Summary of Contents for Generalscan Thumbutton Scanner R152 Series
- Page 1 CONFIGURATION MANUAL...
-
Page 2: Service Information
Copyright GENERALSCAN reserves the right to make changes to any product to improve reliability, function, or design. GENERALSCAN does not assume any product liability arising out of, or in connection with, the application or use of any product, circuit, or application described herein. - Page 3 Bluetooth HID Mode Step 1. The Bluetooth HID mode is a Bluetooth keyboard. When you scan the barcode, the data will be output at the cursor of the text. The blue LED of your device is fast blinking. This means that the device is in pairing mode (HID mode).
- Page 4 Step 4. Please open a notebook app on your phone, when you scan a barcode the data will appear at the tip of the cursor. The barcode below is the test barcode. Generalscan (Test Barcode)
- Page 5 Please scan Bluetooth SPP Mode barcode. The blue LED of your scanner is slow blinking. This means that the device is in pairing mode (SPP mode). Step 2. Please open the application and ´Turn on Bluetooth´ then please change the keyboard with Generalscan Keyboard.
- Page 6 Bluetooth SPP Mode Step 3. Please click to Step 4. Please click to Step 5. Please click to ´Connect Scanner´, ´Bluetooth Scanner´, ´Go select´ Step 6. Choose your Step 7. Enter PIN ´Barcode Scanner´ ´1234´ and click next step ´1234´ Step 8.
- Page 7 The blue LED of your scanner is 2 fast and 1 slow blinking. This means that the device is in pairing mode (BLE mode). Step 2. Please open the application and ´Turn on Bluetooth´ then please change the keyboard with Generalscan Keyboard.
- Page 8 Bluetooth BLE Mode Step 3. Please click to Step 4. Please click to Step 5. Please click to ´Connect Scanner´, ´Bluetooth Scanner´, ´Go select´ Step 6. Choose your Step 7. You will able ´Barcode Scanner´ to see your data in your device.
- Page 9 USB-HID Mode The USB-HID mode is a USB keyboard. When you scan the barcode, the data will be output at the cursor of the text. Step 1. Please scan USB-HID Mode barcode; Step 2. Then connect your device to your computer with the USB cable that comes in the box.
- Page 10 USB-HID Mode Step 3. When your connection is successfull, you will hear 3 beeps from your barcode scanner. After that, you can open a text file or your own software on your computer and display your data at the tip of the cursor.
- Page 11 Bluetooth adaptor GDA201 to use this mode. You can purcha- se the Bluetooth adaptor by scanning the QR code below with your Phone´s camera. Bluetooth SPP Master Mode GDA 201 For using this modes, please contact us. Support@generalscan.cloud...
-
Page 12: Suffix Settings
Suffix Settings You can Enable or Disable the suffix by scanning the following barcodes. The default suffix is CR and LF. Disable Suffix Enable Suffix (*) - Page 13 Special Suffix Settings You can change to a different suffix by scanning the following barcodes. CR LF(*) SPACE...
- Page 14 Offline Storage Mode Offline storage mode is for storing scanned barcodes in the scanner when Bluetooth is not connected, and can then be uploaded uniformly. You can enable or disable offline storage mode by scanning the following barcodes. Enable Offline Storage Mode Disable Offline Storage Mode(*) You can get the number of stored barcodes and clear the stored records by scanning the barcodes on the next page.
- Page 15 Offline Storage Mode Fast Speed Upload Middle Speed Upload Low Speed Upload Barcode Storage Information Clear Barcode Storage...
-
Page 16: Auto-Trigger Mode
Auto-Trigger Mode You can turn on auto-trigger mode at different intervals, and auto- trigger mode does not go into hibernation. Disable Auto Trigger(*) 1 Second Auto Trigger 2 Second Auto Trigger 5 Second Auto Trigger... - Page 17 Hardware Informations You can access your device's software version, ID, battery level and serial number by scanning the barcodes below. Make sure your barcode scanner is connected to a device to view the data. Firmware Version Device ID Battery Level Serial Number...
-
Page 18: Vibration Level
Vibration Level You can set the vibration level by scanning the following barcodes, only for the R-Series. Vibration Off Level 1 Level 2 Level 3 (*) Level 4... - Page 19 DFU Mode Please scan the barcode below to switch to Device Firmware Update mode. After scanning this barcode, make sure that the blue and green LEDs of your device are constantly lit in sequence. Enter DFU Mode To download the software for upgrade application to your phone, you can scan the QR Code below with your phone´s camera and access the application on our website.
- Page 20 Press the trigger button to connection in HID mode? automatically connect back. Please use SPP mode and How can I change keyboard use Android Generalscan language? Keyboard Pro APP. Our all model´s default has How the scanner power hibernation, you don´t need consumption is controlled? to set.
- Page 21 Question Solution Why the buzzer makes a Indicates that the scanner is low-frequency sound and out of service and needs to shuts down or cannot be be charged. power on? The actual scan usage time is Why does the scanner take related to the frequency of a short time to use? use.
-
Page 22: Default Factory Setting
Default Factory Setting You can restore the default factory settings by scanning the following barcode. Default Factory Settings Service Information If you have a question with your GENERALSCAN barcode scanner, please visit our service page for assistance www.generalscan.cloud/services... - Page 23 QUICK CONFIGURATION MANUAL Email: Support@generalscan.cloud ©2024 GENERALSCAN All rights reserved. Version 1.2 858371682024...
