ERICO CADDY CSBEZU Series Instruction Sheet

INSTRUCTION SHEET
CSBEZU
Easy Universal Sway Brace or Restraint Device
Sway Brace Fitting
*(XX) = Finish Specifier.
Sway Brace assemblies are intended to be installed in accordance with
NFPA ® -13 and the manufacturer's installation instructions.
The required type, number, and size of fasteners used for the structure
attachment fitting shall be in accordance with NFPA-13.
WARNING:
1. ERICO products shall be installed and used only as indicated in ERICO product instruction sheets and training materials.
www.erico.com and from your ERICO customer service representative.
2. ERICO products must never be used for a purpose other than the purpose for which they were designed or in a manner that exceeds specified load ratings.
3. All instructions must be completely followed to ensure proper and safe installation and performance.
4. Improper installation, misuse, misapplication or other failure to completely follow ERICO's instructions and warnings may cause product malfunction, property
damage, serious bodily injury and death.
5. Products that are manufactured using spring steel components shall be used only in a non-corrosive indoor environment.
6. All pipe supports, hangers, intermediate components and structural attachments must ONLY be used as described herein and are NEVER to be used for any
other purpose.
NOTE: All load ratings are for static conditions and do not account for dynamic loading such as wind, water or seismic loads, unless otherwise noted.
The customer is responsible for:
a. Conformance to all governing codes.
b. The integrity of structures to which the products are attached, including their capability of safely accepting the loads imposed, as evaluated by a qualified
engineer.
c. Using appropriate industry standard hardware as noted above.
SAFETY INSTRUCTIONS:
All governing codes and regulations and those required by the job site must be observed.
Always use appropriate safety equipment such as eye protection, hard hat, and gloves as appropriate to the application.
Dyna-Flow is a registered trademark of Allied Tube and Conduit Corporation.
EZ FLOW is a trademark of Northwest Pipe Company.
FM is a registered certification mark of FM Approvals LLC, LTD.
NFPA is a registered trademark of National Fire Protection Association, Inc.
UL is a registered trademark of UL LLC.
CADDY, CADWELD, CRITEC, ERICO, ERIFLEX, ERITECH, and LENTON are registered trademarks of ERICO International Corporation.
TECHNICAL SUPPORT:
www.erico.com
Installation Angle
from Vertical
* All Brace and
Service Pipes
shown, not
included
CFS386_H 1 OF 17
Lateral
© 2009, 2011, 2012, 2013, 2014 ERICO
International Corporation.
Longitudinal
Instruction sheets are available at
