
Type
Downstream
Frequency range
Gain
Downstream#Max. output level 80 channels PAL +
QAM (up to 1218 MHz, flat, CSO/CTB = –70/–64 dBc)
Return loss
Noise figure typ.
Upstream
Frequency range
Attenuation
RF connectors
Type
100 ... 240 VAC
General
50 ... 60 Hz
Operating voltage
12.0 V
Power consumption
0.3 A
Operating temperature range (acc. to EN 60065)
3.6 W
Dimensions (W × H × D) appr.
82 %
Weight
82 %
External accessories
82 %
Switching power supply
80 %
70 %
60 mW
Manufacturer
AXING AG
Gewerbehaus Moskau
8262 Ramsen
BVS 1-01P
258 ... 1218 MHz
15 dB
85 dBµV
≥ 18 dB
4 dB BVS 1-01P
5 ... 204 MHz
basic-line
−1 dB
F-female CATV
12 VDC
Subscriber amplifier
2.8 W
−40 ... +60 °C
90 × 112 × 23 mm
Operation instructions
0.246 kg
100 ... 240 V~ / 50 ... 60 Hz
12 V= / 0.3 A
EEA contact address
Bechler GmbH
Am Rebberg 44
78239 Rielasingen
