- Page 1 Flexgrip-wireless GS GHR201 QUICK START GUIDE...
- Page 2 If any further questions, please contact support@generalscan.cloud COPYRIGHT GENERALSCAN reserves the right to make changes to any product to improve reliability, function, or design. GENERALSCAN does not assume any product liability arising out of, or in connection with the application or use of any product, circuit, or application described herein.
-
Page 3: Scanner Features
SCANNER FEATURES Lanyard Hole Trigger Button Lanyard Hole Scanner Slot Data Transmission contacts Charging Contacts ScannerTightening Knob Plug... -
Page 4: Cradle Features
CRADLE FEATURES Green LED Button B Red LED Button A Blue LED Charging Contacts Bluetooth Address Barcode RJ45 Slot... - Page 5 LED&BUTTON FUNCTION OF CRADLE Function and Description LED and Button Green LED blinks 3 times with beep when cradle is successfully connected to the terminal via USB cable. Green LED - Green LED blinks once with beep when cradle received data Data status from scanner.
- Page 6 ASSEMBLE THE SCANNER Step1. Remove the plug by unscrewing the tightening knob plug ① and remove the plug. TOP view of scanner tightening knob plug Step2. Expose the scanner tightening knob plug. Both the tightening knob and the metal plate are locked. Metal plate locked Tightening knob locked Step3.
- Page 7 ASSEMBLE THE SCANNER Step4. ①Insert the scanner into the slot on the handle. ②Then push the scanner forward to fit it well with the handle. CHR202-S is for GS R152# & GS R352# GHR202-L is for GS R1120 & GS R552# Step5.
- Page 8 REMOVE OUT THE SCANNER Step1. Remove the fastening knob plug by snapping downward at the position ①. TOP view of scanner tightening knob plug Step2. Expose the scanner tightening knob plug. Both the scanner tightening knob and the metal plate are unlocked. Metal plate locked Tightening knob locked Step3.
- Page 9 REMOVE OUT THE SCANNER Step4. ①Push the scanner backward. ②At the same time, remove out the scanner by lifting upward. Step5. Move the scanner tightening knob counterclockwise to the locked position. Step6. Assemble back the scanner tightening knob plug. Firstly assemble ②③, then assemble ④.
-
Page 10: Data Output Mode
SCANNER POWER ON AND POWER OFF Press the yellow trigger button for about 3 seconds to power the scanner on. Press the yellow trigger button for about 5 seconds to power off the scanner, or automatically power off scanner after Bluetooth disconnected standby for 5 minutes. - Page 11 DATA OUTPUT MODE USB Mode Step 1. Connect the RJ45/USB Cable Connect the caradle with terminal device using the RJ45/USB Cable, the green LED on the cradle blinks three times with beep after successfully connected. Step 2. Connect scanner and cradle via Bluetooth Turn on scanner and scan the Bluetooth address barcode on the cradle to connect scanner and cradle.
- Page 12 DATA OUTPUT MODE GHR201-#-RJ45/RS232 refer to picture as below GHR201-#-RJ45/RS232 Data Transmission RJ45/RS232 Cable PN: 886783049001 USB port or DC5V power supply DC/USB Cable PN: 886783050001...
- Page 13 Data Bits 8 Flow Control N Stop Bits 1 RESOURCE DOWNLOAD For more information about product configurations, software, user guides, etc., please download from the website below: www.generalscan.cloud/resourcedownload Q & A Problem Possible Causes Possible Solution Why does the Cradle power supply is...
- Page 14 Service Information If you have any question of your GENERALSCAN product, please visit our service page for assistance. www.generalscan.cloud/services QUICK START GUIDE Email: Support@generalscan.cloud ©2024 GENERALSCAN All rights reserved Version 1.0 8 8 6 7 8 3 0 5 5 0 0 1...
