- Page 1 Sauter GmbH Ziegelei 1 Tel: +49-[0]7433- 9933-199 D-72336 Balingen Fax: +49-[0]7433-9933-149 E-Mail: info@sauter.eu Internet: www.sauter.eu Instruction Manual Motorized horizontal Test Stand SAUTER THM-N Version 1.1 02/2018 PROFESSIONAL MEASURING THM-N-BA-e-1811...
- Page 2 In addition, the new THM-N is equipped with a height adjustable bench vice with jaws. By means of this, the user gets much better and flexible possibilities of adapta- tion.
- Page 3 2 Photos and drawings with dimensions View of back side: View: height adjustable jaw bench vice with a variety of possibilities of adjustment Fixing screw of the bench vice carriage Fixing screw of the bench vice height Bench vice height adjustment THM-N -BA-e-1811...
- Page 4 Dimensions in mm Ø: 20 Right adjustment Left ring adjustment ring Height alignment Cycle function for adjusting the Clockwise ON/OFF horizontal test rotation arrangement Counterclock wise rot. Velocity adjustment & indication Cycle adjustment & indication of current state, target value THM-N-BA-e-1811...
- Page 5 Repeating function with cycle adjustment Cycle indication: current state and target value indication (four-digit) Can be combined with length measuring device LB (with serial interface) e.g. for use with AFH FD (force/ displacement) software: Scale length: 200mm, readout: 0.01mm THM-N -BA-e-1811...
- Page 6 In cases of an electrical overcharge, the test stand has got an electronic fuse protection. It is incorporated in the socket of the current supply and can be substituted as necessary (with a screwdriver). Annotation: To have a look at the CE Declaration of Conformity, please click onto the following link: https://www.kern-sohn.com/shop/de/DOWNLOADS/ THM-N-BA-e-1811...
