Homelegance 9630BE-2R Assembly Instruction Manual

Legs and hardware are stored in the box,please
NOTE:Do not use power tools for assembly. Power tools increase
the risk of over tightening which lead to splitting or cracking the
wood.
2R
M
LC
G
G
K
ASSEMBLY INSTRUCTION
ITEM NO:9630BE-2R
RSF 2-seater seat base with pull-out bed, 2 arms with Shelves back rest for 2R and
USB ports, （ Pilllow and Back rest are stored in LC ）
Left Side Chaise with Hidden Storage, （ Lsf arm and Lsf back cushion are stored in
2-seater ）
take out for assembly
Location of KD parts
F
A
B
C
J
H
9630BE-LC
BOX
Dx6
Ex4
Ix4
Lx3
Ox12
Nx16
Page 1/7
2-SEATER PART LIST
Description
No.
POP-UP
A
SLEEPER SEAT
LSF ARM
B
(Arm for LC)
C
RSF ARM
ROUND PLASTIC LEG
D
50x50x50mm
E
CASTOR
F
BACK CUSHION RSF
PILLOW 18"x18"
G
(Packed in LC)
BACK REST
H
(Packed in LC)
I
METAL BRACKET
CHAISE PART LIST
No. Description
J
CHAISE SEAT
K
BACK REST
PLASTIC LEG
L 150x50x50mm
(packed in 2R)
BACK CUSHION LSF
M
(packed in 2R)
METAL BRACKET
I
(packed in 2R)
PILLOW 18"x18"
G
ROUND PLASTIC LEG
D
50x50x50mm(packed in 2R)
HARDWARE LIST :
Diagram
No. Description
O
SCREW
Ø8x45MM
N
SCREW
Ø8x25MM
Diagram Quantity
1
1
1
4
4
1
1
1
2
Diagram Quantity
1
1
3
1
2
1
2
Quantity
12
16
Not Included
