A DIVISION OF LJ DESIGN & MANUFACTURING
3150 Custom Adjustments Guide
Custom Arm Pad
Activate Swing Arms
Seat Depth/Recline Position
Tilt Tension Control
Height Adjustment/Tilt Lock
• Height Adjustment/Tilt Lock: Twist the paddle to adjust the seat height - up or down.
Press button to lock the tilt upright; press again to unlock the tilt.
• Tilt Tension Control: Twist to adjust the strength of tension for your chair if you choose to not lock into place.
• Seat Depth/Recline Position: Twist the paddle to slide the seat forward or backward.
Press button to adjust and lock into one of 5 upright positions.
• Activate Swing Arm: Press up under the swing arms to activate - now swing your arms out of the way.
• Custom Arm Pad: With your hand simply move the arm pad to your preferred position.
3205 N 124th St ) BROOKFIELD, WI 53005 ) 800-892-5563 ) INFO@CONCEPTSEATING.COM ) CONCEPTSEATING.COM
1 of 2
CS - 3150 Custom Adjustment Instructions Form# 1062.02 Revised 07/17
