- Page 1 CONFIGURATION MANUAL For R1522, R5523...
-
Page 2: Service Information
Copyright GENERALSCAN reserves the right to make changes to any product to improve reliability, function, or design. GENERALSCAN does not assume any product liability arising out of, or in connection with, the application or use of product, circuit, or application described herein. - Page 3 Bluetooth HID Mode Step 1. The Bluetooth HID mode is a Bluetooth keyboard. When you scan the barcode, the data will be output at the cursor of the text. The blue LED on your scanner is fast blinking. This means that the scanner is in pairing mode (HID mode).
- Page 4 The blue light on the scanner has turned off as the connection is completed and successful. Step 4. Please open a notebook app on the mobile terminal, when you scan a barcode, its information will appear at the cursor. The barcode below is the one for testing. Generalscan (Test Barcode)
- Page 5 The blue LED on your scanner is slow blinking. This means that the scanner is in pairing mode (SPP mode). Step 2. Please open Keyboard Pro on your Android mobile device and ´Turn on Bluetooth´ on it, then change the keyboard into Generalscan Keyboard.
- Page 6 Bluetooth SPP Mode Step 3. Please click on Step 4. Please click on Step 5. Please click on ´Connect Scanner´. ´Bluetooth Scanner´. ´Go select´. Step 6. Choose your Step 7. Enter PIN ´Barcode Scanner´. ´1234´ and click next step. ´1234´ Step 8.
- Page 7 The blue LED on your scanner is 2 fast and 1 slow blinking. This means that the scanner is in pairing mode (BLE mode). Step 2. Please open Keyboard Pro on your Android mobile device and ´Turn on Bluetooth´ on it, then change the keyboard into Generalscan Keyboard.
- Page 8 Bluetooth BLE Mode Step 3. Please click on Step 4. Please click on Step 5. Please click on ´Connect Scanner´. ´Bluetooth Scanner´. ´Go select´. Step 6. Choose your Step 7. You will able to see ´Barcode Scanner´. the barcode information on your terminal device.
- Page 9 USB-HID Mode The USB-HID mode is a USB keyboard. When you scan the barcode, the data will be output at the cursor of the text. Step 1. Please scan USB-HID Mode barcode. Step 2. Then connect your scanner to your computer with the USB cable that comes in the packing box.
- Page 10 USB-HID Mode Step 3. When then connection is successfull, you will hear 3 beeps from your barcode scanner. After that, you can open a text file or your own software on your computer to scan. The information of the barcode scanned will be displayed at the cursor.
- Page 11 USB-VCP Mode To use the VCP Mode (Virtual COM Port), an application needs to be downloaded firstly. The one Generalscan suggested, except General- scan Keyboard Pro is “Serial Debug Assistant”. Please download and install it by scanning the barcode of guiding documents below. After setting, the barcode information will be output from this app.
- Page 12 Quick Pairing App Quick pairing connection of Generalscan scanners and the terminal device is available in Bluetooth HID mode and Bluetooth SPP mode. Please scan the barcode below for the methods of quickly pairing your Generalscan scanner with your terminal device.
- Page 13 Bluetooth Adaptor For wider scanning range, you will need a Bluetooth adaptor to ensure a stable Bluetooth connection. Generalscan has the GDA 201 for you. You can also get video on how to use it by scanning the barcode below.
-
Page 14: Suffix Settings
Suffix Settings To add the suffix CR or LF or Tab, please scan the following code. - Page 15 Suffix Settings To add the suffix CRLF, please scan the following code. CR LF You can disable the suffix by scanning the following code. Disable Suffix...
- Page 16 Offline Storage Mode Offline storage mode is for storing scanned barcodes in the scanner when Bluetooth is not connected, and can then be uploaded uniformly. You can enable or disable offline storage mode by scanning the following barcodes. Enable Offline Storage Mode Disable Offline Storage Mode(*) You can get the number of stored barcodes and clear the stored records by scanning the barcodes on the next page.
- Page 17 Offline Storage Mode Fast Speed Upload Middle Speed Upload Low Speed Upload Barcode Storage Information Clear Barcode Storage...
-
Page 18: Auto-Trigger Mode
Auto-Trigger Mode You can turn on auto-trigger mode at different intervals, and auto- trigger mode does not go into hibernation. Disable Auto Trigger(*) 1 Second Auto Trigger 2 Seconds Auto Trigger 5 Seconds Auto Trigger... - Page 19 Hardware Informations You can access your device's software version, ID, battery level and serial number by scanning the barcodes below. Make sure your barcode scanner is connected to a device to view the data. Firmware Version Device ID Battery Level Serial Number...
-
Page 20: Vibration Level
Vibration Level You can set the vibration level by scanning the following barcodes. Vibration Off Level 1 Level 2 Level 3 (*) Level 4... - Page 21 DFU Mode Please scan the barcode below to switch to Device Firmware Update mode. After scanning this barcode, make sure that the blue and green LEDs of your device are constantly lit in sequence. Enter DFU Mode To download the software for upgrade application to your phone, you can scan the QR Code below with your phone´s camera and access the application on our website.
- Page 22 Press the trigger button to connection in HID mode? automatically connect back. Please use SPP mode and How can I change keyboard use Android Generalscan language? Keyboard Pro APP. Our all model´s default has How the scanner power hibernation, you don´t need consumption is controlled? to set.
- Page 23 Question Solution Why the buzzer makes a Indicates that the scanner is low-frequency sound and out of service and needs to shuts down or cannot be be charged. power on? The actual scan usage time is Why does the scanner take related to the frequency of a short time to use? use.
-
Page 24: Default Factory Setting
Default Factory Setting You can restore the default factory settings by scanning the following barcode. Default Factory Settings Service Information If you have a question with your GENERALSCAN barcode scanner, please visit our service page for assistance www.generalscan.cloud/services... - Page 25 QUICK CONFIGURATION MANUAL Email: Support@generalscan.cloud ©2024 GENERALSCAN All rights reserved. Version 2.0 858371882025 For R1522, R5523...
