- Page 1 HDMI Fiber Optic Extender User Manual VER: V2.0...
- Page 2 Description The HDMI Fiber optic extender provides extension of HDMI and 3D signals long distances over one fiber optic cable, it supports high resolution up to 4K*2K, EDID copy/pass-thru function. The extender can use for a wide range of applications requiring long distance transmission of high resolution with high quality by its good stability and powerful security.
-
Page 3: Specifications
2. Specifications Parameter Description Standards HDMI 1.4 Maximum pixel 225MHz clock Video Resolution range Up to 3840*2160@30Hz Connector Female HDMI type A Impedance 100Ω Interface SFP model – LC connector Fiber type Single-mode Wavelength Single-mode 1310nm Interface 10Gbps Optical bandwidth fiber HDCP + EDID passthrough single multimode fiber 300 meters;... - Page 4 3. Panel Transmitter: Receiver: Port name Description HDMI IN/OUT HDMI signal input/output EDID Copy button, Press 3 seconds, copy EDID from HDMI IN EDID display device to system .If HDMI IN interface no display connect, restore default EDID. DC/5V Power adapter socket FIBER SFP model --- LC connector LED indicator...
- Page 5 4. Package list HDMI optical fiber transmitter ………. 1 pcs HDMI optical fiber receiver ……………. 1 pcs Fiber optic module ………………………….2 pcs Power adapter …………………………………2 pcs User manual ……………………………….….. 1 pcs 5. Installation 1. Connect the provided DC power supplies to the power socket of the transmitter and the receiver, 2.
