Summary of Contents for ASROCK DeskMini B660 Series

  • Page 2 Version 1.0 Published January 2021 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
  • Page 3 If you require assistance please call ASRock Tel : +886-2-28965588 ext.123 (Standard International call charges apply) The terms HDMI®...
  • Page 4 ES OF ANY KIND WHETHER UNDER THIS AGREEMENT OR OTHERWISE, EVEN IF INTEL HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. LICENSE TO USE COMMENTS AND SUGGESTIONS. This Agreement does NOT obligate Licensee to provide Intel with comments or suggestions regarding the Software. However, if Licensee provides Intel with comments or suggestions for the modification, correction, improvement or enhancement of (a) the Software or (b) Intel products or processes that work with the Software, Licensee grants to Intel a non-exclusive, worldwide,...

  • Page 5: Table Of Contents

    Contents Chapter 1 Introduction Package Contents Specifications Chapter 2 Product Overview Front View Rear View Motherboard Layout Chapter 3 Hardware Installation Begin Installation Installing the CPU Installing the CPU Fan and Heatsink Installing Memory Modules (SO-DIMM) Installing the WiFi Module Installing the M.2 SSD (Type 2280) Installing the 2.5-inch HDD/SSD Complete...
  • Page 6 Introduction EZ Mode Advanced Mode 5.3.1 UEFI Menu Bar 5.3.2 Navigation Keys Main Screen OC Tweaker Screen Advanced Screen 5.6.1 CPU Configuration 5.6.2 Chipset Configuration 5.6.3 Storage Configuration 5.6.4 ACPI Configuration 5.6.5 USB Configuration 5.6.6 Trusted Computing Tools Hardware Health Event Monitoring Screen Security Screen 5.10 Boot Screen...

  • Page 7: Chapter 1 Introduction

    DeskMini B660 series Chapter 1 Introduction Thank you for purchasing DeskMini B660 series barebone system. In this documentation, Chapter 1 and 2 contains the introduction of the barebone system and step-by-step installation guides. Chapter 3 contains the guide of hardware installation.

  • Page 8: Specifications

    1.2 Specifications System DeskMini B660 • Model Chassis • 1.92L (155 x 155 x 80mm) • Supports 12 Gen Intel® Core Processors (LGA1700) CPU cooling • Supports Standard Intel Box Fan Coolers Mother- • B660M-STX board ® Chipset • Intel B660 Graphics • Intel®...
  • Page 9 DeskMini B660 series Storage • 2 x SATA3 6.0 Gb/s Connectors • 1 x Blazing M.2 Socket (M2_1, Key M), supports type 2280 PCIe Gen5x4 (128 Gb/s) mode • 1 x Hyper M.2 Socket (M2_2, Key M), supports type 2280 PCIe Gen4x4 (64 Gb/s) mode* * Supports Intel®...

  • Page 10: Chapter 2 Product Overview

    Chapter 2 Product Overview This chapter provides diagrams showing the location of important components of the DeskMini B660 Barebone system series. 2.1 Front View Description Power Button Power LED HDD LED MIC-In USB 3.2 Gen2x2 Type-C Port USB 3.2 Gen2 Type-A Port Headphone/Headset...

  • Page 11: Rear View

    DeskMini B660 series 2.2 Rear View Description *Specification for DC plug DC Jack (Supports 19V DC Power Adapters) 5.5 mm D-Sub Port HDMI Port 2.5 mm USB 2.0 Ports USB 3.2 Gen1 Type-A Ports USB 3.2 Gen2 Type-C Port ( USB-C / DP Alt mode ) DisplayPort 1.4...

  • Page 12: Motherboard Layout

    2.3 Motherboard Layout CPU_FAN1 DC Jack USB 3.2 Gen2 USB_3 CLRMOS1 Mic In USB 3.2 Gen2x2 USB_2 USB 2.0 T: USB_4 PANEL1 B: USB_5 PLED PWRBTN USB_8_9 Intel USB 3.2 Gen2 USB_1 HDLED RESET B660 Top: USB 3.2 Gen1 T: USB_6 RJ-45 Headphone B: USB_7...
  • Page 13 DeskMini B660 series Back Side View M2_2 SATA3 SATA3...
  • Page 14 No. Description CPU Fan Connector (CPU_FAN1) 2 x 260-pin DDR4 SO-DIMM Slots (DDR4_A1, DDR4_B1) Clear CMOS Jumper (CLRMOS1) System Panel Header (PANEL1) USB 2.0 Header (USB_8_9) MONO Speaker Header (SPEAKER1) Audio Header (AUDIO3) CPU Fan Connector (CPU_FAN2) SATA3 Connector (SATA2) SATA3 Connector (SATA1)
  • Page 15 DeskMini B660 series Jumpers Setup The illustration shows how jumpers are setup. When the jumper cap is placed on the pins, the jumper is “Short”. If no jumper cap is placed on the pins, the jumper is “Open”. Clear CMOS Jumper...
  • Page 16 Onboard Headers and Connectors Onboard headers and connectors are NOT jumpers. Do NOT place jumper caps over these headers and connectors. Placing jumper caps over the headers and connectors will cause permanent damage to the motherboard. System Panel Header Connect the power PLED+ PLED- (9-pin PANEL1)
  • Page 17 DeskMini B660 series MONO Speaker Header Please connect the chassis Front_L- speaker to this header. (4-pin SPEAKER1) Front_L+ Front_R+ (see p.6, No. 6) Front_R- Serial ATA3 Connectors These two SATA3 (see p.7, No. 9 and 10) connectors support SATA data cables for internal...
  • Page 18 Audio Header This Audio header allows you to (5-pin AUDIO3) connect the audio cable for head- Audio-R (see p.6, No. 7) phone. Audio-L Jack detect...

  • Page 19: Chapter 3 Hardware Installation

    DeskMini B660 series Chapter 3 Hardware Installation 3.1 Begin Installation 1. Unscrew the four screws of the back panel. 2. Pull out the motherboard tray while holding the handle .

  • Page 20: Installing The Cpu

    3.2 Installing the CPU 1. Before you insert the 1700-Pin CPU into the socket, please check if the PnP cap is on the socket, if the CPU surface is unclean, or if there are any bent pins in the socket. Do not force to insert the CPU into the socket if above situation is found.
  • Page 21 DeskMini B660 series Please save and replace the cover if the processor is removed. The cover must be placed if you wish to return the motherboard for after service.

  • Page 22: Installing The Cpu Fan And Heatsink

    3.3 Installing the CPU Fan and Heatsink DeskMini B660 series supports both Intel CPU Box Fan (65W) and third-party CPU fan cooler. Please note that the DeskMini B660 series chassis has 52mm height limitation for the CPU fan cooler.

  • Page 23: Installing Memory Modules (So-Dimm)

    This motherboard provides two 260-pin DDR4 (Double Data Rate 4) SO-DIMM slots. 1. DeskMini B660 series requires DDR4 SO-DIMM. 2. For dual channel configuration, you always need to install identical (the same brand, speed, size and chip-type) DDR4 SO-DIMM pairs.

  • Page 24: Installing The Wifi Module

    3.5 Installing the WiFi Module 1. Insert the WiFi Module Card into the M.2 Slot for WiFi + BT Module. 2. Tighten the screw to secure the WiFi Module Card to the motherboard. 3. Attach the SMA Wi-Fi Antenna Cables to the WiFi Module.

  • Page 25: Installing The M.2 Ssd (Type 2280)

    DeskMini B660 series 3.6 Installing the M.2 SSD (Type 2280) 1. Locate the M.2 slot on the motherboard. 2. Carefully insert the M.2 SSD into the slot. 3. Tighten the screw to secure the M.2 SSD to the motherboard.

  • Page 26: Installing The 2.5-Inch Hdd/Ssd

    3.7 Installing the 2.5-inch HDD/SSD 1. Place another HDD/SSD on the tray B shown in Step 1. Then turn the motherboard tray upside down and secure the HDD/SSD with the four screws. *Removing the motherboard before installing the second HDD/SSD. 2.
  • Page 27 DeskMini B660 series 4. Place another HDD/SSD on the tray B shown in Step 1. Then turn the motherboard tray upside down and secure the HDD/SSD with the four screws. *Removing the motherboard before installing the second HDD/SSD. 5. Connect the SATA Data and Power Cable to the HDD/SSD.

  • Page 28: Complete

    3.8 Complete 1. Connect the power button cable to the System Panel Header on the motherboard. 2. Align the motherboard tray with the two sliding tracks on the chassis while sliding it back to the chassis. Sliding Track 3. Then refasten the four screws that you removed earlier.

  • Page 29: Installing The Vesa Bracket (Optional)

    DeskMini B660 series 3.9 Installing the VESA Bracket (Optional) 1. Secure the VESA Bracket to the right side panel of the DeskMini B660 series by using the four screws. 2. Attach the other VESA Bracket to the rear of a compatible display using the four screws.
  • Page 30 4. Complete.

  • Page 31: Installing The Wifi Antennas (Optional)

    DeskMini B660 series 3.10 Installing the WiFi Antennas (Optional) 1. Insert the Wi-Fi Antenna Connectors to the antenna ports on the rear panel of the DeskMini B660 series *Please make sure to align the flat surface of Wi-Fi Antenna Connectors with the flat side of holes when inserting the connectors.
  • Page 32 4. Set the WiFi 2.4/5 GHz Antenna at 90-degree angle. *You may need to adjust the direction of the antenna for a stronger signal.

  • Page 33: Chapter 4 Auto Driver Installer

    DeskMini B660 series Chapter 4 Auto Driver Installer After you install the Windows OS and boot into the system, a notification will pop up to help you to install and update required drivers.

  • Page 34: Chapter 5 Uefi Setup Utility

    Chapter 5 UEFI SETUP UTILITY 5.1 Introduction This section explains how to use the UEFI SETUP UTILITY to configure your system. You may run the UEFI SETUP UTILITY by pressing <F2> or <Del> right after you power on the computer, otherwise, the Power-On-Self-Test (POST) will continue with its test routines.

  • Page 35: Ez Mode

    DeskMini B660 series 5.2 EZ Mode The EZ Mode screen appears when you enter the BIOS setup program by default. EZ mode is a dashboard which contains multiple readings of the system’s current status. You can check the most crucial information of your system, such as CPU speed, DRAM frequency, SATA information, fan speed, etc.

  • Page 36: Advanced Mode

    5.3 Advanced Mode The Advanced Mode provides more options to configure the BIOS settings. Refer to the following sections for the detailed configurations. To access the EZ Mode, press <F6> or click the "EZ Mode" button at the upper right corner of the screen.

  • Page 37: Navigation Keys

    DeskMini B660 series 5.3.2 Navigation Keys Use < > key or < > key to choose among the selections on the menu bar, and use < > key or < > key to move the cursor up or down to select items, then press <Enter>...

  • Page 38: Main Screen

    5.4 Main Screen When you enter the UEFI SETUP UTILITY, the Main screen will appear and display the system overview. The availability and location of BIOS settings can be different for different models and BIOS versions. My Favorite Display your collection of BIOS items. Press F5 to add/remove your favorite items.

  • Page 39: Oc Tweaker Screen

    DeskMini B660 series 5.5 OC Tweaker Screen In the OC Tweaker screen, you can set up overclocking features. Because the UEFI software is constantly being updated, the following UEFI setup screens and descriptions are for reference purpose only, and they may not exactly match what you see on your screen.
  • Page 40 CPU Cache Ratio The CPU Internal Bus Speed Ratio. The maximum should be the same as the CPU Ratio. BCLK Aware Adaptive Voltage BCLK Aware Adaptive Voltage enable/disable. When enabled, pcode will be aware of the BCLK frequency when calculating the CPU V/F curves. This is ideal for BCLK OC to avoid high voltage overrides.
  • Page 41 DeskMini B660 series Intel Thermal Velocity Boost Voltage Optimizations This service controls thermal based voltage optimizations for processors that implment the Intel Thermal Velocity Boost (TVB) feature. Dual Tau Boost Enable Dual Tau Boost feature. This is only applicable for CMLS 35W/65W/125W skus.
  • Page 42 DRAM Reference Clock Select Auto for optimized settings. DRAM Frequency If [Auto] is selected, the motherboard will detect the memory module(s) inserted and assign the appropriate frequency automatically. DRAM Gear Mode High gear is good for high frequency. Primary Timing CAS# Latency (tCL) The time between sending a column address to the memory and the beginning of the data in response.
  • Page 43 DeskMini B660 series RAS to RAS Delay (tRRD_L) The number of clocks between two rows activated in different banks of the same rank. RAS to RAS Delay (tRRD_S) The number of clocks between two rows activated in different banks of the same rank.
  • Page 44 TAT Training Value tRDRD_sg Configure between module read to read delay. tRDRD_dg Configure between module read to read delay. tRDRD_dr Configure between module read to read delay. tRDRD_dd Configure between module read to read delay. tRDWR_sg Configure between module read to write delay. tRDWR_dg Configure between module read to write delay.
  • Page 45 DeskMini B660 series tWRWR_dg Configure between module write to write delay. tWRWR_dr Configure between module write to write delay. tWRWR_dd Configure between module write to write delay. TAT Runtime Value tRDRD_sg Configure between module read to read delay. tRDRD_dg Configure between module read to read delay.
  • Page 46 tWRRD_dr Configure between module write to read delay. tWRRD_dd Configure between module write to read delay. tWRWR_sg Configure between module write to write delay. tWRWR_dg Configure between module write to write delay. tWRWR_dr Configure between module write to write delay. tWRWR_dd Configure between module write to write delay.
  • Page 47 DeskMini B660 series RTL (MC0 C0 A1) Configure round trip latency value. RTL (MC0 C1 A1) Configure round trip latency value. RTL (MC1 C0 B1) Configure round trip latency value. RTL (MC1 C1 B1) Configure round trip latency value. ODT Setting Dimm ODT Training ODT values will be optimized by Dimm On-Die Termination Training.
  • Page 48 MRC Training Respond Time Try Slowest MRC Training. Realtime Memory Timing Configure the realtime memory timings. [Enabled] The system will allow performing realtime memory timing changes after MRC_DONE. Reset for MRC Failed Reset system after MRC training is failed. MRC Training on Warm Boot When enabled, memory training will be executed when warm boot.

  • Page 49: Advanced Screen

    DeskMini B660 series 5.6 Advanced Screen In this section, you may set the configurations for the following items: CPU Configuration, Chipset Configuration, Storage Configuration, ACPI Configuration, USB Configuration and Trusted Computing. Setting wrong values in this section may cause the system to malfunction.

  • Page 50: Cpu Configuration

    5.6.1 CPU Configuration Processor E-Core Information This item displays the E-Core Information. Processor P-Core Information This item displays the P-Core Information. Intel Hyper Threading Technology Intel Hyper Threading Technology allows multiple threads to run on each core, so that the overall performance on threaded software is improved. Active Processor P-Cores Select the number of cores to enable in each processor package.
  • Page 51 DeskMini B660 series CPU C6 State Support Enable C6 deep sleep state for lower power consumption. CPU C7 State Support Enable C7 deep sleep state for lower power consumption. Package C State Support Enable CPU, PCIe, Memory, Graphics C State Support for power saving.
  • Page 52 Legacy Game Compatibility Mode When enabled, pressing the scroll lock key will toggle the Efficient cores between being parked when Scroll Lock LED is on and un-parked when LED is off.

  • Page 53: Chipset Configuration

    DeskMini B660 series 5.6.2 Chipset Configuration Primary Graphics Adapter Select a primary VGA. Above 4G Decoding Enable or disable 64bit capable Devices to be decoded in Above 4G Address Space (only if the system supports 64 bit PCI decoding). VT-d Intel®...
  • Page 54 PCIE ASPM Support This option enables/disables the ASPM support for all CPU downstream devices. PCH PCIE ASPM Support This option enables/disables the ASPM support for all PCH PCIE devices. DMI ASPM Support This option enables/disables the control of ASPM on CPU side of the DMI Link. PCH DMI ASPM Support This option enables/disables the ASPM support for all PCH DMI devices.

  • Page 55: Storage Configuration

    DeskMini B660 series 5.6.3 Storage Configuration SATA Controller(s) Enable/disable the SATA controllers. SATA Mode Selection AHCI: Supports new features that improve performance. Hybrid Storage Detection and Configuration Mode This item allows you select Hybrid Storage Detection and Configuration Mode. SATA Aggressive Link Power Management SATA Aggressive Link Power Management allows SATA devices to enter a low power state during periods of inactivity to save power.

  • Page 56: Acpi Configuration

    5.6.4 ACPI Configuration Suspend to RAM Select disable for ACPI suspend type S1. It is recommended to select auto for ACPI S3 power saving. PCIE Devices Power On Allow the system to be waked up by a PCIE device and enable wake on LAN. RTC Alarm Power On Allow the system to be waked up by the real time clock alarm.

  • Page 57: Usb Configuration

    DeskMini B660 series 5.6.5 USB Configuration XHCI Hand-off This is a workaround for OSes without XHCI hand-off support. The XHCI ownership change should be claimed by XHCI driver.

  • Page 58: Trusted Computing

    5.6.6 Trusted Computing NOTE: Options vary depending on the version of your connected TPM module. Security Device Support Use this item to enable or disable BIOS support for security device. O.S. will not show Security Device. TCG EFI protocol and INT1A interface will not be available. Active PCR banks This item displays active PCR Banks.
  • Page 59 DeskMini B660 series NOTE: Your computer will reboot during restart in order to change State of the Device. Platform Hierarchy Use this item to enable or disable Platform Hierarchy. Storage Hierarchy Use this item to enable or disable Storage Hierarchy.

  • Page 60: Tools

    5.7 Tools UEFI Tech Service Contact ASRock Tech Service if you are having trouble with your PC. Please setup network configuration before using UEFI Tech Service. SSD Secure Erase Tool All the SSD's listed that supports Secure Erase function. NVME Sanitization Tool After you Sanitize SSD, all user data will be permanently destroyed on the SSD and cannot be recovered.
  • Page 61 DeskMini B660 series Network Configuration Use this to configure internet connection settings for Internet Flash. Internet Setting Enable or disable sound effects in the setup utility. UEFI Download Server Select a server to download the UEFI firmware.

  • Page 62: Hardware Health Event Monitoring Screen

    5.8 Hardware Health Event Monitoring Screen This section allows you to monitor the status of the hardware on your system, including the parameters of the CPU temperature, motherboard temperature, fan speed and voltage. Fan Tuning Measure Fan Min Duty Cycle. Fan-Tastic Tuning Select a fan mode for CPU Fan, or choose Customize to set 5 CPU temperatures and assign a respective fan speed for each temperature.

  • Page 63: Security Screen

    DeskMini B660 series 5.9 Security Screen In this section you may set or change the supervisor/user password for the system. You may also clear the user password. Supervisor Password Set or change the password for the administrator account. Only the administrator has authority to change the settings in the UEFI Setup Utility.

  • Page 64: Boot Screen

    5.10 Boot Screen This section displays the available devices on your system for you to configure the boot settings and the boot priority. Fast Boot Fast Boot minimizes your computer's boot time. In fast mode you may not boot from an USB storage device. The VBIOS must support UEFI GOP if you are using an external graphics card.
  • Page 65 DeskMini B660 series Full Screen Logo Enable to display the boot logo or disable to show normal POST messages. AddOn ROM Display Enable AddOn ROM Display to see the AddOn ROM messages or configure the AddOn ROM if you've enabled Full Screen Logo. Disable for faster boot speed.

  • Page 66: Exit Screen

    5.11 Exit Screen Save Changes and Exit When you select this option the following message, “Save configuration changes and exit setup?” will pop out. Select [OK] to save changes and exit the UEFI SETUP UTILITY. Discard Changes and Exit When you select this option the following message, “Discard changes and exit setup?”...
