- Page 1 3142r1 HIGH BACK OWNER’S MANUAL...
-
Page 2: Parts List
PARTS LIST 7-Leg Base with Attached Gas Cylinder Casters (1) Seat Back & Cushion (1) Clear Cylinder Grease THE BEST LUBRICANT FOR THE BEST CHAIRS 6.5cc Grease Packet (1) Handwheels (2) C-Loop OR Pivot Armrests (2) 3205 N 124th Street, Brookfield WI 53005 • 800-892-5563 • CONCEPT SEATING.COM... - Page 3 Assembly Instructions Assembling the Base Remove the plastic cap, 1. Open the base box, this is the if attached. smaller of the two boxes. Set the base on the floor. 2. Unwrap the cylinder from the plastic bag. Remove all packaging from the cylinder.
- Page 4 Assembly Instructions Unboxing 1. Open the chair box. This is the larger of the two boxes and may require a team lift. Take the chair out of the box and remove the plastic bag. Lay the bag on the floor to help keep your chair clean.
- Page 5 Assembly Instructions Assembling the Armrests & Base Cont. 2. Next, slide the cylinder with attached base into the machined hole of the tilt mechanism. The cylinder fits into the tilt mechanism as a compression fit. No additional assembly is required. 3.
- Page 6 Assembly Instructions Note: To prevent damage while in transit, the headrest is not attached to the chair prior to shipping. The headrest is at the bottom of the chair box underneath the chair. The headrest Installing Headrest can be attached easily without tools. 1.
- Page 7 Scan the QR code to visit our maintenance and cleaning directory. Here you’ll find video content and more tools on how to properly use and care for your new Concept Seating chair. For further assistance, please contact us at info@conceptseating.com.
-
Page 8: Adjustment Guide
Adjustment Guide Arm Height Button Arm Width Adjustment Handwheel Seat Lock Button Tension Control Knob Height Adjustment Paddle Height Adjustment Paddle Arm Width Adjustment Handwheel Twist the paddle to adjust the height up or down. To Turn the handwheel clockwise to loosen. Pull out move down, use your body weight to lower the chair. - Page 9 Adjustment Guide Pivot Arm Pad Arm Height Button Activate Pivot Arm via Knuckle Lumbar Support Cover Adjustment Pivot Arm Pad Lumbar Support Adjustment With your hand, move the arm pad forward or backward Making sure the valve on the lumbar bulb is closed, pump and left or right.
-
Page 10: Cleaning Guide
Cleaning Guide ALWAYS PRETEST ANY CLEANING METHOD IN AN INCONSPICUOUS OR UNEXPOSED AREA. Consider purchasing a washable slipcover if sharing the chair with others. ALTERNATIVE LEATHER Basic maintenance is recommended at least once a week to extend the material’s lifespan: 1. - Page 11 Cleaning Guide STACCATO 1. Vacuum the chair. 2. Use an upholstery brush and spot treat to remove stains. 3. Fill a handheld steam cleaner with water and steam your fabric chair. You can use detergents with some steam cleaners; this will help remove strong odors. 4.
- Page 12 The warranty further covers: • The steel foot ring and 200mm cylinder on the Concept Seating 24/7 stool model is warranted for 2 years. This does not apply to the Two-Step Stool models, which are fully covered for 6 years.
