Generalscan R552 Series Quick Start Manual

Hide thumbs Also See for R552 Series:

Advertisement

Quick Links

Download this manual
Flexgrip-wired
GS GHR202
QUICK START GUIDE
EN

Advertisement

loading
Need help?

Need help?

Do you have a question about the R552 Series and is the answer not in the manual?

Questions and answers

Related Manuals for Generalscan R552 Series

Summary of Contents for Generalscan R552 Series

  • Page 1 Flexgrip-wired GS GHR202 QUICK START GUIDE...
  • Page 2 If any further questions, please contact support@generalscan.cloud COPYRIGHT GENERALSCAN reserves the right to make changes to any product to improve reliability, function, or design. GENERALSCAN does not assume any product liability arising out of, or in connection with the application or use of any product, circuit, or application described herein.
  • Page 3 FEATURES Lanyard Hole Trigger Button Lanyard Hole Scanner Slot Data Transmission contacts...

  • Page 4: Cable Connection

    FEATURES RJ45 Slot Cable Stopper ScannerTightening Knob Plug CABLE CONNECTION Step1. Insert RJ45 cable terminal into the RJ45 jack on Flexgrip. USB Cable (PN : 886783051001) for GHR202-S/L-RJ45/USB RS232 Cable (PN : 886783056001) for GHR202-S/L-RJ45/RS232...
  • Page 5 CABLE CONNECTION Step2. Loosen the screw on the cable stopper using a screw- driver. Step3. Slide cable stopper into the position of locking the harness. Step4. Tighten the screw on the cable stopper using a screwdriver.
  • Page 6 ASSEMBLE THE SCANNER Step1. Remove the plug by unscrewing the tightening knob plug ① and remove the plug. TOP view of scanner tightening knob plug Step2. Expose the scanner tightening knob plug. Both the tightening knob and the metal plate are locked. Metal plate locked Tightening knob locked Step3.
  • Page 7 ASSEMBLE THE SCANNER Step4. ①Insert the scanner into the slot on the handle. ②Then push the scanner forward to fit it well with the handle. CHR202-S is for GS R152# & GS R352# GHR202-L is for GS R1120 & GS R552# Step5.
  • Page 8 REMOVE OUT THE SCANNER Step1. Remove the fastening knob plug by snapping downward at the position ①. TOP view of scanner tightening knob plug Step2. Expose the scanner tightening knob plug. Both the scanner tightening knob and the metal plate are unlocked. Metal plate locked Tightening knob locked Step3.
  • Page 9 REMOVE OUT THE SCANNER Step4. ①Push the scanner backward. ②At the same time, remove out the scanner by lifting upward. Step5. Move the scanner tightening knob counterclockwise to the locked position. Step6. Assemble back the scanner tightening knob plug. Firstly assemble ②③, then assemble ④.

  • Page 10: Data Output Mode

    SCANNER POWER ON AND POWER OFF Press the yellow trigger button for about 3 seconds, the scanner is powered on. The scanner turned off automatically when power is disconnected. DATA OUTPUT MODE GHR202-#-RJ45/USB refer to the picture as below USB Cable PN: 886783051001 1.
  • Page 11 SCANNER POWER ON AND POWER OFF 2. USB COM Mode Step1. Connect the USB-A Cable Step2. Scan the barcode below, enter into USB COM mode. USB COM Mode Step3. Open a serial software, data will be output in the serial software when scanning barcode.
  • Page 12 Beep 2 times Decode Successfully Green light blinks once Beep once RESOURCE DOWNLOAD For more information on product configurations, software, user guides, etc., please download from the website below: https://www.generalscan.cloud/resourcedownload Q & A Question Solution Case Why does the Please reconeect cables...
  • Page 13 Service Information If you have any question of your GENERALSCAN product, please visit our service page for assistance. www.generalscan.cloud/services QUICK START GUIDE Email: Support@generalscan.cloud ©2024 GENERALSCAN All rights reserved Version 1.0 8 8 6 7 8 3 0 5 4 0 0 1...
