Summary of Contents for Renault TRIBER 2024

  • Page 1 vehicle user manual...
  • Page 3 Welcome aboard your vehicle This vehicle user manual contains the information necessary: – for you to familiarise yourself with your vehicle, to use it to its best advantage and to benefit fully from the all the functions and the technical developments it incorporates. –...

  • Page 4: Table Of Contents

    CONTENTS Starting, stopping the engine - vehicle with key .... 64 Welcome aboard your vehicle ..........4 Gear lever, hand brake ..........68 Driving aids ..............4 Special features of petrol versions ........ 69 Getting to know your vehicle..........6 Driver correction devices, aids ........
  • Page 5 Weights (in kg)............. 171 Replacement parts and repairs ........172 Service sheets ............. 173 Anticorrosion check ............. 179 Renault new vehicle warranty ........... 184 Renault new vehicle warranty........184 Maintenance Appendix............192 Maintenance Appendix ..........192 Service and maintenance........... 195...

  • Page 6: 4 - We L C O M E A B O A R D Y O U R V E H I C L E

    DRIVING AIDS 4 - We l c o m e a b o a r d y o u r v e h i c l e...
  • Page 7 DRIVING AIDS 1. ABS (anti-lock braking system) �� 70 ESC (electronic stability control) �� 71 Braking assistance �� 70 Hill start assistance �� 72 2. Tyre pressure loss warning �� 82 3. Parking distance control �� 92 4. Reversing camera �� 94 We l c o m e a b o a r d y o u r v e h i c l e - 5...

  • Page 8: 6 - G E T T I N G T O K N O W Y O U R V E H I C L E

    KEYS, RADIO FREQUENCY REMOTE CONTROL Radio frequency remote control General information key B Driver’s responsibility when parking or stop­ Key A ping the vehicle Never leave an animal, child or adult who is not self-suffi- cient alone in your vehicle, even for a short time.
  • Page 9 KEYS, RADIO FREQUENCY REMOTE CONTROL Interference by factors in the immedi- ate vicinity (external installations or the Replacement and addi­ use of equipment operating on the tional keys or remote same frequency as the remote control) controls. may affect the operation of the remote You must only contact an ap- control.

  • Page 10: Radio Frequency Remote Control

    RADIO FREQUENCY REMOTE CONTROL Un locking the doors Driver’s responsibility when parking or stop­ Remote controls is used to lock or un- ping the vehicle lock the doors. Never leave an animal, They are powered by a battery which child or adult who is not self-suffi- can be replaced.

  • Page 11: Card

    CARD Battery life General information When the battery is flat, Make sure that the correct battery type you can still lock/unlock is being used, and that the battery is in and start your vehicle. Re- good condition and inserted correctly. fer to the information on “Locking/ Its service life is approximately two years : replace it when the message...
  • Page 12 CARD Note : Pressing button 4 again switch- es off the lighting. Driver’s responsibility when parking or stop­ ping the vehicle Advice Never leave an animal, Avoid leaving the card in child or adult who is not self-suffi- hot, cold or humid areas. cient alone in your vehicle, even Do not keep the card in a place for a short time.

  • Page 13: Hands-Free" Card

    “HANDS-FREE” CARD Using the card in “hands-free” mode Driver’s responsibility when parking or stop­ There are two ways to unlock/lock the ping the vehicle vehicle : Never leave an animal, – the card in “hands-free” mode ; child or adult who is not self-suffi- –...
  • Page 14 “HANDS-FREE” CARD lights up approximately for four sec- “hands-free” remote locking is dis- onds accompanied by a single beep abled. sound. Using the card as a remote control Special features of the locking sys­ If a door is open or not properly closed, when you go away, the vehicle is not locked.
  • Page 15 “HANDS-FREE” CARD Note : The maximum distance at Locking/unlocking only the boot which the vehicle locks depends on the surroundings. Special features If an opening element (a door or the luggage compartment) is open or not properly closed, the vehicle cannot be locked.
  • Page 16 “HANDS-FREE” CARD Driver’s responsibility when parking or stop­ ping the vehicle Never leave an animal, child or adult who is not self-suffi- cient alone in your vehicle, even for a short time. They may pose a risk to them- selves or to others by starting the engine, activating equipment such as the electric windows or locking the doors, for example.

  • Page 17: Locking And Unlocking The Doors

    LOCKING AND UNLOCKING THE DOORS The card’s built-in key Access with key 2 If the remote control The integrated 2 key is used to lock or or,depending on the vehicle, the unlock the front right-hand door if the card does not work card does not work.
  • Page 18 LOCKING AND UNLOCKING THE DOORS Vehicles with key/remote con- Interior locking/unlocking door trol control From the inside Push in button 5 to lock and lift button 5 to unlock. It is impossible to open From outside If equipped, It simultaneously locks or the door if 5 is pushed in.
  • Page 19 LOCKING AND UNLOCKING THE DOORS the 6 switch for more than five sec- onds. Driver’s responsibility when parking or stop­ When the door is closed, all the doors and the tailgate will be locked. ping the vehicle Never leave an animal, Unlocking the vehicle from the outside is only possible with the card in the ve- child or adult who is not self-suffi-...

  • Page 20: Opening And Closing The Doors

    OPENING AND CLOSING THE DOORS Opening from the inside Child safety Opening the doors from the out- side Pull handle 2 . If equipped, this feature is to make it impossible for the rear doors to be With the doors unlocked �� 15, place opened from the inside, move lever 3 on each rear door and check from the your hand on the handle 1 and pull to-...
  • Page 21 OPENING AND CLOSING THE DOORS Depending on the vehicle, this alarm is fitted to the driver’s side door or on all Driver’s responsibility opening elements. when parking or stop­ With the vehicle at a standstill, a warn- ping the vehicle Never leave an animal, ing light will come on if a door or the...

  • Page 22: Engine Immobiliser

    ENGINE IMMOBILISER (Depends on vehicle) Any unauthorised work Engine Immobiliser prevents the ve­ carried out on the engine hicle from being driven by anyone immobiliser (computers, not in possession of the vehicle’s wiring, etc.) could be coded ignition key. dangerous. Work must be carried Operating principle out by qualified personnel.

  • Page 23: Front Seats

    FRONT SEATS To tilt the seatback Move forward or backward For safety reasons, carry out any adjustments when the vehicle is not being driven. Nothing should be placed on the floor (area in front of driver) as such objects may slide under the pedal during braking manoeuvres, thus obstructing its use.

  • Page 24: Seat Belts

    SEAT BELTS – adjust the seats (seat position and Always wear your seat belt when trav- seatback angle, if available); Incorrectly adjusted or elling in your vehicle. You must also – sit with your back firmly against the twisted seat belts may comply with the legislation of the par- seatback;...
  • Page 25 SEAT BELTS Unlocking of each of the rear seat belts every When the vehicle speed reaches or time: exceeds 12 mph (20 km/h), if one of Press the button 4 on latch 5 and the the rear seat belts is or becomes un- –...
  • Page 26 SEAT BELTS – the 7 symbol is displayed for at least into the latch (check that it is locked by 65 seconds and the symbol for the pulling on the buckle). seat concerned changes to red. Adjusting the rear seat belts Always make sure that the rear pas- sengers are properly fastened in and that the number of seat belts indicated...
  • Page 27 SEAT BELTS – No modification may be made to the compo- nent parts of the original- ly fitted restraint system: seat belts, seats and their mountings. For special operations (e.g. fitting child seats), contact an autho- rised dealer. – Do not use devices which allow any slack in the belts (e.g.
  • Page 28 SEAT BELTS – When the rear bench seat is being put back, make sure that the seat belts and buckles are correctly positioned so that they can be used properly. – Make sure that the buckle is in- serted into the appropriate catch. –...

  • Page 29: Methods Of Restraint In Addition To The Front Seat Belts

    METHODS OF RESTRAINT IN ADDITION TO THE FRONT SEAT BELTS Pretensioners Depending on the vehicle, they will consist of : – Have the entire re- straint system checked – seat belt inertia reel pretension­ ers ; following an accident. – chest­level load limiters ; –...
  • Page 30 METHODS OF RESTRAINT IN ADDITION TO THE FRONT SEAT BELTS the belt against the body so that it is at an acceptable level. Airbags for driver and front pas- senger Fitted to the driver and passenger side. The presence of this equipment is indi- cated by the word “Air bag”...
  • Page 31 METHODS OF RESTRAINT IN ADDITION TO THE FRONT SEAT BELTS Operating faults The following cases cause the pre­ In a frontal impact with another ve­ tensioners or airbags to operate. hicle of an equivalent or higher cat­ egory, with an impact area equal to In a frontal impact against a rigid This warning light 2 will light up...
  • Page 32 METHODS OF RESTRAINT IN ADDITION TO THE FRONT SEAT BELTS – impacts to the underside of the vehi- cle from kerbs, for example ; – potholes ; – a fall or a hard landing ; – stones. – in the event of a side impact, affect- ing the front of the vehicle ;...
  • Page 33 METHODS OF RESTRAINT IN ADDITION TO THE FRONT SEAT BELTS All of the warnings below are given so that the air bag is not obstructed in any way when it is inflated and also to pre­ vent the risk of serious injuries caused by items which may be dislodged when the air bag inflates. Warnings concerning the driver’s air bag –...

  • Page 34: Side Protection Devices

    SIDE PROTECTION DEVICES Side Airbags Warnings concerning Depending on vehicle, these airbags the side air bag may be fitted at the sides of the front seats and are deployed at the sides of – Fitting seat covers : the seats (door side) to protect the oc- seats equipped with an airbag re- cupants in the event of a severe side quire covers specifically designed...

  • Page 35: Child Safety

    CHILD SAFETY General information It is recommended that chil- A collision at 50 km/h is dren and infants are seated the same as falling a dis- Carrying children in child restraint. You tance of 10 metres. choose a child restraint that fits Transporting a child Children, and adults, must be correctly your vehicle.
  • Page 36 CHILD SAFETY which seats are recommended for your vehicle. Before fitting a child seat, read Driver’s responsibility Never leave a child unat- the manual and respect its instruc- when parking or stop­ tended in the vehicle. tions. If you experience any difficulties ping the vehicle Check that your child is during installation, contact the manu-...
  • Page 37 CHILD SAFETY Check that the seat is correctly held by seatback to avoid contact between the moving it from side to side and back to seat and the child’s legs. Fit the child seat in rear front : the seat should remain firmly seat.
  • Page 38 CHILD SAFETY Since front passenger airbag triggering and the position of a rear-facing child seat are incompati- ble, NEVER use a rear-facing child restraint on a seat with an airbag. The airbag could cause SERI­ OUS OR FATAL INJURY if inflat­ 3 6 - G e t t i n g t o k n o w y o u r v e h i c l e...

  • Page 39: Child Seats

    CHILD SEATS Attachment by seat belt G e t t i n g t o k n o w y o u r v e h i c l e - 3 7...
  • Page 40 CHILD SEATS RISK OF DEATH OR SERIOUS INJURY : never fit a child seat on the front seat if the vehicle has a passenger airbag which cannot be deactivated. Using a child safety system which is not approved for this vehicle will not correctly protect the baby or child. They risk serious or even fatal injury.
  • Page 41 CHILD SEATS Installation table The table below summarises the information already shown in the diagram on the following pages, to ensure the applicable reg- ulations are respected. Seating Position Second row seats Third row seats Mass Group Weight of the child Front passenger seat LEFT RIGHT...

  • Page 42: Driving Position, Right-Hand Drive

    DRIVING POSITION, RIGHT-HAND DRIVE Driving position, right-hand drive 4 0 - G e t t i n g t o k n o w y o u r v e h i c l e...
  • Page 43 DRIVING POSITION, RIGHT-HAND DRIVE 21 . Rear console cooled box The presence of the equipment DE­ 22 . Gear lever PENDS ON THE VEHICLE VERSION 23. Location for cup holder AND COUNTRY. 24. USB/AUX port (for changing + me- 1 . Left side air vent dia connect) 2 .

  • Page 44: Rear View Mirrors

    REAR VIEW MIRRORS knob 1 to position D and then to posi- Exterior rear view mirror tion B to reset. Objects observed in the door mirror glass are ac- tually closer than they For safety reasons, carry appear. For your safety, out any adjustments take this into account in order to when the vehicle is not...

  • Page 45: Steering Wheel, Power-Assisted Steering

    STEERING WHEEL, POWER-ASSISTED STEERING turn the steering wheel. The force re- Steering wheel height adjust- quired will be greater. ment Never leave the steering wheel at full lock while sta- tionary. For safety reasons, only adjust the steering wheel when the vehicle is sta- tionary.

  • Page 46: Warning Lights

    WARNING LIGHTS The presence and operation of the Dipped beam headlight tell­ warning lights DEPEND ON THE tale. EQUIPMENT AND COUNTRY. Left-hand direction indicator tell-tale. Right-hand direction indicator tell-tale. Gear change indicator This lights up to advise you to change to a higher gear (up arrow) or lower gear (down arrow).
  • Page 47 WARNING LIGHTS Secondary Warning This lights up when the ignition is switched on and goes out after a few When vehicle speed exceeds around Warning light means seconds. 120 km/h (75 MPH), a beep sounds for you should drive very care- If it does not goes out after the ignition every 2 seconds until the driver re- is switched on, or lights up when dri-...
  • Page 48 WARNING LIGHTS Urgent stop warning light (red) ommendation, you risk damaging your If it comes on while driving, this means vehicle. there is a system fault. Contact an au- This lights up when the ignition is thorised dealer. switched on and goes out as soon as The presence and operation of the the engine is started and is accompa- warning lights DEPEND ON THE...
  • Page 49 WARNING LIGHTS Coolant temperature warning display This bar display comes ON when igni- tion is ON and remains lit permanently (or) depending on the variant, the warning light goes off after few sec- onds Depending on the variants,if it blinks (or) gets ON when driving, this means the engine is overheating.

  • Page 50: Displays And Indicators

    DISPLAYS AND INDICATORS Fuel level warning display 4 �� 44 Instrument panel A Instrument panel B Trip Computer 2 This is applicable depending on the variant. This is applicable depending on the variant. It lights up when the ignition is switched on.
  • Page 51 DISPLAYS AND INDICATORS Average fuel economy 14 Instantaneous/Average fuel con­ Service due reminder display 12 sumption 5 Display to change the settings 15 Rev counter (rpm X1000) 6 This display will allows you to cus- Trip distance recorder 7 tomise the brightness of the display in both day and night mode.
  • Page 52 DISPLAYS AND INDICATORS Fuel economy history display 16 Warning lights indicator 17, 18 When driving, if multiple tell-tale lights triggered, the lights 17, 18 will rotate for every 4 seconds. 5 0 - G e t t i n g t o k n o w y o u r v e h i c l e...

  • Page 53: Trip Computer

    TRIP COMPUTER Resetting the trip mileage General information To reset the trip mileage recorder, the display must show the Trip meter func- Trip computer A tion. Press and hold button 1 . Interpreting some of the values displayed after resetting The values showing average fuel con- sumption, range and average speed will become more stable and reliable...
  • Page 54 TRIP COMPUTER Resetting is automatic when the maxi- mum capacity of any of the memories is exceeded. 5 2 - G e t t i n g t o k n o w y o u r v e h i c l e...

  • Page 55: Trip Distance Recorder

    TRIP COMPUTER Journey parameters The display of information shown below DEPENDS ON THE VEHICLE EQUIPMENT AND COUNTRY. DISPLAY Interpreting the display selected Total distance recorder Trip distance recorder Fuel used (since the last time the reset button was pressed) Average fuel consumption (since the last time the reset button was pressed) This value is displayed after driving 400 metres.
  • Page 56 TRIP COMPUTER The display of information shown below DEPENDS ON THE VEHICLE EQUIPMENT AND COUNTRY. DISPLAY Interpreting the display selected SERVICE Mileage before service Service INTERVALS With the ignition switched on, the engine not running and the display set to 1000KM/ “SERVICE INTERVALS”, press the button 1 or 2 for approximately 10 seconds 12month...

  • Page 57: Clock

    CLOCK Display A If the power supply is cut (battery disconnected, sup- ply wire cut, etc.), the clock must be reset. We recommend that you do not To access the display 2 for setting the adjust these settings while dri- time, press button 1 and Wait a few ving.

  • Page 58: Exterior Lighting And Signals

    EXTERIOR LIGHTING AND SIGNALS return to dipped headlight,pull the stalk 3 upward. Switching off the lights Turn the end of stalk 3 until the symbol is opposite mark 2 . Headlight flasher : Pull stalk 3 to- wards you to flash the headlights. Daytime running lights function (front lights only) If fitted on the vehicle, the daytime run-...

  • Page 59: Headlight Beam Adjustment

    HEADLIGHT BEAM ADJUSTMENT thest seats occupied Driver + Lug­ gage in boot Passenger in all seats Passenger in all seats + Luggage in boot Knob A is used to adjust height of the headlight beam according to load. Turn knob A anticlockwise to lower the beams and clockwise to raise them.

  • Page 60: Audible And Visual Signals

    AUDIBLE AND VISUAL SIGNALS Hazard warning lights Direction indicators Horn Move stalk 3 parallel to the steering Press switch 2 . Press on the centre or sides of the wheel and in the direction you are go- highlighted (horn pad) 1 to use the ing to turn it.

  • Page 61: Windscreen Washing, Wiping

    WINDSCREEN WASHING, WIPING Windscreen washer Efficiency of a wiper blade With the ignition on, pull stalk 1 Check the condition of the towards you. wiper blades. How long they last A brief pull will trigger a single sweep depends on you: of the wipers, in addition to the wind- screen washer.
  • Page 62 WINDSCREEN WASHING, WIPING Rear screen wiper – by pressing button 3 again (the warning light goes out). Do not use the wiper arm to open or close the tailgate. Heated rear screen With the ignition on, turn the end of stalk 1 to align the symbol with mark 2 .

  • Page 63: Fuel Tank

    FUEL TANK Capacity of the fuel tank : 40 litres approximately. To fill up with fuel, the engine must be stopped (and not only in standby for the vehicle fitted with the Stop and Start function) : you MUST switch off the ignition. Fire hazard.
  • Page 64 FUEL TANK – Never place the cap near a source of heat or flame. – Do not add any additives to the fuel, you risk damaging the en- gine. If you notice a persistent fuel odour you should : – stop the vehicle as soon as traffic conditions allow and switch off the ignition ;...

  • Page 65: Driving

    RUNNING IN, IGNITION SWITCH Stop and steering lock position Start position D Running in If the engine fails to start at the first at- For the first 1,000 km, do not exceed tempt, turn the key back to home posi- 80 km/h in the highest gear.

  • Page 66: Starting, Stopping The Engine - Vehicle With Key

    STARTING, STOPPING THE ENGINE - VEHICLE WITH KEY – driving for long periods when the low Starting the engine fuel level warning light is lit. Driver’s responsibility – using leaded petrol. when parking or stop­ In cold condition: switch on the ignition –...
  • Page 67 STARTING, STOPPING THE ENGINE - VEHICLE WITH KEY The card must be in detection zone 1 . Special features Accessories function To start : – If one of starting conditions is not ap- (switching on the ignition) plied, the message “BRAKE + START” –...
  • Page 68 STARTING, STOPPING THE ENGINE - VEHICLE WITH KEY Driver’s responsibility when parking or stop­ ping the vehicle Never leave an animal, child or adult who is not self-suffi- cient alone in your vehicle, even for a short time. They may pose a risk to them- selves or to others by starting the engine, activating equipment such as the electric windows or locking...
  • Page 69 STARTING, STOPPING THE ENGINE - VEHICLE WITH KEY ton. Without the card, you will not be able to restart the vehicle. Never switch off the igni- tion before the vehicle With the engine switched off, any ac- cessories being used (radio, etc.) will has stopped completely.

  • Page 70: Gear Lever, Hand Brake

    GEAR LEVER, HAND BRAKE Handbrake Selecting reverse gear An impact to the under- side of the vehicle while manoeuvring (e.g. : strik- ing a post, raised kerb or other street furniture) may result in damage to the vehicle (e.g. : deformation of an axle).

  • Page 71: Special Features Of Petrol Versions

    SPECIAL FEATURES OF PETROL VERSIONS engine (using the start button, or by The following operating conditions : pushing or towing the vehicle) without – driving for long periods when the low having identified and corrected the fuel level warning light is lit ; –...

  • Page 72: Driver Correction Devices, Aids

    DRIVER CORRECTION DEVICES, AIDS ABS (anti-lock braking system) Depending on the vehicle, this is com- Under some driving or cli- posed of : Under heavy braking, the ABS pre- matic conditions, occasion- – the ABS (anti­lock braking sys­ vents the wheels from locking, allowing al brake squeaks, squeals tem) ;...
  • Page 73 DRIVER CORRECTION DEVICES, AIDS The system is for detecting an emer- Electronic stability program hicle when pulling away accelerating gency braking situation. In this case, or decelerating. ESC with understeer control the braking assistance immediately de- and traction control velops maximum power and may trig- Deactivating the ESC function ger ABS regulation.
  • Page 74 DRIVER CORRECTION DEVICES, AIDS A sensor in the steering wheel detects brake pedal to depress the accelerator the direction selected by the driver. pedal. The hill start assistance system cannot complete- Other sensors throughout the vehicle System operation measure the actual direction. The sys- ly prevent the vehicle It only operates when the gear selector tem compares driver input to the actual...

  • Page 75: Take A Break Reminder

    TAKE A BREAK REMINDER – By pressing the switch 3 “Take A The take a break reminder lets you set Break” function will appear on the dis- This function is an addi- a reminder to take a break 1 , when the play.
  • Page 76 TAKE A BREAK REMINDER – Once switching ON the “Take A – Once switching ON the “Take A Break” function and it will enter to the Break” function and it will enter to the Feature options. Feature options. – By pressing the switch 3 “SET DIS- –...
  • Page 77 TAKE A BREAK REMINDER in 30 seconds or vehicle speed reach- es 0 km/h (0 mph)) and with 3 seconds chime. – It is advisable to stop as soon as possible for a selected break time. – If user not taken break after alert message, this message will reappear in every 30 minutes or 50km.

  • Page 78: Driving Advice And Eco Driving

    DRIVING ADVICE AND ECO DRIVING Gear change indicator 1 Depending on the vehicle, to obtain Fuel consumption is accredited in ac- optimum consumption levels, a warn- cordance with a standard regulatory ing light on the instrument panel lets method. Identical for all manufacturers, you know the best time to move up or this enables vehicles to be compared down a gear:...
  • Page 79 DRIVING ADVICE AND ECO DRIVING From the multimedia screen 2 en- Driving advice, Eco-driving – Dynamic driving involving heavy abling you to view information on your and frequent acceleration and brak- last journey. ing is expensive on fuel in compari- son to the time saved;...
  • Page 80 DRIVING ADVICE AND ECO DRIVING Driver obstruction On the driver’s side, only use mats suitable for the vehicle, attached with the pre-fitted components, and check the fitting regularly. Do not lay one mat on top of another. There is a risk of wedging the pedals.
  • Page 81 DRIVING ADVICE AND ECO DRIVING Advice for reducing consumption and helping to preserve the environ­ ment: If the vehicle has been parked in the sun, open the doors for a few mo- ments to let the hot air escape before starting the engine.

  • Page 82: Maintenance And Antipollution Advice

    MAINTENANCE AND ANTIPOLLUTION ADVICE longer complies with anti-pollution reg- Your vehicle complies with criteria for This warning light on the instru- ulations. recycling and recovering vehicles at ment panel will indicate if there are any the end of their service life, which en- Have your vehicle adjusted and faults in the system : tered into force in 2015.

  • Page 83: Environment

    ENVIRONMENT Please make your own contri- Your vehicle has been designed with bution towards protecting the respect for the environment in mind environment too for its entire service life : during pro- duction, use and at the end of its life. –...

  • Page 84: Tyre Pressure Loss Warning

    TYRE PRESSURE LOSS WARNING When the low pressure warning light il- position. The light will remains ON af- luminates you should stop and adjust ter the 1 Minute, along with the electri- the tyre pressure to the recommended cal warning tell tale or warning light COLD tyre pressure.
  • Page 85 TYRE PRESSURE LOSS WARNING Reinitialisation is carried out after a few minutes’ driving. This function is an addi- tional driving aid. Resetting procedure The function does not (depending on vehicle) take the place of the dri- ver. It cannot, therefore, under any circumstances replace the vigilance or the responsibility of the driver.
  • Page 86 The light remains on after one minute. 1 warning light comes ON contact your Renault dealer as soon as possible for tyre replacement. along with 2 warn-...
  • Page 87 TYRE PRESSURE LOSS WARNING verely under inflated. Replace the tyre if it is punctured. – Sensor Failure Illuminates and turned OFF or Illumi- nates continuously as Orange colour This indicates a system fault. Please consult an authorised dealer. System unavailable Warning light 1 flashes for sev- eral seconds, then stays ON.
  • Page 88 TYRE PRESSURE LOSS WARNING The information on the instrument panel signals any potential tyre pressure faults (e.g. deflated or punctured tyre). Indicator Text warning Messages Readings lights in cluster RR TYRE PR.LOW RL TYRE When the tyre pressure loss warning is displayed in yellow. This indicates that PR.LOW Adjust Tyre tyre under-inflation has been detected.
  • Page 89 TYRE PRESSURE LOSS WARNING (depending on vehicle) The information on the instrument panel signals any potential tyre pressure faults (e.g. deflated or punctured tyre). Indicator Messages Text warning in cluster Readings lights When the tyre pressure loss warning & service warning light displayed Adjust Tyre in yellow.

  • Page 90: Automated Manual Transmission

    AUTOMATED MANUAL TRANSMISSION Gear shift pattern Instrument panel Display Gear Shifter 1 2 : automatic mode. (see the marking on the lever) This allows you to engage forward + : Manually moving up a gear 3 : brake pedal press indicator light. gear, reverse and neutral.
  • Page 91 AUTOMATED MANUAL TRANSMISSION If any gear other than neutral is en- – The engine’s idle speed is sufficient gaged, N flashes on the display ; press for parking manoeuvres. Once the vehicle is the brake pedal and place the lever in –...
  • Page 92 AUTOMATED MANUAL TRANSMISSION Creeping to the low engine speed limit to avoid stalling. The vehicle may be kept sta- Avoid selecting D/R mode It is a function that enables the vehicle tionary (stop, red light etc.) by de- after switching off the en- to move slowly without pressing accel- pressing the brake pedal without shift- gine.
  • Page 93 AUTOMATED MANUAL TRANSMISSION moment and at a suitable engine It is recommended to shift to Manual speed because automatic mode takes mode from Auto mode with most into consideration the road surface and adopted gear, to have quick accelera- the chosen driving style. tion during overtaking.

  • Page 94: Parking Distance Control

    PARKING DISTANCE CONTROL Operating principle Ultrasonic sensors, fitted in the vehicle’s rear bumper, measure the distance between the vehicle and an obstacle when reversing. This measurement is indicated by beeps which become more frequent the closer you come to the obstacle, until they become a continuous beep when the vehicle is approximately 35 centimetres from the obstacle.
  • Page 95 PARKING DISTANCE CONTROL This function is an addi- tional aid that indicates the distance between the vehicle and an obstacle whilst reversing, using sound sig- nals. Under no circumstances should it replace the driver’s care or re- sponsibility whilst reversing. The driver should always be ready for sudden incidents while driving : always ensure that there...

  • Page 96: Reversing Camera

    REVERSING CAMERA Operation This function is an addi- tional aid. It cannot, therefore, under any cir- cumstances replace the vigilance or the responsibility of the driver. The driver should always pay at- tention to sudden incidents during driving : always ensure that there are no moving obstacles (such as a child, animal, pram, bicycle, etc.) or small, narrow objects...
  • Page 97 REVERSING CAMERA Static guide line 3 : The static guide line 3 has coloured markers A , B and C showing the dis- tance behind the vehicle : – A (red) approximately 30 centime- tres from the vehicle ; – B (yellow) approximately 70 cen- timetres from the vehicle ;...

  • Page 98: Your Comfort

    AIR VENTS, AIR OUTLETS Air outlets 9 6 - Yo u r c o m f o r t...
  • Page 99 AIR VENTS, AIR OUTLETS 1. Left side air vents 2. Windscreen demisting vents 3. Centre air vents 4. Right side vents 5. Control panel 6. Driver footwell outlets 7. Front passenger footwell outlets Yo u r c o m f o r t - 9 7...
  • Page 100 AIR VENTS, AIR OUTLETS Centre Air Vents Rear Air Vents Air flow (depends on the vehicle) Depending on variants, rear air vents 10 is fitted on the second row pillar Lateral Air vents(Left and Right) – To move the front vanes up/down, trim.
  • Page 101 AIR VENTS, AIR OUTLETS Rear roof Air Vents Depending on variants, roof air vents 11 is fitted on the roof rear side of the vehicle. Do not add anything to the vehicle’s ventilation circuit (for example, to remove bad odours). There is a risk of damage or of fire.

  • Page 102: Heating, Ventilation, Air Conditioning

    HEATING, VENTILATION, AIR CONDITIONING Controls The controls will depend on the vehicle equipment level. 1. Distribution of Air. 2. Adjusting the ventilation fan speed. 3. Switching passenger compartment to isolation mode / air recirculation mode. 4. Air temperature adjuster 5. Switching air conditioning on/off (if light gets ON, it indicates the air conditioning system is ON). 1 0 0 - Yo u r c o m f o r t...
  • Page 103 HEATING, VENTILATION, AIR CONDITIONING Information and advice on use �� 103. Yo u r c o m f o r t - 1 0 1...
  • Page 104 HEATING, VENTILATION, AIR CONDITIONING Switching passenger compart- Adjusting the air temperature Prolonged use of air recir- ment isolation mode/air recircu- lation mode on. culation can lead to con- Turn control 4 to obtain the desired densation forming on the temperature. The further towards the windscreen, and discomfort due red the slide is, the higher the temper- Bring lever 3 to position...

  • Page 105: Air Conditioning

    AIR CONDITIONING Check that the controls are set correct- Information and advice on use ly and that the fuses are sound. Other- wise, switch off the system. Fuel consumption Presence of water under the vehi- You will normally notice an increase in fuel consumption (especially when dri- After prolonged use of the air condi- ving in town) when the air conditioning...

  • Page 106: Windows

    WINDOWS Electric window Manual window winders Electric window Depending on the variants, use 6 to Depending on the variants, turn handle 7 to lower or raise the window to the Press/pull the switch to raise/lower the raise/lower the rear passenger win- windows to the desired height (the rear dows to the desired height.
  • Page 107 WINDOWS When closing the win- Closing windows can dows, ensure that no cause serious injury. part of the body (arm, hand, etc.) is protruding from the vehicle. Risk of serious injury. Avoid resting any objects against a half-open win- dow : there is a risk that the electric window could be dam- Driver’s responsibility aged.

  • Page 108: Interior Lighting

    INTERIOR LIGHTING Front Map reading light Rear Courtesy light Front Courtesy light This feature depends on the vehicle This feature depends on the vehicle This feature depends on the vehicle version. version. version. 2. Pressing switch provides : 3. Press switch to position 1.

  • Page 109: Sun Visor/Grab Handle

    SUN VISOR/GRAB HANDLE Rear Grab handle 2 Front sun visor This offers support and can be held Lower the sun visor 1 over the wind- when the vehicle is being driven, Do screen or unclip it and turn it over the not use it for getting into or out of the side window.

  • Page 110: Passenger Compartment Storage

    PASSENGER COMPARTMENT STORAGE Cooled Glovebox Centre console Storage 4 Upper Glove Box Depending on the variant, opening/ Cup Holder 5 Depending on variant, Press 1 to open closing the valve 3 along the arrow di- the upper glove box. rection will enable/disable the cooling inside glove box.
  • Page 111 PASSENGER COMPARTMENT STORAGE Front door storage 7 Rear door storage 8 Ensure that no hard, heavy or pointed objects are placed in the “open” storage compartments in such a way that they may fall onto passengers during sudden turn- ing, braking or in the event of an accident.
  • Page 112 PASSENGER COMPARTMENT STORAGE Third row armrest storage 9 Depending on variants, front seat stor- age available behind the front seat backrest. Front seat storage 10 11 0 - Yo u r c o m f o r t...

  • Page 113: Accessories Socket

    ACCESSORIES SOCKET Accessories socket 1, 2 Connect accessories It is provided for connecting acces- with a maximum power sories approved by our technical de- of 120 watts (12 V) partment. only.When several ac- cessory sockets are used at the same time, the total power of the connected accessories must not exceed 180 watts.

  • Page 114: Rear Seats

    REAR SEATS To recline the second row seat To slide the second row seat When refitting the seat­ back rest back, make sure it is correctly locked in place. If seat covers are fit­ ted, make sure these do not pre- vent the seatback latch from lock- ing in.
  • Page 115 REAR SEATS To tumble the second row back- It is not permitted to drive rest-left side seat the car while second row seat is in tumbled condition as it leads to damage to the pas- senger in the third row. When returning the back- –...
  • Page 116 REAR SEATS – Follow the same steps in reverse – Follow the same steps in reverse manner to assemble the seat backrest. manner to assemble the seat cushion Make sure that the seat- back is correctly locked. NOTE: Gap 3 between third row seat back and cushion will allow the cus- If necessary, remove any tomer to grab the seatback and remov-...

  • Page 117: Boot

    BOOT To open The attaching of any car- rying device (bike rack, luggage box etc) resting on the luggage compart- ment lid is prohibited. To install a carrying device on your vehicle, contact an authorised dealer. Opening the tail gate manually from the inside If it is impossible to unlock the tailgate From the outside...

  • Page 118: Longitudinal Roof Bars

    LONGITUDINAL ROOF BARS For information on the range of equipment adapt- ed to your vehicle, we ad- vise you to consult an approved Dealer. Refer to the manufacturer’s instructions for in- formation on how to fit and oper- ate the equipment. Please keep these instructions with the rest of the vehicle docu- ment.

  • Page 119: Multimedia Equipment

    MULTIMEDIA EQUIPMENT Hands-free telephone integrat- ed control – In all cases, it is very im- portant to follow the manufacturer’s instructions care- fully. – The specifications of the brack- ets and wires (available from our network) vary depending on the equipment level of your vehicle and the type of radio.
  • Page 120 MULTIMEDIA EQUIPMENT On equipped vehicles, use : Using the telephone – 3 select the audio source. We remind you of the – 4 Scroll to navigate the list with need to conform to the press function. – 5 Volume decrease “-”. legislation in force con- –...

  • Page 121: Maintenance

    BONNET Do not press down on The engine may be hot the bonnet : there is a during operations in risk that the bonnet may close proximity. In addi- accidentally close. tion, the engine cooling fan may come on at any moment. Risk of injury.
  • Page 122 BONNET Ensure that the bonnet is properly locked. Ensure that nothing is preventing locking (grit, cloths, etc.). Make sure nothing is left in the engine compart- ment (cloth, tools, etc.). These may damage the engine or cause a fire. 1 2 0 - M a i n t e n a n c e...

  • Page 123: Engine Oil Level

    ENGINE OIL LEVEL Reading the oil level Topping up, filling Exceeding the maxi­ mum engine oil level It is normal for an engine to use oil for Under no circumstances lubrication and cooling of moving parts must the maximum fill and it is normal to top up the level be- level be exceeded : risk of dam- tween oil changes.
  • Page 124 ENGINE OIL LEVEL Topping up/Filling – wait for approximately 20 minutes to allow the oil to flow into the engine. The engine may be hot – check the level using the dipstick 2 during operations in (as described above). close proximity. In addi- Once the level has been read, ensure tion, the engine cooling that the “cap-type dipstick”...
  • Page 125 ENGINE OIL LEVEL Exceeding the maxi­ mum engine oil level The oil level should only be read with the dipstick as explained above. If the oil level exceeds the maximum level, do not start your vehicle and con- tact an approved dealer. Filling and/or Checking the oil level : Take care when topping...

  • Page 126: Levels, Filters

    LEVELS, FILTERS Topping up Coolant level Brake fluid level After any operation on the hydraulic circuit, a specialist must replace the brake fluid. Only use fluids approved by our Tech- nical Department (and taken from a sealed container). Replacement interval Refer to the Maintenance Document for your vehicle.
  • Page 127 LEVELS, FILTERS Check the coolant level regularly (very Engine switched off : severe damage is likely to be caused Before carrying out any – open the cap 3 ; to the engine if it runs out of coolant). action in the engine –...
  • Page 128 LEVELS, FILTERS When working in the en- For your safety, do not gine compartment, en- remove the bonnet hold- sure that the windscreen ing straps. wiper stalk is in the park Risk of the bonnet position. falling on the road surface. Risk of injury.

  • Page 129: Battery

    BATTERY Handle the battery with For your safety and the care as it contains sul- proper operation of the phuric acid, which must vehicle’s electrical equip- not come into contact ment (lights, windscreen with eyes or skin. If it does, wash wipers, braking assistance etc.), the affected area with plenty of any work on the 12 V battery (re-...
  • Page 130 BATTERY The engine may be hot during operations in close proximity. In addi- tion, the engine cooling fan may start at any moment. Risk of injury. Before carrying out any action in the engine compartment, you must switch off the ignition. Label A Observe the indications on the bat- For your safety, do not...

  • Page 131: Tyre Pressure

    TYRE PRESSURE Adhere to the tyre pressures (including For vehicles used fully the emergency spare wheel). The tyre laden (maximum per­ pressures should be checked at least once a month and additionally before missible all-up weight) any long journey. The maximum speed Tyre pressures should always be must be limited to (62 mph) checked when the tyres are cold, ig-...

  • Page 132: Bodywork Maintenance

    BODYWORK MAINTENANCE – mud in the wheel arches and under- cal Department to protect them after A well-maintained vehicle will last neath the body which forms damp they have been cleaned. longer. It is therefore recommended to patches ; maintain the exterior of the vehicle reg- –...
  • Page 133 BODYWORK MAINTENANCE proved by our Technical Wash the vehicle using Department : a high-pressure cleaning – mechanical compo- device. nents (e.g. : engine compartment) ; Using a roller type car wash – underbody ; – parts with hinges Return the wiper stalk to the park (e.g.

  • Page 134: Interior Trim Maintenance

    INTERIOR TRIM MAINTENANCE Seat belts A well-maintained vehicle will last For further recommenda- longer. It is therefore recommended to These must be kept clean. tions for maintaining the in- maintain the interior of the vehicle reg- Use products selected by our Techni- ularly.
  • Page 135 INTERIOR TRIM MAINTENANCE You are strongly recom- mended not to use high- pressure or spray clean- ing equipment inside the passenger compartment : use of such equipment could impair the correct functioning of the electri- cal or electronic components in the vehicle, or have other detri- mental effects.

  • Page 136: Practical Advice

    PUNCTURE, EMERGENCY SPARE WHEEL – fold the third row seat back to the Spare Wheel 2 desired position. Do not loosen the bolt ex- cessively, otherwise the spare wheel cradle may fall If the vehicle is parked suddenly. on the hard shoulder, you must warn other road users of your vehicle’s presence with a warning...
  • Page 137 PUNCTURE, EMERGENCY SPARE WHEEL Warnings Avoid sudden acceleration or de- Note: Ensure that the celeration and reduce your speed emergency spare wheel or when cornering. If the emergency spare punctured wheel are cor- wheel has been stored rectly positioned. Check that the for several years, have it boot carpet is correctly positioned checked by your Dealer...

  • Page 138: Wheel Trim, Tools

    WHEEL TRIM, TOOLS Accessing the tools Central wheel trim with visible wheel bolts Depending on the vehicle, to access the tools: Depending on the version, the bolts – move the second row right side seat 1 in forward direction �� 112; are directly accessible or after remov- ing the wheel cap 1 .
  • Page 139 WHEEL TRIM, TOOLS lease knob 6 . Swing out the lever 7 and take out the jack 2 . To store the For safety reasons, the jack after use, ensure the jack is locat- use of a jack not recom- ed in the same position, swing out the mended by the manufac- lever 7 again and tighten the knob 6 .

  • Page 140: Changing A Wheel

    CHANGING A WHEEL Vehicles equipped with a jack should be underneath the vehicle and aligned with the jack head). and wheel wrench Turn it a few times to lift the wheel off If necessary, remove the wheel trim. the ground. Unlock the wheel bolts using the wheel Undo the bolts and take off the wheel.
  • Page 141 CHANGING A WHEEL Do not leave the tools For safety reasons, the unsecured inside the ve- use of a jack not recom- hicle as they may be mended by the manufac- projected during braking. turer is strictly forbidden. After use, check that all the tools The jack is specific to the vehicle are correctly clipped into the tool and used to change the wheels.

  • Page 142: Tyres

    TYRES Maintaining the tyres surfaced minor roads will lead to more The tyres are the only contact between rapid tyre wear and affect safety. the vehicle and the road, so it is es- sential to keep them in good condition. You must make sure that your tyres Incidents which occur conform to local road traffic regula-...
  • Page 143 TYRES Swapping needs to be done along with wheel balancing and wheel alignment. Incorrect tyre pres­ Please be aware that a sures lead to abnormal poorly tightened or miss- Emergency spare wheel tyre wear and unusually ing valve cap can make Refer to the information on the “Emer- hot running.
  • Page 144 TYRES Changing a wheel Snow chains may only In all cases, we would rec- As the tyre pressure be fitted to tyres of the ommend that you contact monitor may take sever- same size as those origi- an authorised dealer who al minutes to correctly nally fitted to your vehi­...

  • Page 145: Headlights, Lights: Changing Bulbs

    HEADLIGHTS, LIGHTS: CHANGING BULBS Unclip the connector 5 , remove the Exterior lighting: changing bulbs assembly from its housing and take out the bulb. Front headlights: changing the Bulb type: H7. bulbs Main beam hexadlight 2 Remove the cover A . Remove the cover B .
  • Page 146 HEADLIGHTS, LIGHTS: CHANGING BULBS Unclip the connector 7 , remove the assembly from its housing and take Any operation on (or out the bulb. modification to) the elec- Bulb type: W5W. trical system must be performed by an ap- Direction indicator lights 4 proved Dealer since an incorrect turn the bulb holder 8 a quarter of a connection might damage the...
  • Page 147 HEADLIGHTS, LIGHTS: CHANGING BULBS unscrew the nut 6 and clips to release the light assembly from the outside of the vehicle by pulling towards the out- side. Rotate bulb holders 2 & 3 in anti- open the luggage compartment lid. clockwise direction and remove the remove the panel 4 by removing the bulbs.
  • Page 148 HEADLIGHTS, LIGHTS: CHANGING BULBS To re-fit, proceed in the reverse order Remove the bulb 11 from the holder. taking care not to damage the wiring, Bulb type: W5W. tighten screws 1 first. Refitting LED high-level brake light 8 To refit, proceed in the reverse order, taking care not to damage the wiring.
  • Page 149 HEADLIGHTS, LIGHTS: CHANGING BULBS Bulb type: WY5W. Replace the bulb and refit the indicator light. Interior lighting: changing bulbs Front courtesy light 1 Side indicator lights 13 Make a quarter of a turn (movement 15 ) on the bulb holder 16 and remove (depending on the vehicle) the bulb 17 (movement 18 ).
  • Page 150 HEADLIGHTS, LIGHTS: CHANGING BULBS – Remove the bulb from the holder 4 . Bulb type: Festoon tube 12V. Refitting – clip in the courtesy light 3 until your hear the click; – ensure that the interior lights are properly positioned and locked into place.

  • Page 151: Fuses

    FUSES Removing the fuses Remove the fuse, located at the back of flap A from position. To remove the fuse, slide the fuse. It is not advisable to use the free fuse locations. The engine may be hot when working in close proximity.
  • Page 152 FUSES Allocation of fuses in the passenger compartment (presence of some fuses DEPENDS ON VEHICLE EQUIPMENT LEVEL) 1 5 0 - P r a c t i c a l a d v i c e...
  • Page 153 FUSES Rear power window Backup light/Rear wiper Num­ Allocation BCM/Radio/Ultra low cost Wiper motor navigation BCM/Fuel pump relay/ Defroster/Front power win- Hands-free mode starter relay/Injection ECU/ Power transmission control Hands-free mode unit/Automatic gear selector Reverse lights/Front blower (Manual transmission) Not used Electric power steering Day light Running lamps Starter - Non Hands-free...
  • Page 154 FUSES Right hand side head light - Low beam Position lamp First row accessory socket Front power window -Nor- mal/Anti-pinch Power window Anti-pinch 48 ,49 Not used 1 5 2 - P r a c t i c a l a d v i c e...

  • Page 155: Battery

    BATTERY Starting the vehicle using the bat- Troubleshooting tery from another vehicle Some batteries may have specific conditions If you have to use the battery from an- To avoid all risk of sparks : for recharging. Consult other vehicle to start, obtain suitable your approved dealer.
  • Page 156 BATTERY Check that there is no contact between leads A and B and that the posi- tive lead A is not touch- ing any metal parts on the vehicle supplying the current. Risk of serious injury and/or dam- age to the vehicle. Connect the positive cable (+) A to the (+) terminal 1 of the discharged bat- tery, then to the (+) terminal 2 of the...

  • Page 157: Radio Frequency Remote Control

    RADIO FREQUENCY REMOTE CONTROL Batteries Operating faults If the battery is too weak to ensure cor- rect operation, you can still start and lock/unlock the vehicle �� 16 When replacing : – make sure that the batteries are correctly in- serted.
  • Page 158 RADIO FREQUENCY REMOTE CONTROL Precautions relating to Do not throw away your batteries : used batteries ; give them to an organisation responsi- – keep (new or used) ble for collecting and recycling batteries out of reach of children ; batteries.

  • Page 159: Hands Free Card

    HANDS FREE CARD Replacing the battery When refitting, proceed in the reverse Operating faults order, then press one of the buttons on If the battery is too weak to ensure cor- the card four times, close to the vehi- rect operation, you can still start and When the message “Keycard Battery cle : the message will disappear.
  • Page 160 HANDS FREE CARD Do not throw away your When they need to be used batteries ; give them replaced, be sure to use to an organisation responsi- the same or equivalent ble for collecting and recycling type of battery (consult batteries.

  • Page 161: Windscreen Wiper - To Lift/Replace Wiper Blades

    WINDSCREEN WIPER - TO LIFT/REPLACE WIPER BLADES Check the condition of the wiper blades. You are re- sponsible for their service life : – clean the blades, windscreen and rear screen regularly with soapy water ; – do not use them when the wind- screen or rear screen are dry ;...

  • Page 162: Towing

    TOWING ton for 2 seconds. Shift the gear lever to N (position N in automatic Do not remove the key transmission vehicle). The steering col- from the ignition when umn gets unlocked and accessory the vehicle is being mode gets ON to have the brake lights towed.
  • Page 163 TOWING It is prohibited to hang the car to lower arm or Rear Axle. To hang car there is a specific place provided. P r a c t i c a l a d v i c e - 1 6 1...

  • Page 164: Installation And Use Of Accessories

    INSTALLATION AND USE OF ACCESSORIES Electrical and electronic accessories Before installing this type of accessory (particularly for transmitters/receivers: frequency bandwidth, power level, position of the aerial, etc.), make sure it is compatible with your vehicle. Contact an approved dealer. Before connecting an accessory to a socket, ensure that it does not exceed the maximum power authorised for the socket ��...
  • Page 165 INSTALLATION AND USE OF ACCESSORIES On the driver's side, only use mats suitable for the vehicle, attached with the pre-fitted components, and check the fitting regularly. Do not lay one mat on top of another. There is a risk of wedging the pedals. P r a c t i c a l a d v i c e - 1 6 3...

  • Page 166: Operating Faults

    OPERATING FAULTS The following advice will enable you to carry out quick, temporary repairs. For safety reasons you should always con­ tact an approved dealer as soon as possible. The starter is activated POSSIBLE CAUSES WHAT TO DO Warning lights dim or fail to Battery terminals disconnected, oxi- Retighten them, reconnect them or clean them if they come on ;...
  • Page 167 OPERATING FAULTS On the road POSSIBLE CAUSES WHAT TO DO Smoke under the bonnet. Short circuit or cooling system leak. Stop, switch off the ignition, move away from the vehicle and contact an approved dealer. The oil pressure warning light comes on : on a bend or under brak- The engine oil level is too low.
  • Page 168 OPERATING FAULTS POSSIBLE On the road WHAT TO DO CAUSES The direction indicators do not Faulty electrical Consult an approved dealer. work. circuit. The headlights do not switch on Faulty electrical Consult an approved dealer. or off. circuit or control. Abnormal white smoke from the Mechanical fault : Stop the engine.

  • Page 169: Technical Specifications

    IDENTIFICATION PLATES Please quote the information on the Engine identification plate B The information shown on the vehi­ engine plate or label B in all corre­ cle identification plate should be Identification number spondence or orders. quoted on all correspondence or or­ ders.

  • Page 170: Engine Specifications

    ENGINE SPECIFICATIONS Versions 1.0 12V Engine type BR10DE / B4D (see engine plate) Cubic capacity (cc) Petrol. Type of fuel octane rating The use of unleaded petrol is essential. It is preferable to use fuel with octane rating 91 and higher. Only use spark plugs specified for your vehicle’s engine.

  • Page 171: Dimensions (In Metres)

    DIMENSIONS (IN METRES) (in metres) Te c h n i c a l s p e c i f i c a t i o n s - 1 6 9...
  • Page 172 DIMENSIONS (IN METRES) (*) unladen - without roof bar (**) unladen - with roof bar 1 7 0 - Te c h n i c a l s p e c i f i c a t i o n s...

  • Page 173: Weights (In Kg)

    WEIGHTS (IN KG) (in kg) The weights indicated for a basic vehicle without options : they vary depending on your vehicle’s equipment. Consult your approved Dealer. Minimum Weight - Unladen condition 905 Kg (Depending on vehicle) Maximum Weight - Unladen condition 951 Kg (Depending on vehicle) Maximum Weight - Laden condition...

  • Page 174: Replacement Parts And Repairs

    REPLACEMENT PARTS AND REPAIRS Original parts are based on strict specifications and are subject to highly specialized tests. Therefore, they are of atleast the same level of quality as the parts fitted originally. If you fit genuine replacement parts always to your vehicle, it will perform well. Furthermore, repairs carried out within manufac- turers network using original parts are guaranteed according to the conditions set out on the reverse of repair order.

  • Page 175: Service Sheets

    SERVICE SHEETS VIN: .................. Date: Miles (km): Invoice number: Comments/miscellaneous Type of operation: Stamp Service □ ........□ Anticorrosion check: OK □ Not OK* □ Date: Miles (km): Invoice number: Comments/miscellaneous Type of operation: Stamp Service □ ........□ Anticorrosion check: OK □...
  • Page 176 SERVICE SHEETS VIN: .................. Date: Miles (km): Invoice number: Comments/miscellaneous Type of operation: Stamp Service □ ........□ Anticorrosion check: OK □ Not OK* □ Date: Miles (km): Invoice number: Comments/miscellaneous Type of operation: Stamp Service □ ........□ Anticorrosion check: OK □...
  • Page 177 SERVICE SHEETS VIN: .................. Date: Miles (km): Invoice number: Comments/miscellaneous Type of operation: Stamp Service □ ........□ Anticorrosion check: OK □ Not OK* □ Date: Miles (km): Invoice number: Comments/miscellaneous Type of operation: Stamp Service □ ........□ Anticorrosion check: OK □...
  • Page 178 SERVICE SHEETS VIN: .................. Date: Miles (km): Invoice number: Comments/miscellaneous Type of operation: Stamp Service □ ........□ Anticorrosion check: OK □ Not OK* □ Date: Miles (km): Invoice number: Comments/miscellaneous Type of operation: Stamp Service □ ........□ Anticorrosion check: OK □...
  • Page 179 SERVICE SHEETS VIN: .................. Date: Miles (km): Invoice number: Comments/miscellaneous Type of operation: Stamp Service □ ........□ Anticorrosion check: OK □ Not OK* □ Date: Miles (km): Invoice number: Comments/miscellaneous Type of operation: Stamp Service □ ........□ Anticorrosion check: OK □...
  • Page 180 SERVICE SHEETS VIN: .................. Date: Miles (km): Invoice number: Comments/miscellaneous Type of operation: Stamp Service □ ........□ Anticorrosion check: OK □ Not OK* □ Date: Miles (km): Invoice number: Comments/miscellaneous Type of operation: Stamp Service □ ........□ Anticorrosion check: OK □...

  • Page 181: Anticorrosion Check

    ANTICORROSION CHECK If the continuation of the warranty is subject to repair, it is indicated below. VIN: .................. Date of repair: Stamp Corrosion repair operation to be carried out: Date of repair: Stamp Repair to be carried out: Te c h n i c a l s p e c i f i c a t i o n s - 1 7 9...
  • Page 182 ANTICORROSION CHECK If the continuation of the warranty is subject to repair, it is indicated below. VIN: .................. Date of repair: Stamp Corrosion repair operation to be carried out: Date of repair: Stamp Repair to be carried out: 1 8 0 - Te c h n i c a l s p e c i f i c a t i o n s...
  • Page 183 ANTICORROSION CHECK If the continuation of the warranty is subject to repair, it is indicated below. VIN: .................. Date of repair: Stamp Corrosion repair operation to be carried out: Date of repair: Stamp Repair to be carried out: Te c h n i c a l s p e c i f i c a t i o n s - 1 8 1...
  • Page 184 ANTICORROSION CHECK If the continuation of the warranty is subject to repair, it is indicated below. VIN: .................. Date of repair: Stamp Corrosion repair operation to be carried out: Date of repair: Stamp Repair to be carried out: 1 8 2 - Te c h n i c a l s p e c i f i c a t i o n s...
  • Page 185 ANTICORROSION CHECK If the continuation of the warranty is subject to repair, it is indicated below. VIN: .................. Date of repair: Stamp Corrosion repair operation to be carried out: Date of repair: Stamp Repair to be carried out: Te c h n i c a l s p e c i f i c a t i o n s - 1 8 3...

  • Page 186: Renault New Vehicle Warranty

    (parts, consumables and labour) of any material or assembly defect duly found in the vehicle, at their own request, as well as any repairs on damage caused by this defect to other vehicle parts. It is the authorised RENAULT Dealer’s discretion to decide whether it is appropriate to repair or replace the defective part, whilst keeping the Customer informed, 3.2 24/7 assistance services as defined in the “Renault Assistance”...
  • Page 187 4.6.3 Misuse, abuse, negligence, improper driving habits, theft etc. of the vehicle; 4.6.4 Damage from stress, like use of vehicles in races, rallies, etc., 4.6.5 Use of parts other than Renault Genuine Parts. 4.6.6 Any device and/or accessories not supplied by RIPL.
  • Page 188 NAULT authorized network and not observing the manufacturer’s recommendations on the subject. 5.3 By way of consideration for the parts supplied by RIPL under the RENAULT New Vehicle Warranty, parts replaced under this warranty legally become the property of RIPL.
  • Page 189 6.4.1 The Assistance services are exclusively provided by Renault Assistance. 6.4.2 RIPL and Renault authorized dealers shall not be liable to reimburse the Customer for the expenses/ cost of repair or re- placement of any parts or any labour charges or any other expenses incidental or ancillary thereto, if the Customer does not avail theservices of Renault Assistance as detailed herein.
  • Page 190 6.6.2 Cab Assistance: If customer vehicle is recovered to a dealer by Renault Assistance, the driver and passengers will be provided with one free cab ride, only up to 50 Kms., from the breakdown location, to facilitate them to continue their onward journey. Cost of travel beyond 50 Kms., from the breakdown location, and for any other expenses incurred by the Customer, shall be paid by the Customer and...
  • Page 191 7.4 The Renault Anticorrosion Warranty does not cover: 7.4.1 Any damage which is not covered by the RENAULT New Vehicle Warranty, as defined at the start of this booklet; 7.4.2 Mechanical components which are not an integral part of the bodywork or sub-frame (wheel rims, exhaust system, etc.).
  • Page 192 8.4 The RENAULT Paintwork Warranty does not cover: 8.4.1 any damage which is not covered by The RENAULT New Vehicle Warranty, as defined at the start of this booklet; 8.4.2 damage due to force majeure events: lightning, fire, floods, earthquakes, war, riots and attacks;...
  • Page 193 Renault ofers “Renault Secure” Integrated Extended Warranty and Roadside Assistance Program on select models, in addition to the new vehicle warranty. Kindly Contact 1800 315 44 44 (Toll Free number) or your nearest Renault Dealer for more details. Check for options and prices at https://www.renault.co.in/renault-services/renault-secure.html...

  • Page 194: Maintenance Appendix

    The RENAULT service applies to all RENAULT vehicles and always includes oil change, oil filter replacement, checks, top-ups and a check of your vehicle’s electronic system. The RENAULT service is carried out at the service intervals specified in the maintenance program for your vehicle.
  • Page 195 – Prolonged use (+5000 km / year) in temperatures below -15℃, – Use of fuels that don’t correspond to RENAULT recommendations, (See User Manual booklet). – For diesel engines with Particles Filter, the use of an other engine oil than the one recommended by RENAULT may damage the Particles Filter.
  • Page 196 MAINTENANCE APPENDIX Algeria, Andorra, Azerbaijan, Belarus, Bolivia, Colombia, Costa Rica, Ivory Cost, Cuba, Ecuador, Ethiopia, Georgia, Gautemala, the Republic of Guinea-Bissau, Guyana, Honduras, the Channel Islands, the Cayman islands, the Canary Islands, the Comoros Islands, the Faroe Islands, the United States Virgin Islands, India, Ireland, Liberia, Leichtenstein, Macedonia, Mali, Monaco, Namibia, Nepal, Nicaragua, Niger, Norway, New Zealand, Uganda, Uzbekistan, Panama, Paraguay, Ceuta peninsula, the Czech Republic, Russia, Rwanda, San Marino, El Salvador, Sudan, Switzerland, Tanzania, Thailand, Turkmenistan, Turkey, Ukraine, Vatican City, Vietnam,...

  • Page 197: Service And Maintenance

    SERVICE AND MAINTENANCE In order to ensure economical and safe vehicle operation and to maintain the value of your vehicle, it is of vital importance that all maintenance work is carried out at the proper intervals as specified. Confirmation of service is recorded in the Owner's Manu- al.
  • Page 198 SERVICE AND MAINTENANCE Period- Time or mileage - Whichever is earlier Main- ten- ance Every Sched- 1 Year 2 Year 3 Year 4 Year 5 Year 6 Year 7 Year 8 Year 9 Year Year Year Year ule - PETROL Spark 60,000 plug...
  • Page 199 SERVICE CHECKS THE FOLLOWING CHECKS MUST BE CARRIED OUT DURING EVERY SERVICE Sl.No. Check the wiper blades and screen washer fluid levels Check the condition of the windscreen and door mirrors Check the operation of the instrument panel warning lights Check the exhaust pipe Check the levels, condition and sealing of the hydraulic power-assisted steering circuit (if fitted) Check the levels, condition and sealing of the brake/clutch circuit...
  • Page 200 SERVICE CHECKS THE FOLLOWING CHECKS MUST BE CARRIED OUT DURING EVERY SERVICE Documentation and positioning of the maintenance label Drain the water from the fuel filter Engine oil change alert reinitialisation 1 9 8 - S e r v i c e a n d m a i n t e n a n c e...
  • Page 201 ALPHABETICAL INDEX Symbols A B C D E F G H I K L M N O P R S T V W Symbols Child seats, Cigar lighter, »hands-free » card : use, Cleaning : inside the vehicle, Closing the doors, Control instruments, Accessories socket, Courtesy light,...
  • Page 202 ALPHABETICAL INDEX Fuel economy, Fuel tank, Maintenance, Fuses, Maintenance : bodywork, Maintenance : interior trim, Maintenance : mechanical, Gear lever, Map reading lights, Methods of restraint in addition to the seat belts, Multimedia equipment, Handbrake, Hands-free telephone integrated control, Heating and air conditioning system, 100, Navigation, Heating system,...
  • Page 203 ALPHABETICAL INDEX Remote control door locking unit, Wheel trim, Reverse gear selecting, Windows, Reversing sensor, Windscreen washer, Wipers, Seat belt pretensioners front seat belt, Seat belts, Sequential gearbox, Signals and lights, Starting, Starting the engine, Steering wheel adjustment, Storage compartment, Storage compartments, Tailgate, Telephone,...
  • Page 206 RENAULT S.A.S. SOCIÉTÉ PAR ACTIONS SIMPLIFIÉE AU CAPITAL DE 533 941 113 € / 122-122 BIS, AVENUE DU GENERAL LECLERC 92100 BOULOGNE-BILLANCOURT R.C.S. NANTERRE 780 129 987 — SIRET 780 129 987 03591 / renaultgroup.com NU 1321-6 – 99 91 085 16V – 06/2024 – Edition anglaise...

Table of Contents
