- Page 1 User’s guide Tikee mini v1.0...
-
Page 2: Table Of Contents
Framing and installation recommendations............7 4. Getting started with the Tikee Remote mobile app .....9 Connect your Tikee mini to the mobile app............9 Setting up the connection of your Tikee mini to myTikee......10 Advanced settings........................12 Update your Tikee mini......................14 Setting up a sequence......................15 Format and size of the images.................. -
Page 3: Introduction
1. Introduction Overview of your Tikee mini Here are the main components of the Tikee mini : USB-C slot Trigger LED Power LED Anti-theft system Waterproof breathable membrane Extended power connector The rear of the Tikee mini has many functions. -
Page 4: Prerequisites
First charge of the device Caution : For an optimal use of your Tikee mini, you have to fully charge the battery before its first use. Plug a USB cable (not provided) into your Tikee mini into the dedicated USB slot. -
Page 5: Tikee Mini Overview
Caution : when plugged in, this connector is not waterproof. 2. External power connector It is used to connect the Enlaps external solar panel or the Tikee power adapter (not supplied with the camera). This connector is waterproof, so it can be used outdoors. -
Page 6: Led
Power LED • : Your Tikee mini is turned off, in standby or a sequence is in progress • : Your Tikee mini is powered on - no sequence in progress • Blinking : Tikee mini is charging through USB-C or external power connector... -
Page 7: Microsim Card (Not Included)
Micro SIM card (not included) To use the LTE-4G network with your Tikee mini you have to previously subscribe to a 4G subscrip- tion with data plan (access to the data network) with the telecommunication provider of your choice. For SIM card settings, see page Inserting the SIM card: Metal contacts of the chip downwards, angle left to the bottom - see above. -
Page 8: Starting Up The Tikee Mini
/ tablet. Framing and installation recommendations For a shooting of a few hours, your Tikee mini can be installed on its rubber sole on a sufficiently flat and not tilted surface or on a camera tripod. - Page 9 We recommend to use the stainless steel arm designed by Enlaps for Tikee. 1,5 x installation height 90° It is advisable to lay the Tikee mini flat, half way up the final construction. Starting up the Tikee mini...
-
Page 10: Getting Started With The Tikee Remote Mobile App
1. Activate Bluetooth and location services on your mobile device before launching the mobile app. Once your Tikee mini is powered on and nearby, launch the mobile app Tikee remote and log in with your credentials - created in “Creating a user account on myTikee cloud platform”... -
Page 11: Setting Up The Connection Of Your Tikee Mini To Mytikee
The Tikee mini has 2 possible status: - STOP : basic status of the Tikee mini, in inactive mode the camera will not take a photo sequence and will switch off after 30 minutes of inactivity. You will have to access the camera... - Page 12 If the connection fails : check if the quality of the wireless network is sufficient (for example you can test the connection on your smartphone beforehand) and that your credentials are correct. Note : you can connect the Tikee mini through a mobile hotspot using a smartphone with a 4G connection. Connecting to an LTE telecom network An active microSIM card (with active data transmission) needs to be inserted in its appropriate slot.
-
Page 13: Advanced Settings
We recommand to test the connection of your Tikee mini once the parameters are set up. For that click on ‘’Test connection’’. This step may take several minutes because the Tikee mini will check all of the steps to be connected to myTikee cloud platform server. - Page 14 A Tikee mini can only be associated with a single user account. However, it is possible to connect several smartphones with the same user account. If you want another user to use your Tikee mini with an other myTikee account you can unlink it from your account.
-
Page 15: Update Your Tikee Mini
This method requires a valid Wi-Fi or 4G/LTE connection and a microSD card into the slot SD. Stand close to your Tikee mini and launch the update from the cloud. The update is done following the steps displayed on the screen. -
Page 16: Setting Up A Sequence
It takes a few minutes for your Tikee mini to be fully updated. If you have a sequence in progress, your Tikee mini will pause it to install the update and will restart itself once the update is complete. Setting up a sequence Before launching a sequence, you can check the framing of your camera by doing a preview. -
Page 17: Format And Size Of The Images
- Battery full (without solar panel) - Ambient temperature 20°C - Photo resolution M These figures can be significantly increased by using the Tikee mini with the Enlaps external solar panel or the Enlaps external power supply. Always ON deactivated... -
Page 18: Starting A Sequence
30% of the battery). - Eco : Tikee mini’s energy has decreased, it continues to take images and store them on the microSD card but no longer sends them to the cloud. However, it continues to connect every 24 hours to send its status and update its configuration. -
Page 19: Checking The Progress Of A Sequence
Note 2 : You can check the status of the Tikee mini at any time on the main menu of the Tikee Remote mobile application (near the Tikee). To refresh the page, scroll down the screen. The status will update. -
Page 20: Getting Started With The Mytikee Cloud Platform
5. Getting started with myTikee cloud platform (basic features) To go further, visit : https://help.enlaps.io/en and https://enlaps.io/en/enlaps-academy Foreword Points of view Photoset A Gallery and video All photos of a Feature available using all or part shooting sequence of the photos in... -
Page 21: Point Of View
Sequence : database of all of the shot photos during an in progress or ended sequence. Point of view : A point of view uses the pictures of a sequence to create a video. You can create several points of views based on the same sequence. Point of view Editing a point of view : After you have selected your point of view, you can edit it by clicking on... -
Page 22: Portfolio
Info : When your content is in « Public » sharing mode, it becomes visible and shareable by all the people who have the link (myTikee user or not). The content also becomes visible in the « Public » section next to the search bar. - The watermark will be inlayed at the bottom left of the videos. -
Page 23: Setting Up Your Tikee Mini
Checking the status of your Tikee mini Once you have selected your Tikee mini, you can access to all of its status information: The Tikee mini’s power mode, battery charge status, date of last received image, network quality, available space on the micro SD card and date of last connection. -
Page 24: Product Brief
couleurs 6. Product brief Full-color logo utilisé sur fond 82828 et fond Version nt privilégier est ettrage «tik» est 1 kg et une mention Weight Full-color reverse logo s le cas où ce Dimensions logotype, reverse logo. 125 x 125 x 70 mm n’est tiliser plusieurs 1 camera module for wide angle photos... - Page 25 es couleurs Full-color logo e utilisé sur fond #282828 et fond Version ment privilégier est e lettrage «tik» est Long term sequence : 30 seconds minimum ne et une mention Full-color reverse logo Event or Burst sequence : 5 seconds minimum Picture interval User-defined or brightness-dependent schedules dans le cas où...
-
Page 26: Maintenance And Cautions
- Do not store Tikee mini with a discharged battery (level below 50%). - Do not insert objects (or metal) into the microSIM and microSD card slots. If there are signs of condensation or moisture inside a lens, turn off the Tikee mini (do not charge) and contact customer support. -
Page 27: Information About Frequency Bands (4G/Lte & 3G)
8. Informations about frequency bands ( 4G/LTE & 3G) Radio-Frequency technologies embedded in Tikee mini device : RF technology Frequency bands Max power WIFI 2.4-2.4835Ghz 17.2 dBm (EIRP) 3G/4G LTE-FDD: B1/B2/B3/B4/B5/B7/ -34.3 dBm (ERP) B8/B12/B13/B18/B19/ B20/B25/ B26/ B28/B66 LTE-TDD: B34/B38/B39/ B40/B41... - Page 28 This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device.
-
Page 29: Battery Information
Shooting while charging You can shoot while your Tikee mini is connected to a USB-C cable (not supplied). Note: as the cap of USB port is open while loading, the waterproofness of the Tikee mini is no longer guaranteed. WARNING: Use only chargers labelled : output 5 V 2A min. -
Page 30: Trademarks
10. Trademarks Enlaps™ and Tikee™ are registered trademarks or trademarks of Enlaps SAS in France and at the international level. Other names and brands are the property of their respective owners. Join us : Trademarks...
