Haworth Zody II User Manual

Seat Height Adjustment*
1
Seat height adjustment lets you adjust the chair to
properly position your body at the worksurface and
maintain proper blood flow in your legs. Seat height
should be adjusted to allow your legs to maintain a
90-degree angle to the floor or footrest. (1)Pull up on the
lever and raise your body out of the chair to increase seat
height. (2) Stay in the chair and pull up on the lever to
decrease seat height.
*The indicated dimensions are
determined while chair supports a
load of 64 kg.
2
Back Stop and Forward Tilt
Back stop allows users to lock the back of chair at upright
position for task application. In total there are 6 back rest
positions to fix. (1) Recline to the desired stopping
position and (2) push down on the lever to activate the
back stop. (3) Pull up on the lever to release the back
stop. Rotate the lever forward to engage; rotate backward
to disengage.
Forward Tilt enables you to vary your posture throughout
the day by changing the curve of your spine. (1)Push
down on the lever. (2)Recline just until you hear a click,
then lean forward. (3) Pull up on lever and lean back to
release forward tilt.
Dual Posture*
3
Models with dual posture enable a greater degree of forward tilt to
provide spinal alignment and support for the "perching" posture
between sitting and standing. This posture o ers an alternative to
standing or having to use another chair when you increase the height
of your worksurface. Seat height should be adjusted accordingly.
*The indicated dimensions are
determined while chair supports a
load of 64 kg.
4
Seat Depth Adjustment
Seat depth adjustment moves the seat pad to accommodate
di erent leg lengths. It helps you sit back far enough in the
chair to use the backrest without creating pressure behind
the knees. With a full 74 mm of seat depth you have lots of
room to adjust, so blood flow to your legs isn't restricted
and you stay alert. (1) Pull up and slide the seat forward to
lengthen, or backward to shorten. A minimum of two
fingers should fit between the back of your calf and the
front of the seat.
Haworth - EMEA
Zody II
User Guide
130 mm
400mm 530 mm
6 x
160 mm
590mm
430mm
74 mm
Page 1|2
