Concept Seating 3150 Owner's Manual
Hide thumbs
Also See for 3150:
- Assembly instructions (5 pages) ,
- Adjustment instructions (2 pages) ,
- Adjustment manual (2 pages)
Advertisement
Quick Links
Advertisement
Related Manuals for Concept Seating 3150
Summary of Contents for Concept Seating 3150
- Page 1 3150, 3150HR, 3152, 3152HR Owner’s Manual TOOLS NEEDED: Two half-inch wrenches...
-
Page 2: Parts List
PARTS LIST Gas cylinder (1) Handwheels (2) 7-leg base with attached casters (1) C-Loop or Swing Seat Bottom (1) Seat Back (1) Arm Rests (2) Nut (4) Washer (8) Bolt (4) Grease Packet (1) - Page 3 Assembly Instructions Assembling the Base 1. Open the base box, this is the smaller of the two boxes. Set the base on the floor. 2. Unwrap the cylinder from the plastic bag. Remove all packaging from cylinder. Place thin line of grease around the cylinder, two 3.
- Page 4 Assembly Instructions Assemble the Seat 1. Open the chair box. This is the larger of the two boxes and may require a team lift. Take the seat back out of the box and remove the plastic bag. Locate the small red bag attached to the card- board supports and set it aside.
- Page 5 Assembly Instructions Assemble the Seat Cont. 5. Line up the four holes. Place one washer on the bolt head side and thread thorugh the pre-ma- chined hole. Then, place an additional washer and nut on the opposite side of the bolt head. 6.
- Page 6 Assembly Instructions Attach the Armrest to the Chair 1. Open the arm rest box. This is in the chair box. 2. Unscrew the two hand wheels. These are located on the bottom of the seat, both left and right sides. Set handwheels aside for later use.
- Page 7 Scan the QR code to visit our maintenance and repair directory. Here you’ll find video content and more tools on how to properly use and care for your new Concept Seating chair. For further assistance, please contact us at info@conceptseating.
- Page 8 • Arm Width Adjustment: Turn handwheel clockwise to loosen. Pull or push arm rest to desired width. Turn handwheel counterclockwise to tighten and secure the armrest in place. Adjust for both right and left sides. 3205 N 124th Street, Brookfield WI 53005 • 800-892-5563 • CONCEPT SEATING.COM...
- Page 9 • C-Loop/Swing Arm Height: To adjust the heigh of the armrest, locate the button underneath the armrest pad. Push the button in to raise or lower the arm. 3205 N 124th Street, Brookfield WI 53005 • 800-892-5563 • CONCEPT SEATING.COM...
-
Page 10: Cleaning Guide
Cleaning Guide Always pre-test any cleaning method in an inconspicuous or unexposed area. We recommend purchasing a slipcover if sharing chair with others. Alternative Leather For basic maintenance, clean the whole surface in circular motions using liquid hand soap and water (1 part soap to 9 parts water). - Page 11 Cleaning Guide Cont. Fabric Vacuum the chair. Next use an upholstery brush and spot treat to remove stains. Fill a handheld steam cleaner with water and steam your fabric chair. You can use detergents with some steam cleaners; this will help remove strong odors. Allow the chair to dry thoroughly. Spray the seat with a fabric refresher to complete the deodorizing process.
