- Page 1 V-TUF 240 MOD ELECTRIC INDUSTRIAL MOBILE STAINLESS STEEL COLD WATER PRESURE WASHER Please read this manual before using the VTUF240MOD...
- Page 2 CONTENTS Important safety Instructions Safety Features & Security Norms Technical Data Pre-Use and Maintenance Use of the machine 12-13 Transport & Lifting 14-16 Troubleshooting 17-19 Accessories & Part List XHDH300SS Super Series Pump...
- Page 3 High pressure hoses, fittings and couplings are important for the safety of the appliance. Use only hoses, fittings and couplings recommended by V-TUF. Always wear suitable eye, face and body protection. Do not operate the machine when fatigued or under the influence of alcohol or drugs.
- Page 4 United Kingdom. Modification of Terms: V-TUF reserves the right to modify or amend the terms and conditions of this warranty at any time without prior notice. Packaging The packing materials and any parts replaced during maintenance should be collected and sent to a specialist waste disposal firm (wood, plastic, metal etc.) and not left...
- Page 5 Delivery The transport will be carried out by qualified companies. The merchandise travels under the full responsibility of the transporter and the user; in the event of an accident, or late delivery, the manufacturer accepts no liability. Checks Upon receipt of the goods, check the condition that they are in. Should they appear damaged, avoid any type of installation and immediately advise the transporter and the supplier.
- Page 6 Prior to use, please carefully read the instructions, paying particular attention to "IMPORTANT RECOMMENDATIONS", "SECURITY NORMS" and "PRECAUTIONS". It is forbidden to remove or tamper with the protective parts of the machine. It is forbidden to use inflammable, explosive or toxic substances. It is obligatory to use appropriate protective equipment.
- Page 7 When using the machine outdoors, do not use when it is raining Do not attempt any kind of maintenance whilst the plug is connected to any sort of power supply. Take care not to spray the machine with the water jet as this could lead to short-circuit Should you need to use an extension lead with the power supply, make sure that the connection between the extension lead and the power lead is secure and stable and conforms to standard safety norms.
- Page 8 It is strongly forbidden to carry out any operation with the machine if you are not wearing the appropriate safety equipment (protective glasses, gloves, overalls etc) as per established safety norms. During winter, and in the event of frost, it is advisable to use anti-freeze or to empty out the water from the water circuits by stopping the water supply and briefly running the pump until the water is expelled.
- Page 9 PRECAUTIONS Before activating the high pressure cleaner, make certain that the water pressure and flow supply is correct (Pressure: min. 1 Bar – Max 8 Bar. Flow/Volume is greater that the pump flow); operating the machine with insufficient / no water supply can serious damage to the machine’s waterproofing systems.
- Page 10 TECHNICAL DATA: Industrial Specification – VTUF110/240MOD WATER FLOW (LITRES PER MINUTE): PRESSURE (BAR/PSI): 100 (MAX) MOTOR POWER (1450 RPM): 2.2KW JET SIZE: T25.07OJ, T40.08OJ CHEMICAL FEATURE: LOW PRESSURE CHEMICAL SSQ JET POWER SUPPLY (VOLTAGE): 110V OR 240V WEIGHT: 55KG DIMENSIONS: (L X W X H) CM 830 X 500 X 900MM If you wish to power your pressure washer with a generator, we recommend that the generator has approximately three times the wattage of the pressure washer you...
- Page 11 By following these maintenance instructions, you can prolong the life of your V-TUF industrial pressure washer and ensure reliable performance for years to come. Regular maintenance helps prevent breakdowns, reduces repair costs, and ensures safe operation.
- Page 12 IDENTIFICATION DATA The position of the identification data of the machine 1) Identification of the machine according to EU directives. ATTENTION: Check that your VTUF240 high pressure washer has been provided with these identification details, if they have not been provided please inform your local dealer immediately.
- Page 13 USE WITH CHEMICAL PRODUCTS Turn the pressure washer off, put the relevant chemical nozzle head in the end of the lance, drop the chemical pick up into the chemical container. Turn the machine on and apply the chemical. Best Practice for chemical application When the pressure washer is detergent mode, pull the trigger and wait for the chemical to come through before applying the chemical to the surface.
- Page 14 LUBRICATION OF THE PUMP For the models VTUF240 we recommend: V-TUF Pressure Lube PL500 You should change the oil after the first 50 hours of use, and after each subsequent 500 hours of operation.
- Page 15 TRANSPORT – LIFTING – SHIFTING ATTENTION: Whenever the machine needs to be transported, it should be securely fixed with straps, cables or other suitable equipment in order to avoid accidental movement which could cause damage to people or property as well as to the machine itself. ATTENTION: Should the machine need to be lifted, it should be hooked or coupled by means of straps, or suitable lifting equipment which will safeguard the machine’s integrity.
- Page 16 STORAGE Park the machine on a flat surface. If the machine is not going to be used for an extended period of time, empty the water circuits and the fuel tank then cover the machine and store it in a place protected from atmospheric extremes.
- Page 17 Troubleshooting PROBLEMS CAUSES SOLUTIONS The pump turns but does not The pump is sucking in air. Check that the piping is airtight & watertight reach the required pressure Worn out valves Replace the valves Worn out valve seat / o’ring Replace the valve seat / o’ring Worn out or inadequate water nozzle Replace the water nozzle...
- Page 18 Presence of water in the pump Worn out oil seals. Replace the oil seals. High percentage of humidity in the Change the oil twice as often as is air. normally prescribed. Gaskets are completely worn out. Replace the gaskets. Excessive noise Air is being sucked in.
- Page 19 Worn out oil seals. Replace the oil seals. Oil discharge from between the pump body and the pump head. Excessive vibrations. Worn out or dirty valves. Replace the valves. Air is being sucked in. Check that the piping is airtight & watertight The engine does not start.
- Page 20 E1.0102KITN V-TUF HEAVY DUTY CRUSH RESISTANT PUMP SUCTION FEED HOSE KIT (2m) 3/4F and 3/4M adapter - E1.0102KITN B1.034 V-TUF PROFESSIONAL KCQ PLUG x 3/4" F - B1.034 QRG2LKIT12 2P 1000mm tufGUN TG310 LANCE KIT SSQ QR END WITH BEND B14.5720...
- Page 21 Super Series Pump XHDM300SS 12 litres/min 200 bar LUBRICATION OF THE PUMP We recommend: VTUF PL100 – OIL CAPACITY 0.42 kg You should change the oil after the first 50 hours of use, and after each subsequent 500 hours of operation.
