EVAL_TDA38812_1VOUT user guide
User guide for TDA38812 evaluation board
Evaluation board test results
Figure 10
Output voltage regulation
3.2
Typical operating waveforms
PV
= V
= 12.0 V, V
= 1 V, I
IN
IN
OUT
Figure 11
Start-up at 12 A load, (Ch1: V
User Guide
= 12 A, F
= 800 kHz, room temperature, no air flow
OUT
SW
, Ch2: V
IN
, Ch3: P
,Ch4: enable)
OUT
GOOD
16
V 1.0
