Table of Contents
Chapter 1 Attention
1-1 Quick Installation Guide............................................. .2
1-2 How to acquire images from the Camera ....................2
1-3 How to use Web Camera.............................................2
1-4 Operation Caution.......................................................3
1-5 Package Contents........................................................3
2-1 Names of Parts..........................................................4
2-2 Specifications...............................................................6
2-3 System Requirement..............................................6
3-2 LCD Monitor Display....................................................7
3-3 Power supply.........................................................8
3-4 Shutter Button............................................................9
3-5 Mode Dial................................................................9
3-6 MENU/ENTER Button.............................................9
3-7 Flash Button.........................................................9
3-8 Mode Display Button............................................10
3-9 Macro Button......................................................10
4-1 Mode Selection........................................................11
4-2 Record Mode..........................................................11
4-3 Play Mode............................................................12
4-4 Movie Mode........... ...................................................13
4-5 Setup Mode...............................................................14
5-1 Attaching the Strap...................................................16
5-2 Loading Batteries......................................................16
5-3 Loading and Removing the Memory Card...................17
5-4 Setting Up the OSD Language.................................18
5-5 Setting Up the Date/Time........................................18
6-1 Setup Mode...........................................................19
6-2 Record Mode.........................................................19
6-3 Play Mode..............................................................20
6-4 Movie Mode........... ...................................................21
6-5 PC Mode............................................................21
6-6 TV-OUT Operation................................................22
Chapter 7 Driver Installation
7-1 Installing the Camera Driver for PC.............................22
7-2 Installing the Applications for PC..............................23
7-3 Camera Setting on Windows XP..............................25
1
Chapter 1 Attention
1-1 Quick Installation Guide
1.Insert the CD-ROM into your CD drive and software installation
menu will appear on the computer screen automatically.
2.Click Utility driver to install the digital camera software. Follow the
on-screen instructions to proceed.
3.Once Setup finishes installing all the necessary files on your
computer, Please restart your computer to complete Setup.
To select the PC Camera or Mass Storage items in the PC
Connection menu, perform the following.
Power on the camera and toggle the Mode Dial
to PC. The
PC Camera and Mass Storage two menu items will appears on the
LCD Monitor.
Pressing the arrow buttons
/
on the MENU/ENTER
Button
to move and and select the desired menu items. Pressing
the
or
button to confirm save the settings.
4.To select the PC Camera, Pressing the
or
button to confirm
and save the settings.
5. If a "Connect USB" message pops up on the LCD Monitor, Please
connect the USB cable to the camera and PC to complete the
configuration. Press the Shutter to confirm, and the system will
configure the device automatically.
6. Unplug USB cable and re-power on the camera, then To select
the Mass Storage, Pressing the
or
button to confirm
and save the settings.
7. If a "Connect USB" message pops up on the LCD Monitor,
please connect the USB cable to the camera and PC to
complete the configuration. Press the Shutter to confirm, and
the system will configure the device automatically.
8.Installing the Applications for PC(Install Arcsoft Software)
1-2 How to acquire images from the camera
1.When selecting the Mass Sstorage mode, Press the Shutter to
confirm, In my Computer, it will appear a Removable Drive.
You can access the images recorded in the camera from the
PC.
2. Installing the Applications for PC(Install Arcsoft Software as
PhotoImpression), The following is the instruction of how to
get Images from Arcsoft PhotoImpression
(A).Open up Arcsoft PhotoImpression, select "From Folder"
(B).Click on Browse, and then select the path "Removable Disk\
Dcim\100FSCAM" to Acquire images
1-3 How to use Web Camera
1. Installing the Applications for PC(Install Arcsoft Software as
PhotoImpression or VideoImpression).
2. When selecting the PC Camera mode, Press the Shutter to
confirm, your computer software applications show real-time
Video images. The camera can be used for Video conferencing
or recording movies.
2
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Genius DSC-1.3MTFT
Summary of Contents for Genius DSC-1.3MTFT
-
Page 1: Table Of Contents
Chapter 4 Navigating Modes and Menus 5. If a “Connect USB” message pops up on the LCD Monitor, Please connect the USB cable to the camera and PC to complete the 4-1 Mode Selection……….......………….…..11 configuration. -
Page 2: Operation Caution
1.If lens, LCD monitor or viewfinder surface is dirty, please use USB Cable TV –OUT Cable This User's Manual lens brush or soft cloth to wipe clean instead of touching the lens with you fingers. ●CD-ROM (incl. Camera Driver) TV-OUT Port 2.Do not use any solid object to hit the camera to avoid... -
Page 3: Rear View
Motion Image fro JPEG camera. We recommend that you use a computer system that ●Image Resolution: FINE: 1600 x 1200 exceeds the minimum requirements in order to utilize the camera at (Fireware Interpolation Technology) its optimum efficiency. The minimum system requirements for the... -
Page 4: Chapter 3 Controls, Operation, And Display
(5) Possible number of shots operation after the camera (6) Self-timer photography ●Using the lens cover located on the front of the camera to turn restore to be blinking (7) White balance display n/off camera. After turn on the camera, the red LED will be... -
Page 5: Shutter Button
●This button is only working in the Record Mode. Press this button top of the LCD monitor will be on. ● You can select the working mode by using this Mode to select the desired flash mode while taking a picture and there are Dial: 4 modes available: 1. -
Page 6: Chapter 4 Navigating Modes And Menus
Start Auto Play 3. DPOF (Digital Print Order Format) Settings ●With DPOF for printing your images, there are three options for you: print one image, print all images and print the (1) Possible number of shots recorded date or not. -
Page 7: Movie Mode
(On) (Off) 1. Image Resolution 4. White Balance: (Auto) (Sun) 1600x1200 1280x1024 640x480 (Fluorescent) (Tungsten) (1) Movie Mode (2) Recorded Movie Time (seconds) 2.Image Quality: (3) Recording the movie pictures (Fine Quality) (Basic Quality) (4) Remaining battery power (5) Time/Date... -
Page 8: Chapter 5 Preparing Your Camera
6. OSD Language ●Insert the thin end of strap into the strap holder. ※ If there is a memory card inserted, it will only format the memory card, not the internal memory. 10. TV-Out Operation ●Slide the switch on the battery cover in the direction indicated... -
Page 9: Loading And Removing The Memory Card
There is 8MB internal memory built-in in the camera for saving your data: If there is a memory card inserted, it will be the top priority for saving data. If you want to store data in the internal memory, please remove the memory card first. -
Page 10: Chapter 6 Getting Started
Preset Settings, Format Media, and TV-Out items. To setup MENU/ENTER Button button, the menu items will 2. Using the lens cover located on the front of the camera to turn 1. turn the Mode Dial to Record Mode these items, perform the following: on/off camera. -
Page 11: Movie Mode
1. Power on the camera and toggle the Mode Dial to PC. 2. Using the lens cover located on the front of the camera to turn (If your CD-ROM drive doesn't support the auto-run function. before transferring images. Toggle the Mode Dial on/off camera. -
Page 12: Installing The Applications For Pc
2. The Auto-run program will be executed and the welcome screen appears: (If your CD-ROM drive doesn't support the auto-run 4. Select the language for installation. Click OK to confirm your function. Please double click on the "My Computer" icon selection. -
Page 13: Camera Setting On Windows Xp
2. Users should click "Continue Anyway" button 4. Users should click "Continue Anyway" button and 8. Please select the program folder you want to install When you plug-in the camera and select PC Camera Mode complete the camera setting on Windows XP.
