- Page 1 Pyro S Quick Guide V1.0.0...
- Page 3 Foreword Pyro S Thank you for choosing the wireless high-definition video transmission system. The product adopts the latest codec technology, as well as 2.4 GHz and 5 GHz wireless transmission technology, achieving a super-low latency video transmission. EN Please read this Quick Guide carefully. We wish you a pleasant experience. To obtain Quick Guide information in other languages, please scan the QR code below.
-
Page 4: Key Features
• Upon startup, a quality frequency channel will be automatically chosen. Frequency scan function on the receiver can display the current frequency status, allowing you to choose a desired channel. * The related data is based on Hollyland laboratory test results. EN-2... - Page 5 Configuration EN-3...
- Page 6 1. The quantity of the items depends on the product configuration detailed on the packing list card. 2. You can buy a transmitter, receiver, paddle antenna, rotatable cold shoe mount, DC power adapter, and screw fitting for stabilizer from Hollyland's official website based on your needs. EN-4...
- Page 7 Connection One transmitter can connect to two receivers and two mobile devices Mobile Phone HDMI/SDI OUT Monitor Receiver1 HDMI / SDI IN Transmitter HDMI/SDI OUT Monitor Receiver2 Tablet EN-5...
- Page 8 Connection One transmitter can connect to up to four receivers in Broadcast mode HDMI/SDI OUT Monitor Receiver1 HDMI/SDI IN Transmitter HDMI/SDI OUT Monitor Receiver4 EN-6...
- Page 9 Overview Transmitter HDMI 1.4 Input SMA Antenna Connector Display Screen 1/4 Screw Hole NP-F Battery Plate 3G SDI Input Up Button Power Switch USB-C Port Confirm/Menu Button DC Input (locking) Down Button EN-7...
- Page 10 Overview Receiver HDMI 1.4 Output SMA Antenna Connector Display Screen 1/4 Screw Hole NP-F Battery Plate 3G SDI Output Up Button Power Switch USB-C Port Confirm/Menu Button DC Input (locking) Down Button EN-8...
-
Page 11: Installation
Installation Transmitter 1. Install the antennas as shown in the diagram. 2. Mount the transmitter to the camera using the rotatable cold shoe mount. 3. Connect the transmitter to the camera using an HDMI cable or SDI cable. 4. Install the battery (NP-F batteries). 5. - Page 12 Installation Receiver 1. Install the antennas as shown in the diagram. 2. Mount the receiver on the tripod using the 1/4 screw hole at the bottom. 3. Install the battery (NP-F batteries). 4. Toggle the power switch downward to turn on the receiver. EN-10...
-
Page 13: Home Screen Introduction
Interface Introduction Home Screen Introduction Transmitter ① Current Group ⑥ Broadcast Mode ② Battery Level ⑦ Resolution & Frame Rate ③ Scene Mode ⑧ Frequence Channel ④ Number of Connected Receivers ⑨ Auto Frequency Hopping* ⑤ USB-C Port Status (different icons in different statuses) ⑩... -
Page 14: Entering The Menu
Interface Introduction Receiver ① Current Group ⑥ Broadcast Mode ② Battery Level ⑦ Resolution & Frame Rate ③ Scene Mode ⑧ Frequence Channel ④ Connection Number & Signal Strength ⑨ Auto Frequency Hopping* ⑤ USB-C Port Status (different icons in different statuses) ⑩... - Page 15 Funtions Introduction Transmitter functions description Scene Mode Group Pairing Net Information Provides different Transmitter and receivers Views Wi-Fi scene modes to meet in the same group information. your needs. automatically pair. HD Mode Fan Settings Reset Bitrate at up to Provides different fan Resets to default 12 Mbps for high-...
- Page 16 Funtions Introduction Receiver functions description Frequency Scan System Settings Language Views the current Views device-related Switches the language interference status, information and between Chinese and allowing you to choose a configures settings. English. desired channel. Group Pairing Net Information Version Information Transmitter and receivers Views Wi-Fi information.
- Page 17 Streaming Introduction Transmitter Network Streaming Introduction TYPE-A Wireless Network USB-C OTG Adapter Card 1. Connect the wireless network card to the transmitter using the USB-C OTG Adapter. 2. Observe whether there is any change in the USB-C icon. Network Connected Streaming Streaming Interrupted 3.
- Page 18 App Download and Connection 1. Hollyview download The app HollyView is available for download on Hollyland’s official website. Android users can download the app from the Google Play Store and other App Stores, while iOS users can download it from the App Store.
-
Page 19: Specifications
Specifications Transmitter Receiver • DC Input: 2.0mm Core Socket • DC Input: 2.0mm Core Socket • HDMI Input: HDMI 1.4b • HDMI Output: HDMI 1.4b Port • SDI Input: 3G SDI • SDI Output: 3G SDI • USB-C: USB 2.0 OTG •... - Page 20 Specifications HDMI Input HDMI Output SDI Output 720p50/59.94/60 720p50/59.94/60 720p50/59.94/60 1080i50/59.94/60 1080i50/59.94/60 1080i50/59.94/60 1080p23.98/24/25/29.97/30 1080p23.98/24/25/29.97/30 1080p23.98/24/25/29.97/30 1080p50/59.94/60 1080p50/59.94/60 1080p50/59.94/60 3840*2160 3840*2160 1080p30/25/24/29.97/23.98 30/25/24/29.97/23.98 30/25/24/29.97/23.98 SDI Input SDI Output HDMI Output 1080p60/59.94/50 1080p50/59.94/60 1080p50/59.94/60 1080i60/59.94/50 1080i50/59.94/60 1080i50/59.94/60 1080p30/29.97/25/24/23.98 1080p23.98/24/25/29.97/30 1080p23.98/24/25/29.97/30 720p60/59.94/50 720p50/59.94/60 720p50/59.94/60 1080psf23.98/24...
- Page 21 All copyrights belong to Shenzhen Hollyland Technology Co., Ltd. Without the written approval of Shenzhen Hollyland Technology Co., Ltd., no organization or individual may copy or reproduce part or all of any written or illustrative content and disseminate it in any form.
- Page 24 Manufacturer: Shenzhen Hollyland Technology Co., Ltd. Address: 8F, 5D Building, Skyworth Innovation Valley, Tangtou Road, Shiyan Street, Baoan District, Shenzhen, 518108, China MADE IN CHINA P/N : 3003080469...
