- Page 1 Manual test stand TVL / TVL-XLS / TVL-O / TVL-E PROFESSIONAL MEASURING Original version Operating instructions TVL / TVL-XLS / TVL-O / TVL-E Version 2024-03 TVL-BA-e-2431...
- Page 2 Druge jezikovne različice na Other language versions can voljo na spletni strani be found here www.kern- www.kern- sohn.com/manuals sohn.com/manuals SAUTER GmbH Ziegelei 1 72336 Balingen-Frommern Germany +0049-[0]7433-9933-0 +0049-[0]7433-9933-149 Info.sauter@kern-sohn.com www.sauter.eu...
-
Page 3: Table Of Contents
Table of contents: Technical data ........................... 2 Technical data manual test stand ....................2 Technical data length measuring device LA (not for TVL-E and TVL-O) ........3 Declaration of conformity ......................4 Overview of the device......................5 Scope of delivery ........................5 Dimensions .......................... -
Page 4: Technical Data
Spindle height from base plate 300mm 350mm Thread of the meter mounting 4x M3 (included in the plate scope of delivery) approx. approx. approx. 295 - Workspace 230mm 570mm 360mm Weight 15kg TVL-E workspace: max. 25mm max. 60mm 2 | en TVL-BA-e-2431... -
Page 5: Technical Data Length Measuring Device La (Not For Tvl-E And Tvl-O)
Technical data length measuring device LA (not for TVL-E and TVL-O) TVL-XLS TVL-E/TVL-O Scale length 200mm Readability 0.01mm Control buttons No length Switch on On/0 measuring device Zeros of the LA display LA included in the Changing the units between millimeters... -
Page 6: Declaration Of Conformity
Declaration of conformity The current EC/EU Declaration of Conformity can be found online at: https://www.kern-sohn.com/shop/de/DOWNLOADS/ 4 | en TVL-BA-e-2431... -
Page 7: Overview Of The Device
Overview of the device Scope of delivery • 1x manual test stand • 1x hook for TVL, TVL-O, TVL-XLS (no hook for TVL-E) • Operating instructions Dimensions TVL-E: 155x240x510 mm TVL-XLS: 155x240x810 mm TVL-O: 155x240x510 mm TVL: 155x240x510 mm TVL-BA-e-2431... -
Page 8: Basic Information (General)
The symbol indicates the type of hazard. Indicates general hazards or a danger point Warning of flammable substances Warning of explosive substances Warning of falling loads Warning of suspended load Warning of hand injuries Warning of tipping hazard 6 | en TVL-BA-e-2431... -
Page 9: Intended Use
Only use the manual test stand for compression and tensile tests. The device should be stable and level during the measurement. The device should be stored in a dry and cool environment. If you have any questions, please contact SAUTER or visit our website www.sauter.eu. Improper use The manual test stand is not to be used for medical purposes. -
Page 10: Basic Warnings And Safety Instructions
Basic warnings and safety instructions Observe the notes in the operating instructions Read the operating instructions carefully before commissioning/using the appliance, even if you already have experience with SAUTER appliances. Always keep the instructions in the immediate vicinity of the appliance. Staff training The appliance may only be used by persons who have read and understood the operating instructions, in particular the chapter on safety. - Page 11 The test system can tip over if heavy samples are inserted off- center or if the test system is not used correctly. ● Ensure that the test system is stable. ● Never use the test system as a climbing aid. TVL-BA-e-2431 en | 9...
- Page 12 ● If you do not use the device for a long time, you should charge it every two weeks, otherwise the internal battery is easily damaged, making it impossible to use the device again 10 | en TVL-BA-e-2431...
- Page 13 ● Do not use harsh cleaners, abrasive cleaners or solvents to clean the test system. ● Only one operator may work on the test system at a time. The operator's workstation is located in front of the test system during operation. TVL-BA-e-2431 en | 11...
-
Page 14: Transportation And Storage
Only the original packaging is to be used for return transportation Disconnect all connected cables and loose/movable parts before shipping Reattach any transportation locks provided Secure all parts against slipping and damage 12 | en TVL-BA-e-2431... -
Page 15: Unpacking And Commissioning
On receipt of the appliance, you should first check that no damage has occurred during transportation, that the outer packaging, the housing, other parts or even the appliance itself have not been damaged. If any damage is apparent, please notify SAUTER GmbH immediately. -
Page 16: Functional Description
The test stand should be set up on a solid surface, such as a workstand or a base plate. A SAUTER force gauge can then be attached to the test stand using the four M3 cylinder head screws provided. -
Page 17: Maintenance, Servicing And Disposal
Under no circumstances should aggressive cleaning agents be used. Do not make any changes to the appliance and do not install any spare parts. Contact Sauter GmbH for repair or device inspection. Waste disposal Old appliances and accessories should not be disposed of with household waste. -
Page 18: Battery Law
Batteries containing harmful substances are marked with a symbol consisting of a crossed-out dustbin and the chemical symbol (Cd = cadmium, Hg = mercury, or Pb = lead) of the heavy metal responsible for the classification as containing harmful substances. 16 | en TVL-BA-e-2431...
