USER MANUAL

HDBaseT Extender (330ft/100m)with POE

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HLHC070A and is the answer not in the manual?

Questions and answers

Summary of Contents for Hollyland HLHC070A

  • Page 1: User Manual

    USER MANUAL HDBaseT Extender (330ft/100m)with POE...
  • Page 2: Maintenance

    Maintenance Please put the User Manual in the place where it's safe and easy to find when you need it. Cautions: • Do not use this product in the extreme hot, cold, dusty or humid environments. • Prevent friction with hard objects. •...
  • Page 3: Main Features

    Maintenance Product model and standard: This HD baseT extender can transfer the HDMI signal via CAT-6 cables from HD audio and video products (Blue-ray DVD, PS4, PC, STB) to HDTVs/Projectors. And supports the highest resolution is 4Kx2K (3840x2160); the max transmitting distance is lOOM (330 ft);The device also supports RS232 and Lan transmitting, wide band I R ,and support Power over catSe/6/7.
  • Page 4 Parameters: HDMI out,LAN,RS232,LINK, DC12V, HDMI In, LAN,RS 2 32,LINK, DC 12V, Interface IR IN,IR OUT IR IN,IR OlJT <lOW (IX+ RX with POE) Power <lOW [T X + RX with POE) 12V 2A DC adapter, any side of transmitter or 12V 2A DC adapter, any side of transmitter or receiver receiver...
  • Page 5: Product Introduction

    Product introduction Transmitter: --------0 0- ------­ f)---- - --- 8-- - ----- -------0 0-------- 1.H DBaseT Output Signal 2.IR Output 3.IR Input 4.Power lnput:DC 12V 5.LINK LED 6.HDMI Input 7.RS232 8.Ethernet interface Receiver: --------e 0- ------­ f)- ------- 8-------- 0-------- 1.HDBaseT input Signal 2.IR Output 3.IR Input...
  • Page 6: Installation Instructions

    Installation instructions Installation Diagram: IRout HDMI HDMI =========- Installation Details: 1.Connectyour HDMI sources and HDMI IN port of transmitter with HDMI cable (HDMI cables are not included in this product). 2.lnsert IR blast e r cable to extender TX IR OUT port. I R blaster should be close to your player or other controlled equipment. TX IR IN port can be connected an IR receiving cable.
  • Page 7 Installation instructions TX &RX LED Status: Transmitter Receiver Blue Blue Green Green...
  • Page 8: Packing List

    Packing list • 1 unit transmitter, 1 unit recerver • 1 uni t s of DC 12V 2A adapter • 2 units of IR Input and IR Output connector Distributed by UL TMALINI< SOLUTIONS SC:NSC:, CONNC:CT, SC:CUMC: Phone: 0415 468 731, Email: sales@ultralinks.com.au Suite 1A Level 2, 802 Pacific Highway, Gordon NSW 2072 www.ultralinks.com.au...
