Do you have a question about the C1 and is the answer not in the manual?
Questions and answers
Bob and Randi Oppelt
March 6, 2025
where does the floating block go?
2 comments:
Bob and Randi Oppelt
March 6, 2025
@Bob and **** Oppelt
Mr. Anderson
March 6, 2025
For tiled surfaces, the floating block attachment should be installed on the WYBOT C1 robotic pool cleaner. Follow the installation steps shown in the provided video.
This answer is automatically generated
Jim Lievre
May 27, 2025
cleaner never adds to the app. I click the +, I see the machine, then add the network, select the pool... then it goes back and no machine is added. only a box with a + sign.....
1 comments:
Mr. Anderson
May 27, 2025
The WYBOT C1 cleaner may not be adding to the app after selecting the network and pool because the device might not be powered on or in pairing mode. You need to push and hold the power button until the front light turns green to ensure it's discoverable. Additionally, ensure it is connected via Bluetooth and Wi-Fi. If it's still not adding, a firmware update or network issue may be preventing the connection.
This answer is automatically generated
BEATRIZ Z silva RIVERA
May 21, 2025
blue light comes on, place it in the water and after a few seconds ... it goes off. try it aga in and purple light stays on... what should I do???
1 comments:
Mr. Anderson
May 24, 2025
If the blue light on the WYBOT C1 turns off after being placed in water and the purple light stays on, it may indicate the cleaner was not placed in the pool within the required time after activation. The device should be turned on again, and once the light turns blue, it must be placed in the water within about 3 minutes to prevent it from turning off automatically.
This answer is automatically generated
Sjm
May 14, 2025
Is there a finer filter for this?
1 comments:
Mr. Anderson
May 21, 2025
The WYBOT C1 has a fine mesh screen that effectively catches small particles, including fine sand from a sand filter. There is no specific mention of an ultrafine or finer filter being available beyond this built-in mesh.
This answer is automatically generated
Jerry R Roberts
May 8, 2025
where is the video to attach the float nbloc?
1 comments:
Mr. Anderson
May 19, 2025
The context does not provide a specific video showing how to attach the float nbloc for the WYBOT C1. It suggests contacting customer service for proper placement instructions.
This answer is automatically generated
Shari
April 13, 2025
How to install the float nlock
1 comments:
Mr. Anderson
April 13, 2025
To install the floating kit (referred to as "float nlock") for the WYBOT C1:
1. Attach it to the cleaner using the hook on your pool pole, similar to how you would attach a leaf net. 2. The floating kit includes multiple pieces; align and connect them as shown in the demonstration. 3. Some pieces may not be required depending on your pool, but if the robot has trouble climbing walls, install the full kit. 4. Once attached, ensure the components are secure before placing the cleaner in the pool.
The floating kit helps improve wall-climbing performance.
This answer is automatically generated
Larry Davis
April 1, 2025
The WYBOT App does not provide for programming on my smartphone. How can I set up my cleaning cycles?
1 comments:
Mr. Anderson
April 1, 2025
If the app does not allow programming on your smartphone, you cannot set up cleaning cycles for the WYBOT C1. The cleaning cycles must be scheduled through the app.
This answer is automatically generated
Bob Zawadzki
March 28, 2025
How to put wybot in pairring mode
1 comments:
Mr. Anderson
March 28, 2025
To put the WYBOT C1 in pairing mode, press and hold the power button until the LED light turns green. This indicates the device is ready to connect. Make sure Bluetooth is enabled on your mobile device.
This answer is automatically generated
Collin Blake
March 10, 2025
Can I clean the filter by stopping the machine half way through its cycle
1 comments:
Mr. Anderson
March 10, 2025
Yes, the WYBOT C1 filter can be cleaned by stopping the machine, but it should be powered off before opening the top cover. The filter basket needs to be removed, emptied, rinsed with clean water, and reinserted before closing the cover.
This answer is automatically generated
Linda L. DeMatteo
July 30, 2025
How do I know if the bot is turned off before charging?
Page 3
Thank you for choosing WYBOT products, your support means a lot to us. Continu- ous providing the best solution to free you up from pool cleaning and enjoy your family time is always our pursuit. WYBOT Robotic Pool Cleaner is dedicated to serving you high efficiency, low power consumption, easy operation and thorough pool cleaning work.
Page 4
Read the manual carefully before you use the cleaner. Your safety is the most important thing. Please read through and operate the device as per instructions, WYBOTICS Co., Ltd. is not held liable for any loss or injury caused by improper use. Warning Failure to operate the device as per the warnings can result in serious injury, electrocution or death.
CONTENTS WYBOT C1(OS7010C) AT A GLANCE Product External Overview Product Internal Overview Packing List GET STARTED Charge your new WYBOT C1(OS7010C) Setup your new WYBOT C1(OS7010C) Connect to your App Choose your cleaning mode Preset your cleaning cycle via the app Run your new WYBOT C1(OS7010C)...
WYBOT C1(OS7010C) AT A GLANCE Product External Overview LED Indicator Different light colors to indicate device status Charging Port Connect the charging cable Handle Track Remove and transport the device with it Enhance device’s capability in climbing walls on/off Button...
Product Internal Overview Filter Basket Sealed Part Store collected dirt and debris, need be washed Important components are sealed there. after each use. For your safety, do not try to disassemble it without authorization. Do not operate the device when the top cover or scrubbing brushes are broken. If there is any liquid leakage from the sealing part, stop charging or running the device.
GET STARTED Charge your new WYBOT C1(OS7010C) The device has a lithium-ion rechargeable battery, and you need to charge the batte- ry before first use and when the battery is low. Connect your device to a power outlet using the included cable and adaptor.
Connect to your App You can download the WYBOT App to your smart mobile device by scanning QR code below, or from Google Play or App Store. Android iOS 15.0 or later...
Choose your cleaning mode After connecting to your App, you can preset a suitable cleaning mode for your device. There are 4 cleaning modes, and you can see details below. Mode Cleaning Range Full pool cleaning Wall+ Floor+Waterline Floor only Floor Wall only Wall...
Run your new WYBOT C1(OS7010C) Hold the handle of the cleaner and put it into the pool within 3 minute, otherwise the device will be turned off. Let it sink down to the floor to empty trapped air inside.
Page 12
The cleaner begins to clean walls, floor About 20 seconds of auto calibration and waterline as default or your set. on the floor, the indicator light will turn flashing blue. The cleaner is ready to clean. The device will automatically move to You can insert the included hook into stop by the edge of wall when finishing a pool rod and lift the cleaner out of...
DO A FILTER CLEANING Hold the filter cover handle, press and open it. Note: 1. You should ensure the device is powered off when open the top cover. 2. You need to clean the filter basket before being dry. Take out the filter basket. Empty all debris and rinse it with clean water.
Available LIMITED WA RRANTY 1. All WYBOT pool cleaners in the market have been inspected and licensed to be sold as per local laws. 2. The warranty duration for battery, motor and PCB is two (2) years from the purchas ing date.
kinds of transfer. 4. Any damages to the unit caused by improper use, unauthorized repair or disas- sembly are not covered by WYBOTICS Co., Ltd.’s warranty. 5.The order number or record must be presented for any claim or repair within the warranty period.
Page 16
Issues Details Possible Causes Suggested Solution Device does A solid red light Impeller is stuck Check the impeller not work and clean foreign A flashing red Motor protection Restart light Restart and put it into Not put the device A flashing red into the water or the pool immediately.
CERTIFICATION WYBOT robotic pool cleaners have passed all performance and reliability tests and also has obtained relevant certifications from the countries in which they are sold. you can rest assured. WYBOT CUSTOMER CARE Due to the need for continuous products improvement, the products in the manual are subject to the real products, and WYBOTICS Co., Ltd.
Page 21
Notre objectif est de fournir en permanence la meilleure solution pour vous libérer de cette tâche de nettoyage et profiter de votre temps en famille. Le robot nettoyeur de piscine WYBOT est destiné à vous offrir une grande efficac- ité, une faible consommation d'énergie, une utilisation facile et un travail de nettoy- age approfondi.
Page 22
Lisez attentivement le manuel avant d'utiliser le nettoyeur. Votre sécurité est la chose la plus importante. Veuillez lire attentivement et utiliser l'appareil conformé- ment aux instructions, WYBOTICS Co. n'est pas responsable de toute perte ou bless- ure causée par une utilisation incorrecte. Avertissement Le fait de ne pas utiliser l'appareil conformément aux avertissements peut entraîner des blessures graves, une électrocution ou la mort.
Page 23
Contenu WYBOT C1(OS7010C) EN UN COUP D'OEIL Présentation interne du produit Présentation externe du produit Liste de colisage COMMENCER Chargez votre nouveau WYBOT C1(OS7010C) Configurez votre nouveau WYBOT C1(OS7010C) Connectez-vous à votre application Choisissez votre mode de nettoyage Préréglez votre cycle de nettoyage via l'application EXÉCUTEZ VOTRE NOUVEAU WYBOT C1(OS7010C)...
WYBOT C1(OS7010C) EN UN COUP D'OEIL Présentation interne du produit Indicateur LED Différentes couleurs de lumière pour indiquer l'état Port de chargement de l'appareil Connectez le câble de chargement Poignée Piste Retirez et transportez l'appareil avec Améliorer la capacité de l'appareil à escalader...
Présentation externe du produit Panier filtre Pièce scellée Stockez la saleté et les débris collectés et doivent être Les composants importants y sont scellés. lavés après chaque utilisation. Pour votre sécurité, n'essayez pas de le démonter sans autorisation. N'utilisez pas l'appareil lorsque le capot supérieur ou les brosses à récurer sont cassés.
COMMENCER Chargez votre nouveau WYBOT C1(OS7010C) L'appareil dispose d'une batterie rechargeable au lithium-ion et vous devez charger la batterie avant la première utilisation et lorsqu'elle est faible. Connectez votre appareil à une prise de à l'aide du câble et de l'adaptateur inclus.
Connectez-vous à votre application Vous pouvez télécharger l'application WYBOT sur votre téléphone mobile en scann- ant le code QR ci-dessous, ou depuis Google Play ou App Store. Android iOS 15.0 ou version...
Choose your cleaning mode Après vous être connecté à votre application, vous pouvez prédéfinir un mode de nettoyage adapté à votre appareil. Il existe 4 modes de nettoyage et vous pouvez voir les détails ci-dessous. Gamme de nettoyage Mode Nettoyage complet de la piscine Mur + Sol + Ligne de flottaison Sol uniquement Mur uniquement...
3. Si vous sélectionnez des cycles autres que celui par défaut, vous devez garder le nettoyeur dans la piscine pour terminer des cycles entiers. Exécutez votre nouveau WYBOT C1(OS7010C) Tenez la poignée du nettoyeur et mettez-le dans la piscine dans les 3 minutes, sinon l'appareil s'éteindra.
Page 30
Environ 20 secondes d'étalonnage Le nettoyeur commence à nettoyer automatique au sol, le voyant devien- les murs, le sol et la ligne de flottaison dra bleu clignotant. Le nettoyeur est selon le réglage par défaut ou le prêt à nettoyer. réglage que vous avez effectué.
FAIRE UN NETTOYAGE DU FILTRE Tenez la poignée du couvercle du filtre, appuyez dessus et ouvrez-la. 1. Vous devez vous assurer que l'appareil est éteint lorsque vous ouvrez le capot supérieur. 2. Vous devez nettoyer le panier-filtre avant de le sécher. Retirez le panier-filtre Videz tous les débris et rincez-les à...
Disponible GARANTIE LIMITÉE 1. Tous les nettoyeurs de piscine WYBOT sur le marché ont été inspectés et autorisés à être vendus conformément aux lois locales. 2. La durée de garantie pour la batterie, le moteur et le PCB est de deux (2) ans à...
4. Tout dommage à l'appareil causé par une utilisation inappropriée, une répara- tion ou un démontage non autorisé n'est pas couvert par la garantie WYBOTICS CO., LTD. 5. Le numéro de commande ou le dossier doit être présenté pour toute réclama- tion ou réparation pendant la période de garantie.
Page 34
Non. IProblèmes Détails Causes possibles Solution suggérée La turbine est Vérifiez la turbine et nettoyez L'appareil ne Un indicateur bloquée les corps étrangers. fonctionne rouge fixe Protection moteur Redémarrer Un feu rouge clignotant Ne pas mettre Redémarrez et mettez-le Un feu rouge l'appareil dans l'eau immédiatement dans la clignotant...
CERTIFICATION Les robots nettoyeurs de piscine WYBOT ont passé avec succès tous les tests de performance et de fiabilité et ont également obtenu les certifications perti- nentes des pays dans lesquels ils sont vendus. vous pouvez être rassuré. SERVICE CLIENTÈLE WYBOT En raison de la nécessité...
Page 36
www.wybotpool.com E-mail : support@wybotpool.com Facebook : @WybotPool WYBOTICS CO., LTD No.30, zone ouest de la 4e rue Zhongnan, TEDA Tianjin, Chine Tous les noms commerciaux sont des marques ayant des fabricants respectifs répertoriés.
Page 39
Danke, dass Sie sich für WYBOT Produkte entschieden haben, Ihre Unterstützung bedeutet uns sehr viel. Unser Ziel ist es, Ihnen stets die beste Lösung zu bieten, damit Sie von der Poolreinigung befreit sind und Ihre Zeit mit der Familie genießen können.
Page 40
Lesen Sie die Bedienungsanleitung sorgfältig durch, bevor Sie den Reiniger verwen- den. Ihre Sicherheit ist das Wichtigste. Bitte lesen Sie sich die Anleitung durch und bedienen Sie das Gerät entsprechend. WYBOTICS Co., Ltd. kann nicht für Schäden oder Verletzungen haftbar gemacht werden, die durch unsachgemäße Benutzung entstehen.
Page 42
WYBOT C1(OS7010C) AUF EINEN BLICK Produktinterner Überblick Externe Produktübersicht Packliste ANFANGEN Laden Sie Ihren neuen WYBOT C1(OS7010C) auf Einrichten Ihres neuen WYBOT C1(OS7010C) Verbinden Sie sich mit Ihrer App Wählen Sie Ihren Reinigungsmodus Stellen Sie Ihren Reinigungszyklus über die App ein STARTEN SIE IHREN NEUEN WYBOT C1(OS7010C)...
WYBOT C1(OS7010C) AUF EINEN BLICK Produktinterner Überblick LED-Anzeige Unterschiedliche Lichtfarben zur Anzeige des Ladeanschluss Gerätestatus Verbinden Sie das Aufladekabel Handgriff Verfolgung Entnehmen und transportieren Sie das Gerät damit Verbessern Sie die Fähigkeit des Geräts, EIN/AUS Taste Wände und verschiedene Hindernisse zu überwinden...
Externe Produktübersicht Filterkorb Abgedichteter Teil Angesammelten Schmutz und Ablagerungen müs- Wichtige Komponenten sind dort abge- sen Sie nach jedem Benutzen abwaschen. dichtet. Versuchen Sie zu Ihrer Sicher- heit nicht, sie ohne Genehmigung zu demontieren. Nehmen Sie das Gerät nicht in Betrieb, wenn die obere Abdeckung oder die Sch- rubbbürsten beschädigt sind.
ANFANGEN Laden Sie Ihren neuen WYBOT C1(OS7010C) auf Das Gerät ist mit einer Lithium-Ionen-Batterie ausgestattet, welche Sie vor dem ersten Benutzen und bei niedrigem Batteriestand aufladen müssen. Schließen Sie Ihr Gerät mit dem mitgelieferten Kabel und Adapter an eine Steck- dose an.
Sie sollten das Gerät sofort aufladen. Verbinden Sie sich mit Ihrer App Sie können die WYBOT App auf Ihr intelligentes Mobilgerät herunterladen, indem Sie den QR-Code unten scannen oder bei Google Play oder im App Store. Android iOS 15.0 oder höher...
Wählen Sie Ihren Reinigungsmodus Nachdem Sie sich mit Ihrer App verbunden haben, können Sie einen geeigneten Reinigungsmodus für Ihr Gerät voreinstellen. Es gibt 4 Reinigungsmodi. Einzelheit- en finden Sie unten. Reinigungsbereich Modus Vollständige Reinigung des Pools Wand+Boden+Wasserlinie Nur Boden Boden Nur Wand Wand Wand, dann Boden...
Sie den Reiniger im Pool lassen, um den vollständigen Zyklus abzus- chließen. Starten Sie Ihren neuen WYBOT C1(OS7010C) Halten Sie den Reiniger am Griff fest und setzen Sie ihn innerhalb von 3 Minuten in d- en Pool ein, andernfalls schaltet sich das Gerät aus.
Page 49
Etwa 20 Sekunden nach der automa- Der Reiniger beginnt mit der Reini- tischen Kalibrierung auf dem Boden gung der Wände, des Bodens und der wird die Anzeigeleuchte blau blinken. Wasserlinie wie voreingestellt oder Der Reiniger ist bereit für die Reini- von Ihnen eingestellt.
FÜHREN SIE EINE FILTERREINIGUNG DURCH Tenez la poignée du couvercle du filtre, appuyez dessus et ouvrez-la. Anmerkung: 1. Vergewissern Sie sich, dass das Gerät ausgeschaltet ist, wenn Sie die obere Abdeckung öffnen. 2. Sie müssen den Filterkorb reinigen, bevor er trocken ist. Nehmen Sie den Filterkorb heraus.
OTA- Aktualisierung Verfügbar EINGESCHRÄNKTE GARANTIE 1. Sämtliche auf dem Markt befindlichen WYBOT Pool-Reiniger wurden geprüft und sind für den Verkauf entsprechend den lokalen Gesetzen zugelassen. 2. Die Garantiezeit für Batterie, Motor und Platine beträgt zwei (2) Jahre ab dem Kaufdatum. Verschleißteile, einschließlich Filterkorb, Bürste, Räder usw., sind von der Garantie ausgenommen.
4.Schäden am Gerät, die aufgrund von unsachgemäßem Benutzen, nicht autoris- ierter Reparatur oder Demontage entstanden sind, werden von der Garantie von WYBOTICS Co. nicht abgedeckt. 5.Die Bestellnummer oder der Beleg muss bei jeder Reklamation oder Reparatur innerhalb der Garantiezeit vorgelegt werden. WIE SIE IHR GERÄT WARTEN KÖNNEN Sie sollten die Schritte zur Lagerung Ihres Reinigers befolgen, um dessen gute Leistung zu erhalten.
Page 53
Nein. Probleme Details Mögliche Ursachen Vorgeschlagene Lösung Das Flügelrad Überprüfen Sie das Flügelrad Das Gerät fun- Ein dauerhaftes steckt fest und reinigen Sie es ktioniert nicht rotes Licht Motorschutz Starten Sie neu. Ein blinkendes rotes Licht Sie haben das Gerät Starten Sie das Gerät neu Ein blinkendes nicht ins Wasser...
ZERTIFIZIERUNG Die WYBOT Roboter-Reiniger für Pools haben alle Leistungs- und Zuverläs- sigkeitstests bestanden und auch die entsprechenden Zertifizierungen der Länder erhalten, in denen sie verkauft werden. Sie können sich darauf verlassen. SERVICE CLIENTÈLE WYBOT Aufgrund der Notwendigkeit der fortlaufenden Produktverbesserung beziehen sich die Produkte in diesem Handbuch auf die tatsächlichen Produkte, und...
Page 56
www.wybotpool.com E-Mail: support@wybotpool.com Facebook: @WybotPool WYBOTICS CO., LTD Nr. 30, Zhongnan 4th Straße Westzone, TEDA Tianjin, China Alle Handelsnamen sind eingetragene Handelsmarken der jeweiligen aufge- führten Hersteller.
Page 59
El limpiador robótico de piscina WYBOT se dedica a brindar alta eficiencia, bajo consumo de energía, fácil operación y trabajos de limpieza minuciosos de la piscina.
Page 60
Lea atentamente el manual antes de utilizar el limpiador. Su seguridad es lo más importante. Lee y use el dispositivo según las instrucciones de WYBOTICS CO.,LTD. l no se hace responsable de ninguna pérdida o daño causado uso inadecuado. ADVERTENCIA No utilizar el dispositivo considerando las advertencias puede provocar lesiones graves, electrocución o la muerte.
Page 62
Contenidos WYBOT C1(OS7010C) DE UN VISTAZO Descripción general interna del producto Descripción general externa del producto Lista de contenido COMENZAR Carga tu nuevo WYBOT C1(OS7010C) Configura tu nuevo WYBOT C1(OS7010C) Conéctate a tu aplicación Elige tu modo de limpieza Preestablezca su ciclo de limpieza a través de la aplicación EJECUTE SU NUEVO WYBOT C1(OS7010C)...
Page 63
WYBOT C1(OS7010C) DE UN VISTAZO Descripción general interna del producto Indicador LED Diferentes colores de luz para indicar el estado Entrada de carga del dispositivo. Conecte el cable de carga Manejar Pista Retire y transporte con el dispositivo Mejorar la capacidad del dispositivo para Botón de ON (apagado) / OFF (encendido)
Descripción general externa del producto Cesta de filtro Parte sellada Almacene la suciedad y los residuos recogidos; debe Allí se sellan los componentes import- ser lavado después de cada uso. antes. Por su seguridad, no intente desmontarlo sin autorización. No use el dispositivo cuando la cubierta superior o los cepillos de fregar estén ro- tos.
COMENZAR Carga tu nuevo WYBOT C1(OS7010C) El dispositivo tiene una batería recargable de iones de litio y es necesario cargarla antes del primer uso y cuando la batería esté baja. Conecte su dispositivo a una toma de corriente utilizando el cable y el adaptador incluidos.
LED seguirá parpadeando indicando batería baja cuando encienda el dispo- sitivo y deberá cargarlo inmediatamente. Conéctate a tu aplicación Puede descargar la aplicación WYBOT en su dispositivo móvil inteligente escaneando el código QR a continuación, o desde Google Play o App Store. Android iOS 15.0 o posterior...
Elige tu modo de limpieza Después de conectarse a su aplicación, puede preestablecer un modo de limpieza adecuado para su dispositivo. Hay 4 modos de limpieza y se puede ver los detalles a continuación. Rango de limpieza Modo limpieza completa de piscina Pared+Suelo+Línea de flotación Sólo piso Piso...
3. Si selecciona ciclos distintos al predeterminado, debe mantener el limpiador en la piscina para completar todos los ciclos . Ejecute su nuevo WYBOT C1(OS7010C) Sostenga el mango del limpiador y colóquelo en la piscina dentro de 3 minutos; de lo contrario, el dispositivo se apagará.
Page 69
Aproximadamente 20 segundos de El limpiador comienza a limpiar calibración automática en el piso, la paredes, piso y línea de agua de luz indicadora parpadeará en azul. El forma predeterminada o en su equipo. limpiador está listo para limpiar. El dispositivo se moverá automática- Puede insertar el gancho incluido en mente para detenerse en el borde de una barra de piscina y sacar el...
HACER UNA LIMPIEZA DEL FILTRO Sostenga el asa de la tapa del filtro, presione y ábrala. Anmerkung: 1. Debe asegurarse de que el dispositivo esté apagado cuando abra la cubierta superior. 2. Es necesario limpiar la cesta del filtro antes de secarla. Saque la cesta del filtro.
Disponible GARANTÍA LIMITADA 1. Todos los limpiadores de piscina WYBOT del mercado han sido inspeccionados y autorizados para su venta según las leyes locales. 2. La duración de la garantía para la batería, el motor y la PCB es de dos (2) años a partir de la fecha de compra.
4.Cualquier daño a la unidad causado por un uso inadecuado, reparación o desmontaje no autorizado no estará cubierto por la garantía de WYBOTICS CO., LTD. 5.Se deberá presentar el número de pedido o registro para cualquier reclamo o reparación dentro del período de garantía. CÓMO MANTENER SU DISPOSITIVO Debes seguir los pasos para guardar tu limpiador para que mantenga un buen rendimiento.
Page 73
Asuntos Detalles Posibles causas Solución sugerida El impulsor está Revise el impulsor y limpie las El dispositivo Una luz roja fija atascado partículas extrañas. no funciona Protección del Reanudar Una luz roja inter- mitente motor No coloque el Reinicie y póngalo en la Una luz roja dispositivo en el piscina inmediatamente.
WYBOTICS CO.,LTD. se reserva el derecho de actualizar los productos. Si encuentra algún problema durante el uso, comuníquese con el equipo de posventa. Para obtener más detalles, comuníquese con el sitio web de WYBOT- ICS www.wybotpool.com Servicio al cliente Wybot: Correo electrónico: support@wybotpool.com...
Page 76
www.wybotpool.com Correo electrónico: support@wybotpool.com Facebook: @WybotPool WYBOTICS CO., LTD No.30, Zona Oeste de la Calle 4 Zhongnan, TEDA Tianjin, China Todos los nombres comerciales son marcas comerciales registradas de los respectivos fabricantes enumerados.
Page 79
à limpeza da piscina, de modo a que lhe sobre mais tempo para desfrutar em família. Este robot de limpeza de piscinas WYBOT foi concebido para lhe assegurar uma limpeza de piscina completa, com elevada eficiência, baixo consumo de energia e grande facilidade de utilização.
Page 80
Leia atentamente o manual antes de utilizar o robot de limpeza. A sua segurança é o mais importante. Utilize o aparelho sempre de acordo com as instruções contidas neste manual. A WYBOTICS Co., Ltd. não se responsabiliza por quaisquer perdas ou danos causados por utilização incorreta.
Page 82
Configuração do seu novo WYBOT C1(OS7010C) Associação à App Escolha o modo de limpeza SELEÇÃO DO CICLO DE LIMPEZA ATRAVÉS DA APP COLOCAÇÃO EM FUNCIONAMENTO DO SEU NOVO WYBOT C1(OS7010C) LIMPEZA DO FILTRO CARACTERÍSTICAS DO APARELHO GARANTIA LIMITADA MANUTENÇÃO DO APARELHO PERGUNTAS FREQUENTES E RESOLUÇÃO DE PROBLEMAS...
APRESENTAÇÃO RÁPIDA DO WYBOT C1(OS7010C) Vista Geral do Interior do Produto Indicador LED O estado do dispositivo é sinalizado através de Tomada de Carregamento indicadores luminosos de cores diferentes Ligação do cabo de carregamento Pega Controlo Permite remover o aparelho da água e transportá-lo Aumenta a capacidade do dispositivo Botão de ligar/desligar...
Vista Geral do Exterior do Produto Cesto de Filtragem Parte Selada Armazena a sujidade recolhida; requer limpeza Esta área selada alberga uma série de após cada utilização. componentes vitais do aparelho. Para sua segurança, não tente desmontá-la. Não coloque o aparelho em funcionamento se a tampa superior ou as escovas de limpeza estiverem danificadas.
PRIMEIROS PASSOS Carregamento do seu novo WYBOT C1(OS7010C) Este dispositivo está equipado com uma bateria recarregável de iões de lítio, que será necessário carregar antes da primeira utilização e sempre que esteja fraca. Ligue o aparelho a uma tomada elétrica utilizando o cabo e o adaptador fornecidos.
Associação à App Pode descarregar a app WYBOT para dispositivos móveis a partir do Google Play ou da App Store ou utilizando o código QR a seguir. Android iOS 15.0 ou posterior...
Escolha o modo de limpeza Após associar o aparelho à app, é possível selecionar os modos de limpeza pretendidos. Existem 4 modos de limpeza, detalhados em seguida. Alcance Modo Limpeza completa da piscina Parede + Fundo + Linha de Água Apenas fundo Fundo Apenas parede...
3. Se selecionar ciclos diferentes do predefinido, mantenha o aparelho dentro da piscina até os concluir na totalidade. Colocação em funcionamento do seu novo WYBOT C1(OS7010C) Segure o robot de limpeza pela pega e coloque-o na piscina. Se não o fizer, o apare- lho desliga-se automaticamente após 3 minutos.
Page 89
O indicador luminoso fica azul intermi- O aparelho começa a limpar as tente após cerca de 20 segundos de paredes, o fundo e a linha de água da calibração automática no fundo da piscina, segundo o ciclo predefinido piscina. O robot está pronto a ou selecionado pelo utilizador.
LIMPEZA DO FILTRO Segure a pega da tampa do filtro e prima para abrir. Anmerkung: 1. Certifique-se de que o aparelho está desligado antes de abrir a tampa superior. 2. É necessário limpar o cesto de filtragem antes de o secar. Retire o cesto de filtragem.
Disponível GARANTIA LIMITADA 1. Todos os aparelhos de limpeza de piscinas WYBOT em comercialização são devidamente inspecionados e autorizados, de acordo com a legislação aplicável. 2. A bateria, motor e PCB estão cobertos por uma garantia de dois (2) anos a partir da data de compra.
4. Estão excluídos desta garantia da WYBOTICS Co. quaisquer danos resultantes por uma utilização incorreta, desmontagem ou reparação não autorizada do aparelho. Por favor, indique-nos sempre o número de encomenda ou registo do seu aparelho em caso de reclamação ou pedido de reparação ao abrigo da garantia. MANUTENÇÃO DO APARELHO Siga estes passos na hora de guardar o seu robot de limpeza, a fim de assegurar o seu bom desempenho.
Page 93
Não. Problemas Detalhes Causa Provável Solução Sugerida Impulsor preso Verifique e limpe o impulsor O aparelho nã Luz vermelha fixa o funciona Reiniciar Proteção do Luz vermelha int- ermitente motor O aparelho não foi Reinicie o aparelho e Luz vermelha colocado na água ou coloque-o imediatamente intermitente...
CERTIFICAÇÃO Os robots de limpeza de piscinas WYBOT são sujeitos aos mais rigorosos testes de desempenho e fiabilidade, obtendo sempre todas as certificações necessárias à sua comercialização nos países em que são vendidos. Use sem preocupações. APOIO AO CLIENTE WYBOT Devido à...
Page 96
www.wybotpool.com Email: support@wybotpool.com Facebook: @WybotPool WYBOTICS CO., LTD No.30, Zhongnan 4th Street West Zone, TEDA Tianjin, China Todos os nomes de produtos referidos no presente são marcas registadas dos respetivos proprietários.
Page 99
Grazie per aver scelto i prodotti WYBOT, il vostro supporto significa molto per noi. Fornire continuamente la soluzione migliore per liberarti dalla pulizia della piscina e goderti il tempo in famiglia è sempre il nostro obiettivo. Il robot pulitore per piscine WYBOT è dedicato a offrirti alta efficienza, basso consumo energetico, facilità...
Page 100
Prima di utilizzare l'aspirapolvere, leggi attentamente il manuale. La tua sicurezza è la cosa più importante. Si prega di leggere e utilizzare il dispositivo secondo le istruzi- oni, WYBOTICS Co., Ltd. non è responsabile per eventuali perdite o lesioni causate da un uso improprio.
Page 102
Panoramica interna del prodotto Panoramica esterna del prodotto Lista di imballaggio INIZIARE Ricarica il tuo nuovo WYBOT C1(OS7010C) Configura il tuo nuovo WYBOT C1(OS7010C) Connettiti alla tua App Scegli la modalità di pulizia PREIMPOSTA IL CICLO DI PULIZIA TRAMITE L'APP ESEGUI IL TUO NUOVO WYBOT C1(OS7010C)...
WYBOT C1(OS7010C) IN PANORAMICA Panoramica interna del prodotto Spia LED Diversi colori chiari per indicare lo stato del Porta di ricarica dispositivo Collegare il cavo di ricarica Maniglia Traccia Rimuovere e trasportare con sé il dispositivo Migliora la capacità del dispositivo di...
Panoramica esterna del prodotto Cestello filtro Parte sigillata Conservare lo sporco e i detriti raccolti, devono Lì vengono sigillati i componenti più essere lavati dopo ogni utilizzo. importanti. Per la vostra sicurezza, non tentate di smontarlo senza autorizzazione. Non utilizzare l'apparecchio se il coperchio superiore o le spazzole sono rotti. Se si verifica una perdita di liquido dalla parte sigillante, interrompere la ricarica o il funzionamento del dispositivo.
INIZIARE Ricarica il tuo nuovo WYBOT C1(OS7010C) Il dispositivo è dotato di una batteria ricaricabile agli ioni di litio ed è necessario caricare la batteria prima del primo utilizzo e quando la batteria è scarica. Collega il tuo dispositivo a una presa di corrente utilizzando il cavo e l'adattatore inclusi.
è scarica quando si accende il dispositivo ed è necessario caricarlo immediatamente. Connettiti alla tua App Puoi scaricare l'app WYBOT sul tuo dispositivo mobile intelligente eseguendo la sca- nsione del codice QR riportato di seguito o da Google Play o App Store. Android iOS 15.0 o successivo...
Scegli la modalità di pulizia Dopo esserti connesso alla tua app, puoi preimpostare una modalità di pulizia adatta al tuo dispositivo. Sono disponibili 4 modalità di pulizia e puoi vedere i dettagli di seguito. Gamma di pulizia Modalità Pulizia completa della piscina Muro+Pavimento+Linea di galleggiamento Solo sul pavimento della piscina Pavimento...
Se si selezionano cicli diversi da quello predefinito, è necessario tenere il pulitore nella piscina per completare cicli interi. Esegui il tuo nuovo WYBOT C1(OS7010C) Afferrare la maniglia del pulitore e immergerlo nella piscina entro 3 minuti, altrimenti il dispositivo si spegnerà.
Page 109
Dopo circa 20 secondi di calibrazione L'aspirapolvere inizia a pulire pareti, automatica sul pavimento, la spia pavimento e linea di galleggiamento diventerà blu lampeggiante. L'aspi- come impostazione predefinita o nel rapolvere è pronto per pulire. set. Il dispositivo si sposterà automatica- È...
EFFETTUARE UNA PULIZIA DEL FILTRO Afferrare la maniglia del coperchio del filtro, premerla e aprirla. Anmerkung: 1. È necessario assicurarsi che il dispositivo sia spento quando si apre il coperchio superiore. 2. È necessario pulire il cestello del filtro prima che si asciughi. Rimuovere il filtro a cestello Svuotare tutti i detriti e sciacquarli con acqua pulita.
Disponibile GARANZIA LIMITATA 1. Tutti i pulitori per piscine WYBOT presenti sul mercato sono stati ispezionati e autorizzati per la vendita in conformità alle leggi locali. 2. La durata della garanzia per batteria, motore e PCB è di due (2) anni dalla data di acquisto.
4. Eventuali danni all'unità causati da uso improprio, riparazione non autorizzata o smontaggio non sono coperti dalla garanzia WYBOTICS Co., Ltd. 5. Per qualsiasi reclamo o riparazione entro il periodo di garanzia è necessario presentare il numero o la registrazione dell'ordine. COME CONSERVARE IL DISPOSITIVO È...
Page 113
Problemi Dettagli Cause possibili Soluzione suggerita La girante è Controllare la girante e pulire le Il dispositivo Una luce rossa bloccata impurità non funziona fissa Una luce rossa Protezione del Ricomincia lampeggiante motore Non mettere il Riavviare e metterlo Una luce rossa dispositivo in acqua immediatamente in piscina.
CERTIFICAZIONE I robot pulitori per piscine WYBOT hanno superato tutti i test di prestazione e affidabilità e hanno anche ottenuto le certificazioni pertinenti dai paesi in cui vengono venduti. puoi stare tranquillo. SERVIZIO CLIENTI WYBOT In considerazione della necessità di un continuo miglioramento dei prodotti, i prodotti illustrati nel manuale sono soggetti ai prodotti reali e WYBOTICS Co., Ltd.
Page 116
www.wybotpool.com www.wybotpool.com E-mail: support@wybotpool.com Facebook: @WybotPool WYBOTICS CO., LTD .30, Zhongnan 4th Street West Zone, TEDA Tianjin, Cina Tutti i nomi commerciali sono marchi registrati dei rispettivi produttori elencati.
Need help?
Do you have a question about the C1 and is the answer not in the manual?
Questions and answers
where does the floating block go?
@Bob and **** Oppelt
For tiled surfaces, the floating block attachment should be installed on the WYBOT C1 robotic pool cleaner. Follow the installation steps shown in the provided video.
This answer is automatically generated
cleaner never adds to the app. I click the +, I see the machine, then add the network, select the pool... then it goes back and no machine is added. only a box with a + sign.....
The WYBOT C1 cleaner may not be adding to the app after selecting the network and pool because the device might not be powered on or in pairing mode. You need to push and hold the power button until the front light turns green to ensure it's discoverable. Additionally, ensure it is connected via Bluetooth and Wi-Fi. If it's still not adding, a firmware update or network issue may be preventing the connection.
This answer is automatically generated
blue light comes on, place it in the water and after a few seconds ... it goes off. try it aga in and purple light stays on... what should I do???
If the blue light on the WYBOT C1 turns off after being placed in water and the purple light stays on, it may indicate the cleaner was not placed in the pool within the required time after activation. The device should be turned on again, and once the light turns blue, it must be placed in the water within about 3 minutes to prevent it from turning off automatically.
This answer is automatically generated
Is there a finer filter for this?
The WYBOT C1 has a fine mesh screen that effectively catches small particles, including fine sand from a sand filter. There is no specific mention of an ultrafine or finer filter being available beyond this built-in mesh.
This answer is automatically generated
where is the video to attach the float nbloc?
The context does not provide a specific video showing how to attach the float nbloc for the WYBOT C1. It suggests contacting customer service for proper placement instructions.
This answer is automatically generated
How to install the float nlock
To install the floating kit (referred to as "float nlock") for the WYBOT C1:
1. Attach it to the cleaner using the hook on your pool pole, similar to how you would attach a leaf net.
2. The floating kit includes multiple pieces; align and connect them as shown in the demonstration.
3. Some pieces may not be required depending on your pool, but if the robot has trouble climbing walls, install the full kit.
4. Once attached, ensure the components are secure before placing the cleaner in the pool.
The floating kit helps improve wall-climbing performance.
This answer is automatically generated
The WYBOT App does not provide for programming on my smartphone. How can I set up my cleaning cycles?
If the app does not allow programming on your smartphone, you cannot set up cleaning cycles for the WYBOT C1. The cleaning cycles must be scheduled through the app.
This answer is automatically generated
How to put wybot in pairring mode
To put the WYBOT C1 in pairing mode, press and hold the power button until the LED light turns green. This indicates the device is ready to connect. Make sure Bluetooth is enabled on your mobile device.
This answer is automatically generated
Can I clean the filter by stopping the machine half way through its cycle
Yes, the WYBOT C1 filter can be cleaned by stopping the machine, but it should be powered off before opening the top cover. The filter basket needs to be removed, emptied, rinsed with clean water, and reinserted before closing the cover.
This answer is automatically generated
How do I know if the bot is turned off before charging?
