ASROCK VISION 3D SERIES Brochure page 3

Vision 3D
Head phone
1
Microphone
2
2 x USB3.0 ports
3
Slot-in Optical Disc Drive
4
5 4-in-1 Card reader (MMC/SD/MS/MS Pro)
6 Power ON/OFF button with status indicator
7 DC-In jack
Optical S/PDIF Out port
8
9 Audio Jack x5
10 LAN (RJ-45) port
11
1 x USB3.0 port
12
5 x USB 2.0 ports
13
DVI-I port
14
eSATAII connector
15
HDMI connector
The specification is subject to change without notice. The brand and product names are trademarks of their respective companies. Any configuration other than original product specification is not guaranteed.
1 2
10
7
8
11
9
HTPC Series
3 4
5
13
14 15
Vision 3D, 3D Your Vision
6
12
