Portable Winch PCW3000 User Manual

Portable capstan gas-powered pulling winch
Hide thumbs Also See for PCW3000:
Table of Contents

Advertisement

Quick Links

Download this manual
READ
CAREFULLY
BEFORE USE
Portable Winch Co.
PORTABLE CAPSTAN GAS-POWERED PULLING WINCH
TM
PCW3000
USER MANUAL
Maximum pulling capacity (single line): 700 kg (1550 lb)
© 2012 Portable Winch Co. - All Rights Reserved
www.portablewinch.com
English version

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PCW3000 and is the answer not in the manual?

Questions and answers

Related Manuals for Portable Winch PCW3000

Summary of Contents for Portable Winch PCW3000

  • Page 1 READ CAREFULLY BEFORE USE Portable Winch Co. PORTABLE CAPSTAN GAS-POWERED PULLING WINCH PCW3000 USER MANUAL Maximum pulling capacity (single line): 700 kg (1550 lb) © 2012 Portable Winch Co. - All Rights Reserved www.portablewinch.com English version...

  • Page 2: Table Of Contents

    Summary Introduction – p. 3 1.0 Safety guidelines – p. 3 1.1 Safety messages – p. 3 1.2 Label – p. 3 Serial number and warning label – p. 3 1.2.1 1.3 Safety information – p. 4 2.0 Before first use – p. 5 2.1 Upon receiving the winch –...

  • Page 3: Introduction

    Introduction Portable Winch Co. wishes to thank you for purchasing a Portable Capstan Winch . This manual was written to help you make the best use of your new winch and to use it in the most secure way. R .

  • Page 4: Safety Information

    1.3 Safety information DO NOT LET CHILDREN USE THE PORTABLE CAPSTAN WINCH . KEEP CHILDREN AND ANIMALS AWAY FROM THE WORK AREA. NEVER LET SOMEONE WITHOUT TRAINING USE THE PORTABLE CAPSTAN WINCH . MAKE SURE THE USER KNOWS ABOUT THE SAFETY AND USAGE PROCEDURES AND HAS READ THIS MANUAL AND THE HONDA ENGINE USER MANUAL.

  • Page 5: Before First Use

    DO NOT TOUCH THE CAPSTAN DRUM IMMEDIATELY AFTER OPERATION AS IT WILL GET HOT AND BURN BARE SKIN. 2.0 Before first use 2.1 Upon receiving the winch Inspect the box to detect any apparent damage. If there is damage or missing parts, inform the carrier immediately.

  • Page 6: Capstan Drum

    2.2.4 Capstan drum Your Portable Capstan Winch is equipped with a 76 mm (3") capstan drum. Only one (1) size drum fits this winch. 2.2.5 Spark arrestor In certain areas, it is forbidden to use a gas (petrol) engine without a spark arrestor. You Portable Capstan Winch is equipped with an internal spark arrestor.

  • Page 7: Rope Maintenance

    3.1.2 Rope maintenance VISUALLY INSPECT YOUR ROPE BEFORE EACH USAGE. IF IT SHOWS ANY SIGN OF DETERIORATION (CUT STRANDS, EXCESSIVE ABRASION) REPLACE IT. IF YOUR ROPE IS DIRTY, WASH IT. DIRTY ROPES DETERIORATE FASTER AND CAUSE PREMATURE WEAR ON PARTS WHICH ARE IN CONTACT WITH THE ROPE.

  • Page 8: Winch Anchor

    3.3 Winch anchor OPTION 1: In most cases, the winch is anchored to a fixed point using the included polyester sling or with optional anchoring devices and the rope end is tied to the object you want to move. The load is moving towards the winch when you pull the rope. OPTION 2: Alternately, the winch can be anchored to the load that needs to be moved and the rope end is tied to a fixed point.

  • Page 9: Using The Hitch Plate Winch Anchor For Tow Balls Up To 50 Mm (2'') Diameter

    3.3.2 Using the hitch plate winch anchor (PCA-1261) for tow balls up to 50 mm (2'') diameter 1) Figure 1: Push the safety hooks in the rectangular openings of the hitch plate. The rubber plate must be under the winch; 2) Figure 2: Start the winch engine;...

  • Page 10: Using The Winch Support Plate With Heck-Pack System For 50 Mm European Balls And Winch Support Plate Adaptor

    IF YOU NEED TO PULL DOWNWARD, YOU WILL NEED TO INSTALL EITHER A PULLEY OR A ROLLER TO PREVENT DAMAGE TO THE WINCH SUPPORT PLATE. MAKE SURE THE ANCHORING VEHICLE’S HAND BRAKE IS ON AND WORKING PROPERLY. POSITION BLOCKS BEHIND THE WHEELS TO PREVENT ROLL BACK.

  • Page 11: Using The Tree/Pole Mount With Anchor Strap

    MAKE SURE THE ANCHORING VEHICLE’S HAND BRAKE IS ON AND WORKING PROPERLY. POSITION BLOCKS BEHIND THE WHEELS TO PREVENT ROLL BACK. 3.3.5 Using the tree/pole mount with anchor strap (PCA-1263) The tree/pole mount is intended to use with either the winch support plate (PCA-1268) or the vertical pull winch support (PCA-1264).

  • Page 12: With The Winch Support Plate

    3.3.5.1 With the winch support plate (PCA-1268) After the installation of the tree/pole mount (section 3.3.5), follow these steps: 1) Figure 1: Insert the winch support plate onto the square tubing of the tree/pole mount (PCA-1263) and fasten it down with the hitch pin and ‘’R’’ pin; 2) Figure 2: Attach the winch anchor hooks to the eye bolts of the winch support plate;...

  • Page 13: Rope Installation

    THE PORTABLE CAPSTAN WINCH IS NOT INTENDED FOR LIFTING PURPOSES. IMPORTANT: AFTER PULLING FOR A FEW SECONDS, RELEASE THE TENSION AND CHECK THE SOLIDITY OF THE INSTALLATION AND TIGHTEN THE SLING OF THE TREE/POLE MOUNT AGAIN. 3.4 Rope installation USING COMMON SENSE WHILE INSTALLING THE ROPE IS THE KEY TO A SECURE WINCH USAGE.

  • Page 14: Direction

    3.4.3 Direction Install the rope in such a way that it does not rub against other objects. Try to set-up the rope so that the front of the load is slightly lifted. Do not pull downwards or through an obstruction. Generally, if the rope touches the ground while pulling, your installation is incorrect.

  • Page 15: Winching

    3.5.2 Winching While winching, position yourself away from the winch in order to see both the winch and the load. Pull HORIZONTALLY on the rope. The tension you exert on the rope will keep the winch level. DO NOT WRAP THE ROPE AROUND YOUR HANDS OR YOUR BODY! ALSO BEWARE OF THE ROPE ACCUMULATING IN FRONT OF YOU;...

  • Page 16: If Your Rope Is Too Short

    3.5.2.4 If your rope is too short If your rope is too short, you will have to link two ropes together: 1) Figure 1, no. 1: Using the bowline knot (section 3.2.1), link your two ropes together; 2) Figure 1, no. 2: IMPORTANT: Leave about 1 m (3’) of rope tailing out of the knot on the rope holding the load.

  • Page 17: Lubrication

    4.2 Lubrication The gearbox is lubricated at the factory and should not require additional lubrication or maintenance. If there is appearance of a leak, check oil level by placing the winch on a level surface and remove the oil plug (figure 1).

  • Page 18: Warranty

    Hang on to your proof of purchase (invoice with serial number). It will be used to establish the beginning of the warranty period. Portable Winch Co. will replace or repair, at its option, any defective product. All other Portable Winch accessories are covered by a complete one (1) year warranty.

  • Page 19: Ce Declaration Of Conformity

    5.4 CE Declaration of conformity DECLARATION OF CONFORMITY PORTABLE WINCH CO. 1170 Thomas-Tremblay St. Sherbrooke, QC J1G 5G5 CANADA Tel: +1 819 563-2193 www.portablewinch.com Declare that the product Portable Capstan Winch Model PCW3000 For intended purpose Pulling non-rolling objects at angles +45º from...

  • Page 20: Exploded View And Parts List

    5.5 Exploded view and parts list...

  • Page 21: Technical Data

    10-0102 DRUM RETAINING WASHER 44-0001 UNIVERSAL SERIAL NUMBER & WARNING LABEL 44-0025 ROPE INSTALLATION LABEL PCW3000 44-0023 DECIBEL WARNING 93 dB LABEL 5.6 Technical data  Engine: 4-stroke all positions Honda GX-35 cc  Maximum pulling force (single line): 700 kg (1550 lb) ...

  • Page 22: Manufacturer

    5.7 Manufacturer The Portable Capstan Winches are manufactured by: Portable Winch Co. 1170, Thomas-Tremblay Street Sherbrooke, Quebec, J1G 5G5 CANADA Phone: +1 819 563-2193 Toll free (Canada & USA): 1-888-388-PULL (7855) Fax: +1 514 227-5196 Email: info@portablewinch.com www.portablewinch.com...
