- Page 1 Corin TV Stand FOLLOW US: CONTACT INFO: ITEM NO. 014-HG-41008 The instruction booklet contains IMPORTANT support@belleze.com @bellezefurniture safety information. Please read it in full and 1-800-682-6376 keep it for future reference. www.belleze.com...
- Page 2 Scan this QR Code to view our online tutorial Estimated time for assembly: 120 mins Weight limitations are as follows: Maximum Load 70 lb Maximum Load 20 lb...
- Page 3 Assemble the furniture on an empty carton, carpet, or rug to prevent scratches or damage. For safety, please keep pets and children away from the assembly area. Ensure the product is fully assembled before use. If you are missing any hardware or products, do not use it until you have restored the missing parts.
-
Page 4: Package Contents
PACKAGE CONTENTS... - Page 5 PACKAGE CONTENTS CODE DESCRIPTION Top Panel Center Panel Bottom Panel Left Side Panel Right Side Panel Left Medial Panel Right Medial Panel Left Surround Panel Right Surround Panel Center Surround Panel Support Leg Top Divider Panel Top Crossbar Center Crossbar Side Storage Shelf Panel Side Back Panel Top Back Panel...
- Page 6 PACKAGE CONTENTS 37x + 4x 37x + 4x 48x + 5x 11x + 1x 16x + 1x 16x + 1x 12x + 1x 24x + 2x Install all hardware perpendicular to the opening.
- Page 7 Required tools for assembly (Not included) Attach cam bolts to the center crossbars (14) and all the legs (20, 21, 22, 23). v.10202023U...
- Page 8 Assemble the center crossbar (14) to the center panel (2). Attach cam bolts to the center panel (2), left surround panel (8) and the right surround panel (9).
- Page 9 Assemble the center surround panel (10) between the left and right surround panels (8, 9). Then assemble it to the left and right medial panels (6, 7). Assemble the left and right medial panels (6, 7) to the underside of the center panel (2).
- Page 10 Secure the center surround panel (10) to the center panel (2).
- Page 11 Option 1 (TV Stand) Option 2 (Fireplace Mantel) v.10202023U...
- Page 12 OPTION 1 ASSEMBLY (TV STAND) Slide in the center back panel (25) and then assemble the bottom panel (3) to the medial panels (6, 7). Slide the side back panels (17) to the side of the stand, then attach support legs (11) to the bottom panel (3).
- Page 13 Attach cam bolts to side panels (4, 5). Assemble left legs (20, 21) to the left panel (4) and the right legs (22, 23) to the right panel (5). v.10202023U...
- Page 14 Assemble the stand assembly and the top crossbar (13) between the side panels (4, 5). Attach foot protectors under the legs.
- Page 15 Attach the top divider (12) on top of the center panel (2). Slide the top back panel (18) to the stand. v.10202023U...
- Page 16 Attach cam bolts to the underside of the top panel (1). Assemble the top panel (1) on top of the stand.
- Page 17 Further secure the top crossbar to the top panel. Secure the back panels in place. v.10202023U...
- Page 18 Attach anti-tipping straps to the back of the stand.
- Page 19 Attach door hinges to the cabinet doors (19). Attach door handles to the cabinet doors (19). v.10202023U...
- Page 20 Assemble cabinet doors to the stand. Adjust the position of the cabinet doors. Up and down In and out Side to side adjustment by adjustment by adjustment using loosening the screws loosening the screws the front adjustment on the mounting on the hinge arm.
- Page 21 Insert shelf pegs inside the stand and put the storage shelf panels (16, 24) on the pegs. v.10202023U...
- Page 22 device to prevent the furniture from tipping over. • Mark the drill position on the wall with a pencil. • Drill a small hole on the marked position. • Insert a wall anchor into the drilled hole. • Fixed the anti-tipping strap to the wall with provided screws.
- Page 23 Attach the top garnishing strip on top of the stand. 0.2” / 5mm 2” / 50mm YOU’RE FINISHED! v.10202023U...
- Page 24 OPTION 2 ASSEMBLY (FIREPLACE MANTEL) Assemble the bottom panel (3) to the medial panels (6, 7). Slide the side back panels (17) to the side of the stand, then attach support legs (11) to the bottom panel (3). WARNING Risk of death or serious injury. This surface must be placed against a fixed in place wall at least as tall as the television.
- Page 25 Attach cam bolts to side panels (4, 5). Assemble left legs (20, 21) to the left panel (4) and the right legs (22, 23) to the right panel (5). v.10202023U...
- Page 26 Assemble the stand assembly and the top crossbar (13) between the side panels (4, 5). Attach foot protectors under the legs.
- Page 27 Attach the top divider (12) on top of the center panel (2). Slide the top back panel (18) to the stand. v.10202023U...
- Page 28 Note: Screws are provided in the heater package. The heater has a glass front panel. Careful when handling glass to prevent injury or damage. Set the unit from the back of the fireplace mantel and center it in the opening. Check the alignment and attach the unit to the mantel by inserting screws through the drilled holes on the mantel.
- Page 29 Attach cam bolts to the underside of the top panel (1). Assemble the top panel (1) on top of the stand. v.10202023U...
- Page 30 Further secure the top crossbar to the top panel. Secure the back panels in place.
- Page 31 Attach anti-tipping straps to the back of the stand. v.10202023U...
- Page 32 Attach door hinges to the cabinet doors (19). Attach door handles to the cabinet doors (19).
- Page 33 Assemble cabinet doors (19) to the stand. Adjust the position of the cabinet doors. Up and down In and out Side to side adjustment by adjustment by adjustment using loosening the screws loosening the screws the front adjustment on the mounting on the hinge arm.
- Page 34 Insert shelf pegs inside the stand and put the storage shelf panels (16) on the pegs.
- Page 35 device to prevent the furniture from tipping over. • Mark the drill position on the wall with a pencil. • Drill a small hole on the marked position. • Insert a wall anchor into the drilled hole. • Fixed the anti-tipping strap to the wall with provided screws. v.10202023U...
- Page 36 Attach the top garnishing strip on top of the stand. 0.2” / 5mm 2” / 50mm YOU’RE FINISHED!
- Page 37 Warning Only place items on top of the product if they meet the recommended size and weight limits. Climbing on, stepping on, or placing overweighted objects on the product may cause property damage and/or injuries. Items placed onto this product must be resting on a support surface without hanging over the edges.
- Page 38 WARNING For use with televisions weighing 70lbs (31.8kg) or less. Use with heavier televisions may result in instability, causing tip over resulting in death or serious injury. Death or serious injury may occur when children climb on audio and/or video equipment furniture. A remote control or toys placed on the furnishing may encourage a child to climb on the furnishing and as a result the furnishing may tip over on to the child.
