Summary of Contents for Genius D211

  • Page 1: Table Of Contents

    4-5 Setup Mode 14-17 1-3 Operation Caution Chapter 5 Preparing Your Camera 1-4 Package Contents 5-1 Attaching the Strap 17-18 Chapter 2 Getting to Know Your 5-2 Loading Batteries 18-19 5-3 Loading and Removing Camera the Memory Card 19-21 2-1 Front View & Rear View...

  • Page 2: Chapter 1 Attention

    Copyright information Unless agreed by the right owner, all the pictures taken with this digital camera cannot be used in violation of copyright law. Moreover, when "No Photography" restriction is placed on site, you cannot record any live performance, improvisation or exhibits even for personal purpose.

  • Page 3: Operation Caution

    ● If water has entered the camera, immediately turn the power OFF and remove t he batteries. ● How to maintain your camera: 1. If the lens, LCD monitor or viewfinder surface is dirty, please use a lens brush or soft cloth to wipe the surface clean instead of touching the lens with your fingers.

  • Page 4: Chapter 2 Getting To Know Your Camera

    2 x AA Alkaline Batteries ● USB Cable ● TV –OUT Cable ● This User's Manual Chapter 2 Getting to Know Your Camera 2-1 Names of Parts Front View Flash Red-eye Reduction LED Lens Cover/ Power Button Macro Button Lens...

  • Page 5: Specifications

    Flash Button Status LED (10) Battery Cover Macro Mode LED (11) Memory Card Slot ENTER Button 2-2 Specifications ●Lens: F=7.5 mm ●Image Sensor: 1/2" CMOS with 2.0 mega pixels ●Focus: F=2.8 ●Sensitivity: ISO 100 ●White Balance: Auto, Sun, Tungsten, Fluorescent.

  • Page 6: System Requirements

    ●Recordable Image Numbers (8MB): 1280X1024 1600X1200 2048X1536 800X600 Fine 16MB Normal Power Supply: 2 x AA Alkaline Batteries or supports CRV-3, USB 5V (PC -CAM ● Mode) ●Dimensions: 93 x 56 x 38 mm ●Weight: About 120g (batteries excluded) 2-3 System Requirements...

  • Page 7: Chapter 3 Controls, Operation, And Display

    English recommend that you use a computer system that exceeds the minimum requirements in order to utilize the camera at its optimum efficiency. The minimum system requirement for the digital camera is as follows: System Requirement Microsoft Windows 98SE/Me/2000/XP Intel Pentium 166MHz or higher...

  • Page 8: Power Supply

    ●Slide the lens cover toward right gently and turn off the camera. ●Use the lens cover located on the front of the camera to turn on/off camera. After you turn on the camera, the red LED will be blinking, and then the last image recorded appears on the LCD monitor.

  • Page 9: Shutter Button

    8.PC Mode 3-4 Shutter Button This camera is designed for 2-step shutter function. A "[ ]" mark will appear on the center position on the LCD monitor when you press and hold the Shutter button down half way. Then press the Shutter button down fully and the camera beeps;...

  • Page 10: Menu/Enter Button

    Standard à Full Display à Image Only à LCD Monitor Off à Only Operation Settings à Standard 2.Press the " M ode Display Button" to enter the " P lay Mode" to view the images when the camera is powered off.

  • Page 11: Chapter 4 Navigating Modes And Menus

    English ※If you selected the Macro Mode when using the camera, the flash off function will be enabled automatically. Chapter 4 Navigating Modes and Menus 4-1 Mode Selection 4-2 Record Mode à For more information, please refer to the "LCD Monitor...

  • Page 12: Play Mode

    English Image Resolution: 4-3 Play Mode (1) Possible number of shots (2) Remaining battery power...
  • Page 13 Start Auto Play 3. DPOF (Digital Print Order Format) Settings ●With DPOF for printing your images, there are three options for you: print one image, print all images and print the recorded date or not. ●DPOF function can only be operated with the printer settings of the memory card inserted, not active with internal memory.

  • Page 14: Movie Mode

    English Page Up Page Down 4-4 Movie Mode (1) Movie Mode (2) Recorded Movie Time (seconds) (3) Recording the movie pictures (4) Remaining battery power (5) Time/Date 4-5 Setup Mode 1. Image Resolution 2048x1536 1600x1200 640x480 1280x1024...
  • Page 15 English 2. Image Quality: (Fine Quality) (Basic Quality) 3. Self-timer (On) (Off) 4. White Balance: (Auto) (Sun) (Fluorescent) (Tungsten)
  • Page 16 English 5. EV Compensation 6. OSD Language 7. Date / Time 8. TV-Out Operation...

  • Page 17: Chapter 5 Preparing Your Camera

    Select the correct frequency type (50Hz or 60Hz) according to your region. 10. Format Media ※If there is a memory card inserted, it will only format the memory card, not the internal memory. 11. Reset to default factory anticipated settings...

  • Page 18: Loading Batteries

    Insert 2 x AA alkaline batteries or a rechargeable battery. Please make sure the batteries are full of power. If the batteries are in low power, please change new batteries as soon as possible to keep the camera operating normally.

  • Page 19: Loading And Removing The Memory Card

    NOTE: Do not open the cover roughly to avoid damaging the battery compartment cover. Ø If the battery power indicator shows only one black block that means that power is available, and you can continue to use the flash. Ø When the battery indicator turns red, you cannot take still and movie pictures any more.
  • Page 20 ●Pull the memory card out with your fingers in the correct direction. NOTE: Before using the camera, please remember to insert the memory card into the slot. If the memory card is full or there are already images stored in it, you can turn the...

  • Page 21: Setting Up The Osd Language

    ●The specification of memory card applicable to this camera is SD or MMC (4/8/16/32/64/128MB). ●If inserting the memory card in the wrong direction, it will not fit. Do not insert the card roughly to avoid damage. ●If the camera detects no memory card, please gently wipe the metal interface of the card with a soft cloth and reloading the card again.

  • Page 22: Record Mode

    1. Turn the Mode Dial to Record Mode 2. Using the lens cover located on the front of the camera to turn on the camera. After turn on the camera, then the last image recorded appears on the LCD monitor.

  • Page 23: Play Mode

    ※ The DPOF function can only be operated with the memory card inserted. ※ If there is no image stored in the internal memory or on the memory card, a “ No picture” message pops up on the LCD Monitor in the Play Mode.

  • Page 24: Movie Mode

    1. Turn the Mode Dial to Movie Mode 2. Use the lens cover located on the front of the camera to turn on the camera. After you turn on the camera, the last image recorded appears on the LCD monitor.
  • Page 25 English Turn your PC on if it isn’t already on. Click the Start button in the Windows Taskbar, and select Programs > ArcSoft VideoImpression > VideoImpression. The following VideoImpression main screen will appear.
  • Page 26 English Click the New button and the following Album screen will appear.

  • Page 27: Tv-Out Operation

    If you want to stop capturing, press ESC or click on Pause 6-6 TV-Out Operation Using the TV-Out function offered by the camera, you can transfer images to ot her display devices, e.g. TV or computer. To transfer the images, follow this method:...

  • Page 28: Chapter 7 Driver Installation

    2. When you use this function; please use the video cable provided with the camera to connect the camera and output device. 3. You can turn on the camera. There will no images shown on the LCD Monitor. All the images and information will be shown on the output device's display via the video output cable.
  • Page 29 2. The Auto-run program will be executed and the welcome screen appears. If your CD-ROM drive doesn't support the auto-run function, double click on the "My Computer " icon on the desktop. Then double click on the CD -ROM drive icon and click the InstallMgr.exe file in the root directory.
  • Page 30 English 4. Select the language for installation. Click OK to confirm your selection. 5. You will see the Welcome screen. Click Next to continue. 6. Enter Software License Agreement window. Please click Yes to continue the installation. 7. Please follow the instructions of installation Wizard to select a destination...
  • Page 31 English 8. Please select the program folder you want to install 9. When the installation is completed, the window below will appear. Click Finish to end the installation.

  • Page 32: Downloading Photos/Video From Camera

    English 7-3 Downloading photos/video from camera Turn on your PC if it isn’t on already. Click on the PhotoImpression icon in the Windows Desktop, or choose Start > Program Files > ArcSort PhotoImpression 3.0 > PhotoImpression 3.0. The following PhotoImpression main screen will appear.
