USER'S gUidE TiKEE / TiKEE PRO - v3.0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Tikee and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Enlaps Tikee

Summary of Contents for Enlaps Tikee

  • Page 1 USER’S gUidE TiKEE / TiKEE PRO - v3.0...

  • Page 2: Table Of Contents

    Buttons and LEds........................6 3. Tikee’s first start up First connection and first setting..................7 Recommendations for installing and for framing with your Tikee..7 Settings of the solar panel....................8 4. getting started with the mobile app Tikee Remote Connect your Tikee to the mobil app................10 Setting up the connection of your Tikee..............11...

  • Page 3: Beginning

    Lock the position of the solar panel once the tilt adjusted LOCKiNg SYSTEM Lock the position of the solar panel once the rotation adjusted The back side of Tikee has many functions. Each function is explained below with its corresponding icon. Power button...

  • Page 4: Prerequisites

    Prerequisites Some elements are needed to ensure the optimal functioning of your Tikee: - A microSd card (not supplied) is needed to use your Tikee (see dedicated section) (see dedicated chapter). - A smartphone (supported versions: Android 5.0 and up/iOS 10.0 and up - min. Bluetooth version 4.1)

  • Page 5: First Charge Of The Device

    (not supplied), and then into a power outlet. Note : the sealing of your Tikee is not guaranteed when the USB cable is plugged into the USB slot. if a power supply unit is used, be sure that the voltage is 5v and that the delivered current is more than 1A.

  • Page 6: Tikee Presentation

    2. Tikee presentation MicroSd card (not supplied) insert the microSd card into the slot on the back side of your Tikee Technical information about microSd cards compatible with Tikee : - microSdHC, microSdXC, - 8gB to 128gB capactity, - UHS-1 class and speed class minimum U1 or U3 Note: Before use, we strongly recommend to format the microSd card (see corresponding chapter).

  • Page 7: Buttons And Leds

    : stop shooting Power LED • : Your Tikee is turned off, in standby or a sequence is on progresse • : Your Tikee is powered on and active - no sequence in progress The color is related to the battery level:...

  • Page 8: Tikee's First Start Up

    For a period of several days/months shooting, we recommend to use a rigid support which ensure a same framing over time and secure the position of your Tikee. if you want you will find a set of accessories for your Tikee on our store at: https://enlaps.io/products-accessories/?lang=en...

  • Page 9: Settings Of The Solar Panel

    Tikee view angle (°220) * Place the focus area in such way that it is facing Tikee and centered between the two lenses. Once you have chosen the framing, lock the position of your Tikee so that there is no change in the framing over the time.
  • Page 10 Tilt the panel according to the latitude of your position (approximately 30° in France for example). The tilt of Tikee can be Once the panel has been tilted at the locked here. desired angle, lock it with the 2 screws located on either side of the photovoltaic panel (by squeezing moderately).

  • Page 11: Getting Started With The Mobile App Tikee Remote

    Before you keep reading, make sure you have followed the instructions of Chapter 1 - Beginning. 1. Once your Tikee is powered on and nearby, launch the mobile app Tikee remote and log in with your ids - same as the web app.

  • Page 12: Setting Up The Connection Of Your Tikee

    Blue icon(s): connectivity enabled Setting up the connection of your Tikee to Mytikee web if you want use your Tikee’s WiFi modem or 4g LTE modem (TikeePRO only) to regularly upload photos to Mytikee web application, you have to complete the following settings.
  • Page 13 For that click on ‘’Test connection’’. This step may take several minutes because the Tikee will check all of the steps to be connected to Mytikee web application server. At the end of the test you will receive a notification about the success or not of the test.

  • Page 14: Advanced Settings

    This step may take several minutes because the Tikee will check all of the steps to be connected  to Mytikee web application server. At the end of the test you will receive a notification about the success or not of the test.

  • Page 15: Update Your Tikee

      if you want another user to use your Tikee with an other Mytikee account you can unlink it from your account. This unlink can also be done on the web app. You will not be able to link with a Tikee associated with another account than yours. You have to ...

  • Page 16: Setting Up A Timelapse Sequence

    : in case of stopping an in progress short-term sequence before the end normally set, the images are not uploaded in the web application but are kept on the microSd card. You can check the status of your Tikee at any time by clicking on: getting started with the mobile app Tikee Remote...

  • Page 17: Format And Size Of The Images

    2 photos per day : days Below 60% of battery, the Tikee camera no longer sends photos to the cloud but continues to take photos and stores them on the microSd card. Tikee will send these photos (and next photos) as soon as the battery is above 70% of charge.

  • Page 18: Checking The Progess Of A Timelapse Sequence

    The sequence(s) start(s) when the Trigger LEd flashes slowly every 10s during the whole shooting Note : if you create new time lapses sequences and that your Tikee is still in timelapse capture mode, you don’t need to start again the new time lapses sequences.

  • Page 19: User Account

    Disconnecting from the mobile app The mobile app will keep your user’s id from the first connection. if you want to log off from the mobile application, go to My Account (opposite image). getting started with the mobile app Tikee Remote...

  • Page 20: Getting Started With The Web App Mytikee

    25 and 100 images. Prior to this calculation, the project would not appear in your account and so the final pictures won’t be visible. You can check the status of your Tikee on the web app to confirm its proper functioning.
  • Page 21 Once it has been duplicated, you are free to edit it. Setting up your Tikee You can manage all of your Tikee settings by clicking at the bottom of the screen on Choice of the Tikee Select the Tikee you want to set up by clicking on it.
  • Page 22 You can unpair a Tikee by logging into the web application Mytikee. 1. Log in 2. Click on : 3. Select the Tikee you want to unlink and click at the top right of it on : 4. The selected Tikee is now disassociated from your user account.

  • Page 23: Editing A Timelapse Project

    Editing a timelapse project To edit a project, click on the top right of the thumbnail project then click on : Important : Editing does not modify the photoset. Filters When you modify the filters, the photo mosaic will update automatically with the photos that fit within the filters.
  • Page 24 June : Automatic update of the timelapse with the latest pictures uploaded by your Tikee on the web application : To activate or deactivate this mode, click on When the mode is on, you can select a start date without an end date. As soon as new photos are uploaded on the web app, the timelapse will be automatically updated (only for the long-term timelapses - otherwise the app set the date of last uploaded photos).
  • Page 25 Filter ‘’Days of the week’’ You can select photos shot only some days of the week. in the example below: Monday, Tuesday, Thursday, Saturday and Sunday: Mosaic Total number of images of the project vs Filtered photos in the example below, with the selected filters in previous examples, 169 photos meet the filtering criteria on a total of 1143 photos included in the photo set deleting an image and a selection of images To delete a photo :...
  • Page 26 To create your timelapse, uploaded photos must be in the same format as the existing photos in the mosaic of the set. When manually adding photos made by Tikee, you can select the complete photoset (all the content of the file), the application will automatically delete duplicates.
  • Page 27 Pan&Zoom. Full size framing Switch the cursor on ‘’Full frame’’. The video uses panoramic photos taken by your Tikee. Pan&Zoom framing Switch the cursor to ‘’Pan & Zoom’’. The time lapse video will then move in the panoramic image from the ‘Start’...
  • Page 28 <iframe> tag. Tutoriel : https://www.youtube.com/watch?v=zy46TKvcFOE Public mode When your timelapse sharing mode is ‘’Public’’ , everybody with the link (Enlaps users or not) can view and share your timelapse. it can also be watched in the ‘‘Community’’ timelapses section.

  • Page 29: Visualizing A Timelapse

    Watermark Filigrane Tikee When creating your timelapse, a watermark with the logo Tikee will appear highlighted on your video. This watermark can be disabled in the case of a PREMiUM membership. No Enlaps watermark and/or custom logo (PREMIUM) With a PREMiUM account, you can choose to not watermark when creating your timelapse or to affix your custom logo.
  • Page 30 With a PREMiUM account, you can download the video in full Hd with a bitrate of 16 Mbs/s. Viewing last shot photo You can view the last shot photo by your Tikee by clicking on the project. it appears under your timelapse.

  • Page 31: Enlaps Support

    ‘’Share on Facebook’’ Enlaps support For questions relating to your Tikee camera or mobile & web applications, you can read our FAQ: https://enlaps.io/faq/?lang=en You can also contact us at support@enlaps.fr or directly by private message on Facebook.

  • Page 32: Maintenance And Cautions

    - do not store Tikee with a discharged battery (level below 50%). - do not insert objects (or metal) into the microSiM and microSd card slots. if there are signs of condensation or moisture inside a lens, turn off the Tikee (do not charge) and contact customer support.

  • Page 33: Battery Information

    Shooting while charging You can shoot a timelapse while your Tikee is connected to a USB micro cable (not supplied). Note: as the cap of micro USB port is open while loading, the tightness of the Tikee is no longer guaranteed.

  • Page 34: Trademarks

    8. Trademarks Enlaps™ and Tikee™ are registered trademarks or trademarks of Enlaps SAS in France and at the international level. Other names and brands are the property of their respective owners. Follow us on : Trademarks...

This manual is also suitable for:

Tikeepro
